Medium Pressure Boiler Tube – Seamless Carbon Steel
For Industrial Boilers & Cogeneration Systems
OD 6mm – 204mm | WT 1mm – 18mm | Cold Drawn
Product Overview
Our medium pressure boiler tube is a seamless carbon steel tube designed for service where working pressures range from 2.5 MPa to 9.8 MPa and operating temperatures are below 450°C . Manufactured by the cold drawing process, these tubes are widely used in medium industrial boilers, cogeneration systems, and small power station boilers.
Key Features:
Medium pressure rating – Working pressure 2.5-9.8 MPa
Moderate temperature – Operating temperature
Higher strength than low pressure – Suitable for more demanding service
Good weldability – Low carbon content
100% hydrostatic tested – Guaranteed integrity
Full traceability – EN 10204 Type 3.1 MTC with heat number
✅ Working pressure 2.5-9.8 MPa – Designed for medium pressure service
✅ Moderate temperature – Up to 450°C
✅ Higher strength – Thicker walls for higher pressure
✅ Multiple standards – ASTM A210, GB/T 3087, EN 10216-2
✅ Factory direct | Global shipping
Key Specifications
| Parameter | Details |
|---|---|
| OD Range | 6mm – 204mm (Standard Stock: 19mm – 89mm) |
| WT Range | 1mm – 18mm |
| Length | 4m – 12m (fixed or random) |
| Manufacturing | Cold Drawn (Seamless) |
| Standards | ASTM A210, GB/T 3087, EN 10216-2 |
| Grades | A210 A-1/C, 20#, P235GH, P265GH |
| Surface Finish | Black / Bare / Oiled |
| End Finish | Plain / Beveled |
Pressure Rating Classification
| Category | Working Pressure | Working Temperature | Typical Applications |
|---|---|---|---|
| Low Pressure | ≤2.5 MPa | Heating systems, small industrial boilers | |
| Medium Pressure | 2.5-9.8 MPa | Industrial boilers, cogeneration, small power stations | |
| High Pressure | ≥9.8 MPa | 450-650°C | Power station boilers, superheaters |
Grade Selection Guide
| Application | Recommended Grade | Standard | Pressure Range |
|---|---|---|---|
| Industrial boilers | 20# | GB/T 3087 | 2.5-4.0 MPa |
| Cogeneration systems | A210 A-1, P235GH | ASTM A210, EN 10216-2 | 4.0-6.4 MPa |
| Small power stations | A210 C, P265GH | ASTM A210, EN 10216-2 | 6.4-9.8 MPa |
| Medium superheaters | A210 C | ASTM A210 | 4.0-9.8 MPa |
💡 ASTM A210 is specifically designed for medium to high pressure boiler and superheater service , with Grade C offering higher strength for more demanding applications.
Manufacturing Process – Cold Drawing
text
Hot Rolled Tube → Pickling → Cold Drawing → Heat Treatment → Straightening → Cutting → NDT Testing → Hydrostatic Testing → Shipping
Typical Applications
| Application | Pressure Range | Service Type |
|---|---|---|
| Medium industrial boilers | 2.5-4.0 MPa | Steam generation |
| Cogeneration systems | 4.0-6.4 MPa | Combined heat and power |
| Small power station boilers | 6.4-9.8 MPa | Electricity generation |
| Medium temperature superheaters | 4.0-9.8 MPa | Steam superheating |
Why Choose Our Medium Pressure Boiler Tubes?
| Advantage | Description |
|---|---|
| Higher strength than low pressure | Suitable for more demanding service |
| Cost-effective | Lower cost than high pressure alloy grades |
| Good weldability | Low carbon content – easy field welding |
| 100% tested | Hydrostatic – guaranteed integrity |
| Full traceability | EN 10204 3.1 MTC with heat number |
