Help Center1746-OG16 Allen Bradley SLC500 System TTL Output Module 1746OG16
Product Spotlights
Related Products
-
1746-OV16 Allen Bradley SLC500 System DC Output Module 1746OV16NegotiableMOQ: 1 Piece -
1746-OB16 Allen Bradley SLC500 System DC Output Module 1746OB16NegotiableMOQ: 1 Piece
-
1746-OAP12 Allen Bradley SLC500 System AC Output Module 1746OAP12NegotiableMOQ: 1 Piece
-
1746-OB16E Allen Bradley SLC500 System DC Output Module 1746OB16ENegotiableMOQ: 1 Piece
-
1746-OB8 Allen Bradley SLC500 System DC Output Module 1746OB8NegotiableMOQ: 1 Piece
Rossonix Co., Limited, a trusted supplier in the industrial automation sector since 2011, proudly presents the Allen Bradley 1746-OG16 TTL Output Module. Designed specifically for the SLC500 system, this module delivers reliable, high-speed TTL-level output signals for precision control applications. With an annual export value of US$5-10 million and a global distribution network covering North America, Europe, Oceania, and more, Rossonix ensures that every module meets rigorous quality standards. Whether you are upgrading an existing SLC500 rack or building a new control system, the 1746-OG16 offers seamless integration and dependable performance.
Key Features & Benefits
- 16 TTL Output Points – Each channel provides 5V DC TTL logic output, ideal for driving digital logic circuits, indicators, or interfacing with other TTL-compatible devices.
- High-Speed Switching – With typical response times in the microsecond range, this module supports fast-paced applications such as high-speed counting, pulse generation, and real-time control.
- Direct Compatibility – Designed for Allen Bradley SLC500 programmable controllers; plug-and-play installation without additional adapters.
- Industrial-Grade Construction – Built to withstand harsh environments with an operating temperature range of 0°C to 60°C and robust electrical isolation for noise immunity.
- LED Status Indicators – Each output point has a dedicated LED for quick visual diagnostics, simplifying troubleshooting and maintenance.
- Compact Form Factor – Occupies a single slot in the SLC500 chassis, saving valuable rack space for other I/O modules.
Technical Specifications
| Parameter | Value |
|---|---|
| Output Type | TTL (5V DC logic) |
| Number of Outputs | 16 |
| Output Voltage (Nominal) | 5V DC |
| Output Current per Point | 24 mA (sink/source compatible) |
| Backplane Current Draw | 130 mA @ 5V |
| Isolation Voltage | 1500V RMS (optical isolation) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (H x W x D) | Approx. 8.6 x 4.5 x 11.0 cm |
| Weight | 0.25 kg (0.55 lbs) |
Why Choose Rossonix for Your Automation Needs?
At Rossonix Co., Limited, we combine over a decade of experience in industrial automation with a global supply chain to offer you high-quality Allen Bradley components at competitive prices. Our team of 11-50 professionals ensures that every shipment is carefully inspected and packaged. We hold ISO9001:2015 certification, demonstrating our commitment to consistent quality management and customer satisfaction. With an annual export value exceeding US$5 million and strong presence in key markets such as North America, Europe, Asia, and Oceania, we are your reliable partner for automation spares.
Additional Services:
- Flexible shipping options from Shenzhen, Hong Kong, and European warehouses
- Customized packaging and labeling available upon request
- Technical support via email or phone for installation and configuration
- Extended warranty options (up to 2 years) – please inquire
Frequently Asked Questions
-
Q: Can this module be used with SLC 5/01, 5/02, 5/03, 5/04, or 5/05 processors?
A: Yes, the 1746-OG16 is compatible with all SLC500 processors that support the 1746 I/O bus. It works seamlessly in any standard SLC500 chassis. -
Q: What is the difference between TTL output and relay output?
A: TTL outputs provide fast, low-voltage (5V) digital signals ideal for driving logic circuits or solid-state relays, while relay outputs handle higher voltages/currents but operate slower. -
Q: Does the module require an external power supply?
A: No, the module receives power from the SLC500 backplane. The backplane current draw is 130 mA at 5V. -
Q: Are there any software configuration steps required?
A: Typically, the module auto-detects when installed. You may configure output point mapping in RSLogix 500 or similar software, but no complex setup is needed. -
Q: What is the typical lead time for this product?
A: For in-stock items, we can ship within 1-3 business days. For volume orders, lead times vary but are typically 7-15 days depending on quantity and destination. -
Q: Is this product genuine Allen Bradley or a third-party replacement?
A: We supply genuine Allen Bradley (Rockwell Automation) modules sourced from authorized channels. Each unit is tested before shipment. -
Q: Do you offer bulk pricing discounts?
A: Yes, please contact our sales team for quantity discounts. We offer competitive prices for OEMs, system integrators, and distributors. -
Q: What is the warranty period?
A: We provide a standard 1-year warranty against manufacturing defects. Extended warranty options are available upon request.
Contact Rossonix today for a quote or technical inquiry. Our experienced team is ready to help you optimize your control system with the reliable 1746-OG16 TTL output module. Trust in our global track record and ISO-certified quality to keep your operations running smoothly.
