Wuxi Yansheng Technology Co., Ltd. is proud to offer premium 7075 T6 Aluminum Sheet Plate – a high-strength, aerospace-grade alloy known for its exceptional hardness and structural integrity. Manufactured in our 1,000–3,000 m² facility in Wuxi, China, each plate strictly complies with ASTM B209 / B210 standards, ensuring reliable performance in the most demanding applications. With an annual export value exceeding US$50 million and a dedicated team of 101–200 employees, we guarantee consistent quality and on-time delivery to global markets including North America, Europe, Southeast Asia, and the Middle East.
Our 7075 T6 aluminum alloy plate delivers an outstanding combination of high tensile strength (up to 570 MPa) and light weight (density ~2.81 g/cm³), making it the material of choice for aerospace structural components, military equipment, precision molds, and high-performance sporting goods. The T6 temper (solution heat-treated and artificially aged) provides maximum hardness while maintaining good machinability and corrosion resistance.
Key Features & Specifications
- Exceptional Strength-to-Weight Ratio: Ultimate tensile strength 570 MPa, yield strength 505 MPa – ideal for weight-sensitive applications.
- High Hardness: Brinell hardness 150–160 HB, ensuring wear resistance in tooling and structural parts.
- Excellent Fatigue Resistance: Suitable for cyclic loading components like aircraft wing skins and fuselage frames.
- Good Machinability: Can be cut, drilled, tapped, and CNC milled with standard tools.
- Corrosion Resistance: Naturally protected by an oxide layer; anodizing or coating available for enhanced protection.
- Dimensional Stability: Tight flatness tolerance (ASTM B209) minimizes post-processing warping.
- Wide Size Range: Thickness 0.5–200 mm, width 600–2500 mm, length up to 12 m; custom sizes upon request.
Typical Mechanical Properties (ASTM B209)
| Property | Value | Unit |
| Tensile Strength | 570 | MPa |
| Yield Strength (0.2% offset) | 505 | MPa |
| Elongation | 11 | % |
| Hardness (Brinell) | 150–160 | HB |
| Density | 2.81 | g/cm³ |
| Modulus of Elasticity | 71.7 | GPa |
Applications & Benefits
- Aerospace: Aircraft wing spars, ribs, fuselage frames, helicopter rotor parts – where every gram counts.
- Defense & Military: Armor plates, missile components, and structural brackets requiring high ballistic resistance.
- Mold & Die Industry: High-hardness 7075 T6 is used for plastic injection molds, blow molds, and forming dies due to good wear resistance.
- Sporting Goods: High-end bicycle frames, rock climbing equipment, and archery components benefit from the alloy’s stiffness and light weight.
- General Engineering: Jigs, fixtures, robot arms, and automation parts where strength and dimensional stability are critical.
Customer Benefits: By choosing our 7075 T6 aluminum plate, you reduce machining time thanks to consistent material quality. Our strict dimensional tolerances minimize scrap and rework. We offer flexible cutting services – you can order plates cut to exact dimensions, saving you secondary operations. Surface finishes include mill, brushed, or anodized – customized per your requirements.
Why Choose Wuxi Yansheng Technology Co., Ltd.?
- Proven Track Record: Since 2017, we have exported over US$50 million annually to more than 15 countries and regions.
- Certified Quality Systems: Our factory operates under ISO9001, ISO14000, OHSAS18001, and other management standards – ensuring process control from raw material to final shipment.
- Advanced Equipment: We utilize precision slitting, leveling, and cutting machines to guarantee flatness and edge quality.
- Flexible Logistics: Ship from Tianjin, Shanghai, Qingdao, or Ningbo ports – choose the most cost-effective route for your region.
- Customer Support: Our technical team (101–200 employees) provides prompt pre-sales and after-sales service, including material certificates, test reports, and custom packaging.
Trust Wuxi Yansheng Technology Co., Ltd. for your most demanding aluminum plate needs. With a decade of experience in the industry, we have supplied high-hardness 7075 T6 plates to leading aerospace manufacturers and defense contractors. Contact us today for a quotation, free sample, or technical consultation – let our quality speak for itself.
Frequently Asked Questions (FAQ)
-
Q: Is the 7075 T6 aluminum plate actually certified to ASTM B209?
A: Yes, every batch is produced and tested according to ASTM B209/B210. We provide mill test certificates with each shipment. -
Q: Can you cut the plates to custom sizes?
A: Absolutely. We offer shearing, sawing, and laser cutting services for custom lengths, widths, and shapes. -
Q: What is the typical lead time?
A: For standard sizes (4'×8' sheets), lead time is 7–10 working days. Custom dimensions may take 15–20 days depending on volume. -
Q: Do you offer surface treatments like anodizing or painting?
A: Yes, we can supply clear or colored anodizing, chromate conversion coating, or primer painting as per your requirements. -
Q: What is the difference between 7075 T6 and 6061 T6?
A: 7075 is much stronger (≈570 MPa vs 310 MPa) and harder, but less weldable. 7075 T6 is preferred for high-stress structural parts; 6061 is better for general fabrication. -
Q: Is this plate suitable for food contact applications?
A: 7075 contains zinc and copper; it is not typically recommended for direct food contact unless coated. For food-grade applications, we recommend 5052 or 6061. -
Q: How is the plate packaged for export?
A: Each plate is interleaved with protective paper, strapped onto wooden pallets, and wrapped with waterproof plastic for ocean freight. Custom packaging (e.g., crates) available. -
Q: Can I get a small sample before large order?
A: Yes, sample plates (e.g., 100×100 mm) are available with freight collect. Contact our sales team to arrange.
