Help CenterStandard Compliant FRP Storage Tank for Dilute H2SO4 Technical Support and Spare Parts Included
Product Spotlights
Related Products
-
3000L FRP Sulfuric Acid Storage Tank 10mm Thickness 0.2MPa Working PressureNegotiableMOQ: 1 Piece -
FRP Chemical Storage Tank for 15% Dilute Sulfuric Acid 5000L With Anti-Leak DesignNegotiableMOQ: 1 Piece
-
Industrial FRP Storage Tank for Dilute Sulfuric Acid Used in Chemical Plant Wastewater TreatmentNegotiableMOQ: 1 Piece
-
Customizable FRP Dilute Acid Storage Tank 20% H2SO4 304 Stainless FittingsNegotiableMOQ: 1 Piece
-
FRP Sulfuric Acid Storage Vessel for Fertilizer Manufacturing 50% Acid ConcentrationNegotiableMOQ: 1 Piece
Hengshui City Yike Composite Materials Co., Ltd., established in 2009 with an annual export value of US$1.5-2.5 million, proudly offers the Standard Compliant FRP Storage Tank for Dilute H2SO4. Designed to safely store dilute sulfuric acid solutions, this tank combines superior corrosion resistance with structural integrity, ensuring long-term reliability in demanding chemical environments. We include comprehensive technical support and essential spare parts to minimize downtime and maximize operational efficiency.
Key Features & Technical Specifications
- Corrosion Resistance: High-quality vinyl ester or epoxy resin liners provide exceptional resistance to dilute H2SO4 (up to 70% concentration), preventing chemical attack and extending tank life.
- Structural Strength: Engineered with advanced filament winding or hand lay-up techniques, the tank wall achieves high tensile strength and impact resistance, suitable for outdoor or indoor installation.
- Standard Compliance: Manufactured in accordance with applicable international standards (e.g., ASTM D3299, GB/T 21238), ensuring consistent quality and safety.
- Customizable Design: Available in vertical or horizontal configurations, with capacities ranging from 500 liters to over 50,000 liters. Fittings such as inlet/outlet nozzles, manholes, and temperature gauges are customizable.
- Thermal Stability: Operates effectively at temperatures up to 80°C (depending on resin choice), suitable for both ambient and mildly heated storage conditions.
- Easy Maintenance: Smooth internal surface reduces scaling and simplifies cleaning. Included spare parts (e.g., gaskets, bolts) facilitate routine service.
- Technical Support: Our engineering team provides installation guidance, troubleshooting, and recommendations for accessories like level indicators, vents, and secondary containment.
Technical Parameters (Example)
| Parameter | Value / Range |
|---|---|
| Capacity | 500L – 50,000L (custom) |
| Working Pressure | Atmospheric (up to 0.1 MPa optional) |
| Design Temperature | -20°C to +80°C |
| Resin Type | Vinyl ester / Epoxy / Polyester (based on acid concentration) |
| Wall Thickness | 4 mm – 20 mm (designed per standards) |
| Spare Parts Included | Gaskets, fasteners, sealant kit, installation manual |
Why Choose Our FRP Storage Tank?
- Reliable Performance: Over 15 years of manufacturing experience ensures consistent quality and compliance with industry norms.
- Global Shipping: Export via Tianjin, Shanghai, or other Chinese ports to markets worldwide (North America, Europe, Southeast Asia, Middle East, etc.).
- Cost-Effective: FRP offers a lower total cost of ownership compared to stainless steel or lined carbon steel tanks for dilute acid storage.
- Comprehensive Service: Technical support from our engineers (installation, maintenance, trouble-shooting) plus a standard spare parts kit included with every order.
- Customization: Choose color, fittings, internal liners, and accessories to match your exact process requirements.
Trust & Company Background
Hengshui City Yike Composite Materials Co., Ltd. has been serving global clients since 2009. With an annual export value between US$1.5 million and US$2.5 million, we supply tanks to diverse industries including chemical processing, water treatment, and electroplating. Our main markets span across North America, South America, Europe, Asia, Africa, and Oceania – a testament to our product’s acceptance and reliability. We adhere to rigorous quality control and offer responsive after-sales support. Contact us today to discuss your dilute H2SO4 storage needs – we provide free quotations and tailor-made solutions with technical support and spare parts included.
Frequently Asked Questions (FAQ)
Q1: What concentration of sulfuric acid can this tank handle?
A: Our FRP tanks are designed for dilute H2SO4, typically up to 70% concentration. For higher concentrations, please consult our engineers for a custom liner recommendation.
Q2: Are installation and foundation requirements provided?
A: Yes, we supply a detailed installation manual and technical support for foundation design. Optional leveling pads and anchor bolts can be included.
Q3: What spare parts come with the tank?
A: Each tank includes a standard spare parts kit containing gaskets, bolts, nuts, sealant, and a maintenance guide. Additional parts are available upon request.
Q4: Can the tank be used for outdoor storage?
A: Absolutely. FRP is UV-resistant (with appropriate gel coat) and weatherproof. We recommend adding UV protection if the tank will be exposed to direct sunlight for extended periods.
Q5: What is the typical delivery time?
A: Lead time depends on capacity and customization, generally 10–30 working days after order confirmation. We ship from major Chinese ports.
Q6: Do you provide certificates of compliance?
A: Yes, we can issue a material test report or certificate of conformance based on standard manufacturing requirements. Specific third-party inspections can be arranged at extra cost.
Q7: How do I clean the tank internally?
A: The smooth FRP interior can be flushed with water or mild detergent. Avoid abrasive tools. Detailed cleaning procedures are in the manual.
Q8: What warranty do you offer?
A: We provide a standard 12-month warranty against manufacturing defects. Extended warranty options are negotiable.
