Qingdao Conqinphi Environmental Technology Group Co., Ltd. (established in 2015, with a factory area of 10,000–30,000 sqm and an annual export value of US$10–50 million) presents the Compact MVR Wastewater Evaporator Stainless Steel 304 10m³/day. This industrial-grade evaporator is engineered to efficiently concentrate wastewater streams using mechanical vapor recompression technology, significantly reducing energy consumption compared to traditional thermal evaporators. Designed for reliability and ease of operation, it is an ideal solution for industries seeking sustainable wastewater volume reduction and zero-liquid discharge goals.
Our MVR evaporator combines advanced heat pump principles with robust stainless steel 304 construction, ensuring long service life even in corrosive environments. The compact footprint allows easy integration into existing facilities without major civil works. With a treatment capacity of 10 cubic meters per day, it suits medium-scale operations in sectors such as chemical processing, pharmaceuticals, food & beverage, and metal finishing.
Key Features & Technical Specifications
- Energy Efficiency: MVR technology recycles latent heat from vapor, achieving specific energy consumption as low as 30–60 kWh per ton of evaporated water (depending on feed composition).
- Material Quality: All wetted parts are made of stainless steel 304, offering excellent corrosion resistance for a wide range of wastewater streams.
- Compact & Modular Design: The entire unit is prefabricated and skid-mounted, minimizing on-site installation time.
- Automated Control: Equipped with a PLC-based control system and user-friendly touch screen, allowing real-time monitoring of temperature, pressure, flow, and conductivity.
- Flexible Operation: Adjustable evaporation temperature (60–100°C) to handle heat-sensitive or high-boiling-point liquids.
- Low Maintenance: Self-cleaning options available (CIP system) and easy access to key components.
| Parameter | Value |
| Capacity | 10 m³/day (continuous operation) |
| Evaporation temperature | 60 – 100 °C (adjustable) |
| Power supply | 380V / 415V / 480V – 50/60 Hz (customizable) |
| Compressor type | Centrifugal or Roots blower (oil-free available) |
| Material of construction | Stainless Steel 304 (optional 316L) |
| Control system | PLC + HMI touch screen |
| Exterior dimensions (approx.) | 3.5m (L) x 2.0m (W) x 3.0m (H) (may vary per configuration) |
| Weight (approx.) | 4,500 – 6,000 kg |
Customer Benefits
- Reduce operational costs: Lower energy consumption by up to 70% compared to traditional evaporators, thanks to MVR heat recovery.
- Minimize waste disposal volume: Concentrate wastewater to high solids content (up to 30% TDS or more), reducing downstream treatment or hauling costs.
- Meet environmental compliance: Achieve zero liquid discharge (ZLD) when combined with a crystallizer or dryer.
- Simplify maintenance: Modular construction and accessible components reduce downtime.
- Scalable solution: Multiple units can be combined for larger capacities if needed.
Trust & Reliability
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a dedicated manufacturer of environmental equipment since 2015. Our factory spans over 10,000–30,000 square meters and employs 201–300 experienced professionals. With annual exports of US$10–50 million, we serve markets across North America, South America, Europe, Asia, Africa, and Oceania. Our quality management system is certified to ISO9001, environmental management to ISO14000, and occupational health & safety to OHSAS18001, ensuring that every product we deliver meets rigorous international standards. Each MVR evaporator undergoes strict factory testing before shipment from the Port of Qingdao.
We also offer customized configurations — including different materials (SS316L, duplex), additional pre-treatment or post-treatment stages, and remote monitoring options — to match specific wastewater characteristics. Our technical team provides comprehensive after-sales support, including installation guidance, commissioning, and spare parts supply.
Don't let wastewater disposal burden your operation. Contact us today to discuss how our Compact MVR Wastewater Evaporator can help you turn waste into valuable water savings. Request a quote or schedule a virtual demo to see the system in action!
Frequently Asked Questions
-
Q: What types of wastewater can this evaporator handle?
A: It is suitable for industrial wastewater with moderate fouling potential, such as reverse osmosis concentrate, cooling tower blowdown, metalworking fluids, pharmaceutical process streams, and food industry effluents. Highly viscous or heavily scaling streams may require pre-treatment or a different design — please consult our engineers. -
Q: How much energy does it consume per cubic meter of water evaporated?
A: Typical specific energy consumption ranges from 30 to 60 kWh per m³ of evaporated water, significantly lower than conventional multi-effect evaporators (which can consume 200+ kWh/m³). The exact value depends on feed temperature and composition. -
Q: Is the unit fully automated? Can it run unattended?
A: Yes, the PLC system with touch screen provides fully automatic operation including start-up, shutdown, and alarm handling. With proper setup, it can run continuously with minimal operator intervention. However, periodic monitoring is recommended. -
Q: What is the footprint of the 10 m³/day model?
A: Approximate dimensions are 3.5m (L) x 2.0m (W) x 3.0m (H). The actual size varies based on compressor type and optional equipment. We can provide a detailed layout drawing upon request. -
Q: Can the material be upgraded to stainless steel 316L?
A: Yes, we offer SS316L and other corrosion-resistant alloys as options. The price and lead time will vary. -
Q: What certifications does the evaporator comply with?
A: Our manufacturing process follows ISO9001, ISO14000, and OHSAS18001 standards. We can also provide CE certification (if required) as a special request. -
Q: How long is the warranty, and what does it cover?
A: Standard warranty is 12 months from commissioning or 18 months from shipment, whichever comes first. It covers manufacturing defects in materials and workmanship. Extended warranty options are available. -
Q: Do you provide installation and commissioning services overseas?
A: Yes, we offer on-site supervision and training for international customers at cost. We also provide detailed manuals and remote technical support via video call.
