Our company, Rossonix Co., Limited, has been a trusted supplier of industrial automation components since 2011. We are proud to offer the 1746-NO8I Allen Bradley SLC500 System Analog Output Module – a high-quality, reliable solution for precise analog control in SLC 500 systems. This module delivers stable and accurate output signals, making it an essential component for process control, manufacturing automation, and machinery operations. With our extensive experience in the global market and a strong supply chain based in Shenzhen, we ensure that each module meets stringent quality standards.
The 1746-NO8I provides eight independent analog output channels, each configurable for either voltage (0-10V) or current (4-20mA) output. This flexibility allows you to interface with a wide variety of actuators, valves, drives, and other field devices. The module's 12-bit resolution ensures smooth, accurate control signals, minimizing signal noise and enhancing system performance. Whether you are upgrading an existing SLC 500 system or building a new one, the 1746-NO8I is a drop-in replacement that maintains full compatibility with your existing backplane and programming.
Key Features and Benefits
8 Independent Analog Output Channels – Reduce the need for multiple modules, saving rack space and cost.
Configurable Output Range per Channel – Select 0-10V or 4-20mA via software or DIP switches (depending on system design) to match your field devices.
12-Bit Resolution – Provides precise control with 4096 steps, suitable for fine-tuning processes.
Full Compatibility with SLC 500 Systems – Works with SLC 5/02, 5/03, 5/04, and 5/05 processors without additional adapters.
Isolated Outputs – Each channel is optically isolated to protect your PLC from ground loops and electrical noise.
LED Status Indicators – Individual LEDs for each channel show output status and diagnostic information for easy troubleshooting.
Compact Form Factor – Standard SLC 500 module size fits any 1746 chassis, optimizing panel space.
Low Power Consumption – Draws minimal power from the backplane, reducing overall system heat generation.
Technical Specifications
| Specification | Value |
| Model Number | 1746-NO8I |
| Number of Channels | 8 |
| Output Type | Voltage or Current (selectable per channel) |
| Output Ranges | 0-10V DC (minimum load 1 kΩ) or 4-20 mA (maximum load 500 Ω) |
| Resolution | 12-bit (4096 steps) |
| Accuracy | ±0.1% of full scale (typical) |
| Isolation | Optical isolation per channel, 500V DC |
| Power Consumption | 5V DC @ 120 mA (from backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Dimensions (H x W x D) | 13.3 x 5.0 x 12.0 cm (5.25 x 1.97 x 4.72 in) |
| Weight | Approximately 0.34 kg (0.75 lb) |
Why Choose Our 1746-NO8I Module?
Genuine Allen Bradley Quality – All modules are sourced from reliable channels and tested to ensure they meet original specifications.
Global Stock & Fast Shipping – With warehouses in Shenzhen, Hong Kong, and Europe, we can ship to most countries within 3-7 business days.
Competitive Pricing – We offer factory-direct pricing without compromising on quality, helping you reduce project costs.
Technical Support – Our experienced team (11-50 employees) provides prompt assistance for integration, troubleshooting, and application questions.
Flexible Order Quantities – Whether you need one module or bulk quantities for large-scale projects, we can accommodate your needs.
Trusted Partner for Automation Components
Rossonix Co., Limited has been serving the global industrial automation market since 2011, with an annual export value exceeding US$5 Million. We are proud to hold ISO9001 and ISO9000 certifications, reflecting our commitment to quality management and continuous improvement. Our main markets cover North America, South America, Europe, Oceania, the Middle East, Asia, and more, demonstrating our ability to meet diverse international requirements. We ship from major ports including Shenzhen, Hong Kong, and Europe, ensuring efficient logistics to over 20 countries.
When you choose the 1746-NO8I Allen Bradley SLC500 Analog Output Module from Rossonix, you are not just buying a component – you are investing in reliability, performance, and peace of mind. Each module undergoes rigorous functional testing before shipment, and we offer a standard warranty to protect your investment. Contact us today for a quote or technical consultation. Let us help you optimize your automation system with top-quality products and dedicated service.
Frequently Asked Questions (FAQ)
Q: Is the 1746-NO8I compatible with all SLC 500 processors?
A: Yes, the 1746-NO8I is designed for the SLC 500 platform and works with SLC 5/02, 5/03, 5/04, and 5/05 processors. It can be installed in any standard 1746 chassis.Q: Can I mix voltage and current outputs on different channels?
A: Absolutely. Each channel can be independently configured for either 0-10V or 4-20mA output, providing maximum flexibility for different field devices.Q: How do I configure the output range for each channel?
A: Configuration can be done via the module's DIP switches or through the processor's programming software (e.g., RSLogix 500). Refer to the user manual for detailed steps.Q: What is the typical lead time for this module?
A: For stock items, we can ship within 2-3 business days. For large or custom orders, lead time may be 5-10 working days depending on quantity.Q: Does the module come with a warranty?
A: Yes, we offer a standard 1-year warranty against manufacturing defects. Extended warranty options are available upon request.Q: Is this module a new original product or refurbished?
A: We typically supply new original modules sourced from authorized distributors. If you require refurbished units for cost savings, please contact us for availability and testing details.Q: Can I get technical support for integration?
A: Certainly. Our technical team can provide wiring diagrams, RSLogix 500 configuration examples, and troubleshooting assistance via email or phone.Q: What are the shipping options to North America?
A: We ship via DHL, FedEx, UPS, or sea freight depending on your preference. For small orders, express courier typically takes 3-7 business days to major US cities.
