EN1057 Copper Pipe for Residential Plumbing
EN1057 Cu-DHP copper pipe is designed for residential plumbing, heating systems, and domestic water supply applications. With excellent durability, clean surfaces, and compatibility with common installation methods, it provides safe and reliable pipeline solutions.
What Is Copper Tube & Pipe？
Product Definition：
Copper tubes and pipes are hollow, long-length products manufactured from high-purity copper through extrusion and precision drawing processes. With copper content of 99.9% or higher, copper tubes offer exceptional thermal and electrical conductivity, outstanding corrosion resistance, excellent formability, and 100% recyclability. Copper has been the preferred material for HVAC, refrigeration, plumbing, and industrial applications for over a century.
Key Characteristics：
| Feature | Description |
|---|---|
| High Purity | Cu ≥99.9% (C11000 / C12200) – excellent conductivity and corrosion resistance |
| Thermal Conductivity | ~390 W/(m·K) – ideal for heat exchangers, condensers, evaporators |
| Electrical Conductivity | ≥101% IACS – excellent for electrical applications |
| Corrosion Resistance | Natural oxide layer provides long-term protection in most environments |
| Excellent Formability | Readily bent, flared, expanded, and soldered/brazed |
| Antibacterial Properties | Copper surfaces naturally kill 99.9% of bacteria – ideal for plumbing |
| 100% Recyclable | Environmentally friendly with no loss of properties |
Copper Tube vs Other Materials：
| Factor | Copper Tube | Aluminum Tube | Steel Tube | Plastic Pipe |
|---|---|---|---|---|
| Thermal Conductivity | Excellent (390 W/m·K) | Good (230 W/m·K) | Poor (45 W/m·K) | Very poor |
| Corrosion Resistance | Excellent | Good | Poor (requires coating) | Excellent |
| Strength | Good | Moderate | High | Low |
| Bacterial Resistance | Excellent | Poor | Poor | Moderate |
| Recyclability | 100% | 100% | 100% | Limited |
| Service Life | 50+ years | 30+ years | 20+ years | 25+ years |
Key Grades：
| Grade | UNS | Purity | Key Features | Best For |
|---|---|---|---|---|
| C11000 (ETP) | C11000 | ≥99.9% | Highest conductivity, electrolytic tough pitch | Electrical, general purpose |
| C12200 (DHP) | C12200 | ≥99.9% | Phosphorus deoxidized, excellent weldability | HVAC, plumbing, gas lines |
| Cu-DHP | C12200 | ≥99.9% | European equivalent to C12200 | EN 1057 applications |
Typical Applications by Industry：
| Industry | Applications | Recommended Grade / Temper |
|---|---|---|
| HVAC & Refrigeration | Refrigerant lines, condenser coils, evaporator coils, heat pumps | C12200, soft (pancake coil) |
| Plumbing & Water Supply | Hot/cold water lines, heating systems, solar water heaters | C12200, hard or half-hard |
| Gas Distribution | Natural gas, LPG, propane lines | C12200, hard |
| Heat Exchangers | Shell and tube, oil coolers, condensers, evaporators | C11000, C12200 |
| Automotive | Brake lines, fuel lines, hydraulic lines | C12200 |
| Marine | Seawater piping, condensers | C12200, CuNi alloys |
| Instrumentation | Pneumatic lines, control lines, capillary tubing | C12200 |
| Electrical | Bus bars, transformer components | C11000 |
Key Specifications – Copper Tube / Pipe
| Parameter | Specification / Range | Remarks |
|---|---|---|
| Standards | ASTM B280 (ACR), ASTM B88 (plumbing), EN 1057, JIS H3300, GB/T 17791, AS/NZS 1571 | Others on request |
| Grades | C11000 (ETP), C12200 (DHP), Cu-DHP, Cu-ETP, T2, TP2 | Purity ≥99.9% |
| Product Type | Seamless (drawn) | All tubes are seamless |
| Outer Diameter (OD) | 3 mm – 219 mm | Custom on request |
| Wall Thickness | 0.3 mm – 10 mm | Depends on OD |
| Length – Straight | 3 m, 4 m, 5 m, 6 m, or custom | Up to 12m available |
| Length – Pancake Coil | 15 m – 50 m per coil | Soft temper |
| Length – Level Wound Coil | 100 m – 500 m per spool | Soft temper, automated feeding |
| Temper | Soft (annealed), half-hard, hard (drawn) | See Screen 6 |
| Surface | Bright annealed, clean, oil-free | Tinning available |
| Density | 8.94 g/cm³ (C11000/C12200) | – |
| Thermal Conductivity | ~390 W/(m·K) (C11000) | – |
| Electrical Conductivity | ≥101% IACS (C11000) | – |
| Melting Point | 1083°C | – |
| Modulus of Elasticity | 115 GPa | – |
| Testing | Eddy current (100%), hydrostatic, tensile, hardness, flattening, flaring | Mill cert EN 10204 3.1 |
| Packaging | End capped, bundled, wooden case / pallet, plastic wrapped | Seaworthy, ISPM 15 |
