Technical Specification for SLW6130T Solar LED Lighthouse |
||||
|
Product Name |
Solar LED Lighthouse |
||
Product Model |
SLW6130T |
|||
Rated voltage |
DC24V |
|||
IP Level |
IP65 |
|||
Light source |
Light source type |
LED |
||
Power |
4*100W |
|||
luminous flux |
4 * 15000LM |
|||
Service life |
80000h |
|||
Protection level |
IP65 |
|||
Voltage Power |
Operating voltage |
DC24V |
||
Battery Type |
gel battery |
|||
Solar Panels |
3*400W |
|||
Solar cell type |
monocrystalline solar panel |
|||
Control System |
60A/MPPT controller |
|||
Control mode |
Space-time/light control/manual control |
|||
Deployment Method |
Drawer type heavy track |
|||
solar battery |
4 * 200AH |
|||
Battery life |
1000 cycle |
|||
Charging time |
||||
Working time 20H |
||||
Overall dimension |
2200 × 1350 × 2450mm Length * Width * Height |
|||
Lifting mode |
hand cranking |
|||
Light up and down angle adjustment |
0-90 degrees |
|||
Lifting height |
7 meters |
|||
Main rod material |
304 stainless steel |
|||
Tire size |
165 |
|||
Traction tail light |
There are |
|||
Number of legs |
4 1000 lb legs |
|||
Walking wheel |
Folding walking wheel |
|||
Tail light plug |
7-core European standard |
|||
Wind resistance grade |
Level 8 |
|||
Product characteristics |
||||
|
1. scope of application Applicable to a variety of large-scale construction operations, mining operations and other on-site large-scale, high-brightness lighting.
2. performance characteristics: 1. Solar panel technology: it adopts green solar power supply system, monocrystalline silicon photovoltaic power generation technology, long life, less than 10% maximum attenuation, nano surface spraying, not easy to accumulate dust. The three-layer pull-type design structure can be folded quickly for easy storage. Low carbon, green, environmental protection.
2. Solar battery technology: 4x200AH high-efficiency non-memory gel battery pack is adopted ,1000 cycles.
3、Lighting performance: The lamp adopts four 100W high efficiency LED light sources. Each lamp cap can be individually adjusted according to site needs, and the lamp cap can also be adjusted to four different directions for lighting. The overall lighting is both far and near, the lighting brightness is high, the range is large, and the LED light source has a long service life.
4, lighting time 20 hours, charging time 10-16 hours, (according to the customer sunshine time decision), lighting range 100-200 meters range radiation.
5. Lifting performance: Four-section telescopic hand rocker is used as the lifting adjustment method, the overall lifting height is 7 meters, and the beam irradiation angle can be adjusted by rotating the lamp holder up and down.
6. The whole is made of various high-quality metal materials, with compact structure and stable performance, ensuring normal work under various harsh environments and climatic conditions, preventing rain and water spraying, and wind resistance grade is 8.
7, customized: can be customized according to customer needs different power, different configuration, different structure of solar lighting equipment.
|
||||
Design |
||||
Audit |
||||
Approved |
||||
Version |
A0 |
