Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 and headquartered in Qingdao, Shandong, China, is a specialized manufacturer with over 200 employees and a factory area spanning 10,000–30,000 square meters. We bring years of expertise in industrial evaporation and wastewater treatment. Our Tubular Skid-Mounted MVR Evaporator is engineered to deliver high-efficiency mechanical vapor recompression in a compact, pre-assembled package. Every unit comes with a Mill Test Report, ensuring full traceability of materials and compliance with international standards. Designed for reliability and energy savings, this evaporator is ideal for clients requiring a robust, low-maintenance solution for concentration and zero liquid discharge (ZLD) processes.
The tubular heat exchanger design provides excellent heat transfer coefficients and is suitable for handling fouling fluids, scaling liquids, and high-viscosity solutions. The skid-mounted configuration significantly reduces installation time and costs—simply connect utilities and it’s ready to operate. Equipped with an advanced PLC + HMI system, the evaporator offers precise control over temperature, pressure, and flow, ensuring stable performance even under varying feed conditions. Below are the key technical specifications:
| Parameter | Specification |
|---|---|
| Evaporation Capacity | 500 – 50,000 L/h (customizable) |
| Heat Exchanger Type | Vertical or horizontal tubular |
| Material of Construction | SS304, SS316L, Duplex (upon request) |
| Compressor Power | 22 – 400 kW |
| Operating Temperature | 60 – 120°C (adjustable) |
| Power Consumption | 30 – 80 kWh per ton of evaporated water |
| Control System | Siemens PLC + 10” HMI touchscreen |
| Dimensions (Skid) | Customizable; typical footprint 6m x 3m x 4m |
| Standards & Certificates | Mill Test Report; ISO14000, OHSAS18001 (company-level) |
Key Features & Benefits
- Energy Efficiency: MVR technology reuses vapor compression to reduce steam consumption by up to 90% compared to traditional evaporators.
- Compact Skid Design: Pre-piped, pre-wired, and factory-tested—minimizes on-site installation work and saves valuable floor space.
- Material Traceability: Every unit includes a comprehensive Mill Test Report confirming the chemical and mechanical properties of the steel used.
- Versatile Application: Suitable for brines, industrial wastewater, pharmaceutical extracts, food concentrates, and chemical solutions.
- Low Fouling: Tubular design with high fluid velocity reduces scaling and extends operation cycles between cleaning.
- Automatic Control: PLC with remote monitoring capability ensures stable operation with minimal operator intervention.
- Customizable Options: Additional heat recovery, CIP system, or anti-corrosion coatings available upon request.
The standard compliance with Mill Test Report is a distinctive advantage for customers who require strict material verification for projects in pharmaceutical, food, or chemical industries. Our factory follows rigorous quality management practices, and the company holds multiple certifications such as ISO9001, ISO14000, OHSAS18001, SA8000, and others (as listed in our company profile). With an annual export value exceeding US$10 million and a global presence across North America, South America, Europe, Asia, Africa, and Oceania, we have proven our capability to deliver reliable equipment worldwide.
We also provide comprehensive after-sales support including commissioning, training, and spare parts supply. Our engineers can assist with process optimization to maximize your evaporation efficiency. Whether you are looking to reduce waste volume, recover valuable by-products, or meet stringent environmental regulations, the Tubular Skid-Mounted MVR Evaporator from Qingdao Conqinphi is a sound investment.
Contact us today for a tailored proposal. Our team will work with your specific feed composition and required capacity to design the optimal evaporator system. Choose reliability, choose efficiency, choose Conqinphi.
Frequently Asked Questions (FAQ)
-
What is the difference between MVR and traditional multi-effect evaporators?
MVR uses a mechanical compressor to recycle the vapor, requiring only electric power, while traditional evaporators consume steam. MVR can achieve energy savings of 60–90%. -
Does the evaporator come with a Mill Test Report for all wetted materials?
Yes, every unit is supplied with a Mill Test Report for the stainless steel tubes and shell, providing full material traceability. -
Can the skid-mounted unit be installed outdoors?
Yes, the skid is designed for both indoor and outdoor installation. Weatherproofing options (e.g., insulation, rain cover) are available upon request. -
What is the typical lead time for a standard capacity evaporator?
Lead time varies by configuration but generally ranges from 8 to 14 weeks after order confirmation, depending on customization. -
What after-sales service do you provide?
We offer on-site commissioning, operator training, remote technical support, and a one-year warranty for defects in materials and workmanship. -
Can the evaporator handle corrosive or viscous liquids?
Yes, materials can be upgraded to SS316L, Duplex, or special alloys. For high viscosity, we can adjust the tube geometry and flow velocity. -
Is the control system compatible with SCADA or remote monitoring?
Yes, the PLC supports Modbus RTU/TCP and can be integrated into your plant DCS or SCADA system. Remote monitoring options are available. -
Do you provide test runs or pilot trials?
We have a pilot-scale MVR evaporator available at our factory in Qingdao. We also offer mobile test units for on-site demonstration upon request.
