Dear Valued Customer,
As a leading manufacturer with over a decade of expertise, Qingdao Yongke Machinery Co., Ltd. is proud to present our 304 Stainless Steel Frame Krah Marine Pipe Machine PLC Controlled, specifically engineered for the demanding marine environment. Since 2010, we have dedicated ourselves to delivering robust and reliable pipe production solutions, and our latest machine integrates a corrosion-resistant 304 stainless steel frame with advanced PLC control to ensure unmatched precision and durability. Whether you require pipes for offshore platforms, shipbuilding, or coastal infrastructure, this machine guarantees superior performance and longevity, backed by our ISO9001, ISO14000, and OHSAS18001 certified manufacturing processes.
Key Features & Technical Specifications
- 304 Stainless Steel Frame: Resists rust and corrosion in humid and saline marine atmospheres, extending machine lifespan by over 30% compared to standard carbon steel frames.
- Advanced PLC Control System: Fully automated control with touch-screen interface, allowing real-time monitoring of pipe diameter, wall thickness, and production speed. Reduces labor costs and human error.
- Krah Technology: Specialized for spiral wound, ribbed-wall pipes with excellent ring stiffness (up to SN16) suitable for deep-sea drainage and effluent systems.
- High Production Efficiency: Achieves linear speeds up to 20 m/min (customizable) with minimal material waste, thanks to precision temperature control and extruder synchronization.
- Heavy-Duty Components: Equipped with high-torque gearboxes, wear-resistant screws, and German-quality electrical parts to ensure continuous 24/7 operation.
- Eco-Friendly Design: Low energy consumption (energy-saving motor) and noise reduction system meet international environmental standards.
Typical Technical Parameters (Customizable)
| Parameter | Specification |
|---|---|
| Pipe Diameter Range | 200 – 1200 mm (optional up to 3000 mm upon request) |
| Wall Thickness | 0.5 – 6 mm |
| Production Speed | 5 – 20 m/min (adjustable) |
| Extruder Output | Up to 500 kg/h (depending on screw design) |
| Total Power | 150 – 300 kW (customizable) |
| Machine Dimensions (L×W×H) | 25 m × 6 m × 4 m (approx., varies by configuration) |
| Control System | Siemens or Mitsubishi PLC with HMI touch screen |
Benefits for Your Marine Projects
- Corrosion Resistance: The 304 stainless steel frame ensures the machine withstands harsh coastal environments, reducing maintenance frequency and downtime.
- Consistent Quality: PLC control guarantees uniform pipe formation, meeting strict marine standards for pressure resistance and leak-proof performance.
- Easy Operation: User-friendly interface with recipe storage allows quick changeover between different pipe sizes, increasing production flexibility.
- Global Compliance: Our machines are designed to adapt to various local voltage and frequency requirements (380V/50Hz, 440V/60Hz, etc.), making them suitable for export worldwide.
- Comprehensive Support: We provide installation guidance, operator training, and remote technical assistance via video call to ensure smooth commissioning.
Trusted by Global Buyers
Qingdao Yongke Machinery Co., Ltd. has been a trusted partner for marine pipe manufacturers since 2010. With a factory spanning 10,000–30,000 square meters and a dedicated team of 51–100 employees, we have achieved an annual export value of US$1–1.5 million. Our products are shipped from Qingdao Port to markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. We have successfully delivered similar PLC-controlled marine pipe machines to clients in shipbuilding and offshore oil & gas sectors, earning repeat orders through reliable performance and on-time delivery. Your satisfaction is our priority—we offer a comprehensive warranty, spare parts supply, and 24/7 after-sales service.
Choose our 304 Stainless Steel Frame Krah Marine Pipe Machine and invest in a solution that combines cutting-edge technology with rugged durability. Contact us today for a customized quotation or technical proposal tailored to your specific production needs!
Frequently Asked Questions (FAQ)
-
Q: What pipe materials can this machine process?
A: It is primarily designed for HDPE, PP, and PVC resins used in Krah-type spiral pipes. The extruder screw and barrel can be customized for different polymers upon request. -
Q: Can the machine produce pipes with diameters outside the standard range?
A: Yes, the machine is modular. By changing the winding mandrel and calibrator, we can accommodate larger diameters up to 3000 mm. Please consult with our sales team for your specific requirements. -
Q: Is the PLC control system easy to operate for workers without prior experience?
A: Absolutely. The HMI interface is intuitive, with step-by-step guidance and preset production recipes. We also provide on-site training and detailed manuals to ensure quick learning. -
Q: How does the 304 stainless steel frame compare to standard steel frames?
A: 304 stainless steel offers excellent resistance to chloride-induced corrosion, making it ideal for marine environments. It also maintains structural integrity longer, reducing replacement costs over the machine's lifecycle. -
Q: What is the typical lead time and shipping process?
A: Standard lead time is 45–60 days after order confirmation. We offer FOB Qingdao, CIF, or DDP terms. The machine is packed in waterproof and shock-resistant export crates to ensure safe arrival. -
Q: Do you provide after-sales service and spare parts?
A: Yes, we offer a one-year warranty on the entire machine and keep a comprehensive inventory of spare parts. Our technical team is available via email, phone, or video call for troubleshooting. -
Q: What certifications does the machine hold?
A: Our factory is certified with ISO9001, ISO14000, and OHSAS18001. The machine components meet CE standards (CE certification can be arranged at extra cost). We can also provide inspection reports from SGS or other third-party agencies upon request. -
Q: Can I visit your factory before placing an order?
A: Certainly! We welcome customers to inspect our facility in Qingdao, Shandong. We can also arrange online live demos to showcase the machine's operation in real time.
Note: All specifications are subject to customization. For detailed technical drawings and a tailored proposal, please contact our sales engineers.
