Qingdao Conqinphi Environmental Technology Group Co., Ltd. is proud to present our Low Temperature Evaporator for Pharmaceutical Waste Concentrating Solvent Recovery. Designed specifically for the pharmaceutical industry, this evaporator efficiently concentrates waste streams and recovers valuable solvents at low temperatures, minimizing thermal degradation and ensuring high purity. With over 9 years of manufacturing experience and a factory spanning 10,000-30,000 square meters, we deliver reliable, energy-saving solutions that meet the rigorous demands of global pharmaceutical facilities.
Our low temperature evaporator operates at temperatures as low as 30-50°C, leveraging vacuum technology to reduce the boiling point of liquids. This gentle process preserves the integrity of heat-sensitive pharmaceutical compounds and solvents, while achieving concentration ratios up to 95%. The system is constructed from high-grade stainless steel (316L) to resist corrosion and comply with sanitary standards. It is fully automated with a PLC and HMI touch screen, allowing precise control of temperature, pressure, and feed rate.
Key features and technical specifications:
- Low Operating Temperature: 30-50°C reduces energy consumption and prevents thermal degradation of active ingredients.
- High Recovery Rate: Up to 98% solvent recovery, significantly reducing waste disposal costs.
- Vacuum System: Advanced vacuum pump ensures stable low-pressure environment for efficient evaporation.
- Compact Design: Modular skid-mounted structure saves floor space and simplifies installation.
- Automated Control: PLC with remote monitoring capability for real-time data logging and alarms.
- Corrosion Resistance: All wetted parts are 316L stainless steel or PTFE-lined.
- Customizable Capacity: Available from 100 L/h to 5000 L/h or more, tailored to your production volume.
| Parameter | Value |
|---|---|
| Evaporation Temperature | 30-50°C (adjustable) |
| Vacuum Level | -0.08 to -0.095 MPa |
| Concentration Ratio | Up to 90-95% |
| Solvent Recovery Rate | ≥95% (depending on solvent type) |
| Power Supply | 380V/50Hz (customizable) |
| Material of Construction | SS316L, PTFE, glass-lined options |
| Control System | Siemens PLC + HMI touch screen |
| Noise Level | ≤75 dB(A) |
Advantages for your pharmaceutical operations:
- Waste Reduction: Convert liquid waste into concentrated residue, reducing disposal volume by 80-90%.
- Solvent Reuse: Recovered solvents can be directly reused in production, cutting raw material costs.
- Energy Efficiency: Low temperature operation and heat pump integration reduce energy consumption by up to 40% compared to traditional evaporators.
- Compliance Ready: Designed to meet GMP and FDA guidelines for pharmaceutical equipment (materials, cleanability, documentation).
- Easy Maintenance: CIP (Clean-in-Place) system integrated; easy access to all components.
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a trusted manufacturer since 2015, with a factory size of 10,000-30,000 square meters and an annual export value of US$10-50 million. We employ 201-300 skilled workers and engineers, and our quality management system is certified under ISO9001, ISO14000, and OHSAS18001. Our products are exported to North America, South America, Europe, Southeast Asia, and many other regions. We ship from Qingdao Port, ensuring timely delivery worldwide.
By choosing our Low Temperature Evaporator, you benefit from over 9 years of R&D expertise, a dedicated after-sales team, and a commitment to environmental sustainability. We offer free technical consultation, on-site installation guidance, and a 12-month warranty. Contact us today to discuss your specific requirements and receive a customized solution that maximizes your solvent recovery while minimizing waste.
Frequently Asked Questions
-
Q: What types of solvents can be recovered with this evaporator?
A: Our low temperature evaporator is suitable for a wide range of organic solvents commonly used in pharmaceuticals, such as ethanol, methanol, acetone, ethyl acetate, and dichloromethane. The system is customizable for specific solvent mixtures. -
Q: What is the minimum operating temperature?
A: The evaporator can operate at temperatures as low as 30°C, depending on the vacuum level and solvent properties. Lower temperatures are achievable with enhanced vacuum systems. -
Q: Does the system require special installation conditions?
A: The unit is skid-mounted and requires only a flat concrete foundation, electrical connection, and cooling water supply. Our team provides detailed installation drawings and on-site support if needed. -
Q: How do you ensure the purity of recovered solvents?
A: The gentle evaporation process minimizes decomposition. Additionally, optional distillation columns or filters can be added to achieve higher purity levels (e.g., >99%) for reuse in critical processes. -
Q: What is the typical payback period?
A: Depending on the volume of waste and solvent value, many customers achieve payback within 12 to 24 months due to reduced disposal costs and solvent purchase savings. -
Q: Can the evaporator handle batch or continuous operation?
A: We offer both configurations. The standard model supports continuous feed, while a batch mode is available for small-scale or variable feed streams. -
Q: Do you provide after-sales service and spare parts?
A: Yes, we offer a 12-month warranty, remote technical support, and a global network of spare parts distributors. Our engineers are available for on-site service upon request. -
Q: What certifications does your factory hold?
A: Our factory is ISO9001, ISO14000, and OHSAS18001 certified. We can also provide CE certification if required for the European market.
