Help Center6061 T651 Aluminum Tooling Plate Sheets for Chemical Tanker and Pressure Vessel Manufacturing
Product Spotlights
Related Products
-
1060 Mirror Polished Aluminum Sheet Anti-Oxidation Reflective Pure Aluminum Plate For Kitchen EquipmentUS$ 2.6 - 5.2MOQ: 100 Kilograms -
Marine Anti-Corrosion 5083 H321 Aluminum Plate Combined With 3003 1100 Mirror Aluminum Sheet StockUS$ 2.6 - 5.2MOQ: 100 Kilograms
-
6061 T6 6082 T651 7075 T6 Aluminum Sheet With Laser Cutting Service for Custom PartsUS$ 3 - 5MOQ: 100 Kilograms
-
Ultra High Strength 7075 T6 20-120mm Aluminum Plate Aerospace Industrial ComponentsUS$ 3 - 5MOQ: 100 Kilograms
-
Anti Corrosion Ocean Environment Marine Aluminum Plate Offshore Platform AccessoriesUS$ 3 - 5MOQ: 100 Kilograms
Wuxi Yansheng Technology Co., Ltd. is a professional manufacturer established in 2017, specializing in high-performance aluminum products. Our 6061 T651 Aluminum Tooling Plate Sheets are engineered specifically for demanding environments such as chemical tanker construction and pressure vessel manufacturing. With a factory size spanning 1,000–3,000 square meters and a dedicated team of 101–200 employees, we ensure every plate meets rigorous quality standards. These plates combine excellent machinability, dimensional stability, and corrosion resistance, making them a reliable choice for critical applications.
The 6061 T651 temper provides a stress-relieved condition that reduces internal residual stresses, minimizing distortion during machining. This attribute is vital for tooling plates used in precision fixtures, jigs, and molds. For chemical tankers and pressure vessels, the alloy's inherent resistance to seawater and many chemicals, along with its weldability and formability, offers long service life and safety compliance. Below you will find detailed technical specifications and benefits.
Key Features & Technical Specifications
Material: 6061 T651 aluminum alloy – a precipitation-hardened aluminum with excellent strength-to-weight ratio.
Temper: T651 – solution heat-treated, stress-relieved by stretching, and artificially aged for enhanced stability.
Dimensional Accuracy: Thickness tolerance within ±0.005" (0.13 mm) for critical tooling applications.
Surface Finish: Flat, smooth surface free of pits and scratches; can be supplied with mill finish, brushed, or polished per request.
Corrosion Resistance: Excellent resistance to atmospheric corrosion, seawater, and many chemical media – ideal for tanker and vessel environments.
Machinability: Good chip-breaking properties, allowing high-speed machining with minimal tool wear.
Weldability: Easily weldable using TIG or MIG processes; suitable for fabricating complex structures.
Size Range: Thickness from 6 mm to 200 mm, width up to 2500 mm, length up to 6000 mm; custom sizes available on request.
Typical Mechanical Properties (at room temperature)
Advantages for Chemical Tanker & Pressure Vessel Manufacturing
Weight Savings: Aluminum’s low density (about one-third that of steel) reduces overall vessel weight, improving fuel efficiency and payload capacity.
Non-Sparking: Aluminum alloys are non-sparking, enhancing safety in flammable or explosive cargo environments.
Low Temperature Toughness: 6061 retains good toughness at cryogenic temperatures, suitable for LNG and other low-temperature storage tanks.
Ease of Fabrication: Can be cut, drilled, tapped, and formed with standard shop equipment, reducing manufacturing lead time.
Long-Term Cost Efficiency: Corrosion resistance lowers maintenance and replacement costs over the asset lifecycle.
Quality Assurance & Company Strengths
As a manufacturer with annual export value exceeding US$50 million, Wuxi Yansheng Technology Co., Ltd. has built a reputation for consistent quality and on-time delivery. Our facility is equipped with advanced cutting, heat treatment, and surface processing equipment. We serve markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, demonstrating our global reach and capability. Our quality management system is certified under multiple international standards (including ISO9001, ISO14000, OHSAS18001, and others), ensuring each plate undergoes strict inspection. We ship from major Chinese ports: Tianjin, Shanghai, Qingdao, and Ningbo, offering flexible logistics options.
When you choose our 6061 T651 Aluminum Tooling Plate Sheets, you receive a product that has been stress-relieved for dimensional stability, verified for mechanical properties, and tailored to your specific requirements. We provide custom cutting, surface treatment, and packaging to match your production needs. Contact us today for a quote or technical consultation – let our experience support your next chemical tanker or pressure vessel project.
Frequently Asked Questions (FAQ)
Q: What is the difference between 6061 T651 and 6061 T6?
A: T651 is a T6 material that has been additionally stress-relieved by stretching (1.5% to 3% permanent set) to reduce residual stresses. This provides better flatness and stability during machining, making it preferred for tooling plates.Q: Can these plates be certified for pressure vessel use?
A: Yes, our 6061 T651 plates can be supplied with material test reports (MTRs) and can meet relevant ASME (Section II or VIII) requirements upon request. Please specify your certification needs when ordering.Q: What sizes are available in stock?
A: We maintain a wide range of standard sizes, but custom dimensions are also available. Typical thicknesses are from 6 mm to 200 mm, with widths up to 2500 mm and lengths up to 6000 mm. Contact us for stock availability.Q: How do you ensure the plates are free from internal stresses that cause warping?
A: The T651 temper includes stress relieving by stretching, which significantly reduces internal stresses. Additionally, we perform ultrasonic inspection and flatness checks to ensure minimal distortion during subsequent machining.Q: Is this material suitable for welding into pressure vessels?
A: 6061 aluminum is generally weldable, but proper procedure (e.g., using ER4043 filler wire) and post-weld heat treatment may be needed to restore strength in the heat-affected zone. We recommend consulting a welding engineer for your specific design.Q: What is the lead time for custom orders?
A: Typical lead time for custom sizes or special surface finishes is 15–25 working days, depending on quantity and complexity. Standard stock items can be shipped within 5–10 working days.Q: Can you provide samples for testing?
A: Yes, we can provide small sample plates (e.g., 100x100 mm) free of charge, with the buyer covering shipping costs. Please send a request with your intended application.Q: Do you export to my country?
A: We ship to all major markets worldwide. Our main export regions include North America, Europe, South America, Southeast Asia, Africa, Oceania, and the Middle East. Contact our sales team for a shipping quote to your port.
Disclaimer: The information provided is based on typical data and should not be used as a substitute for professional engineering judgment. Actual performance may vary depending on application conditions. Wuxi Yansheng Technology Co., Ltd. reserves the right to update specifications without notice.
