Help CenterYX114-333-666 Angle-chase Standing Seam Roof Panel, Color Steel & Al-Mg-Mn Profiled Metal Roof Sheet | Factory Direct Supply
Product Spotlights
- Hidden Fastener Design Screw-free surface, permanent roof waterproofing
- Dual Material Options Budget color steel & high anti-corrosion Al-Mg-Mn alloy available
- Super Wind & Snow Resistance High integral rigidity resists extreme harsh weather
- Long Weather Resistance Anti-UV, anti-fading, durable for long outdoor use
- Fast On-site Installation Integrated lock joint cuts construction time & labor cost
Related Products
-
YX25-300 Concealed Standing Seam Roof Tile, Custom Al-Mg-Mn & Color Steel Metal Roof Panel | Factory Direct CustomizationNegotiableMOQ: 1000 Square Meters -
BLT-666 Corrugated Metal Roof Panel | Factory Direct SupplyUS$ 4.62MOQ: 500 Meters
-
Hubei Bilantian Antique Metal Glazed Tiles Blt - 980US$ 5.85MOQ: 500 Meters
-
Hubei Bilantian Antique Metal Glazed Tiles Blt-780US$ 5.85MOQ: 500 Meters
-
Antique Integrated Metal Cylindrical Tile | Factory Direct CustomizationUS$ 28.46 - 29.23MOQ: 500 Meters
Product Overview
YX114-333-666 angle-chase metal roof tile is a popular hidden-fastener profiled roofing panel for steel structure buildings. Featured with 114mm extra high rib design, it realizes ultra-fast rainwater drainage and avoids roof ponding completely. We provide two optional substrates to match different project demands.
Economical color steel version fits ordinary industrial workshops and warehouses; premium Al-Mg-Mn version is suitable for coastal, humid and strong corrosion areas. Adopting concealed standing seam connection, the whole roof has no exposed screws, solving roof leakage fundamentally. Factory direct supply with stable quality and competitive wholesale price.
Technical Specifications
Product Model: YX114-333-666 Angle-chase Standing Seam Roof Tile
Effective Coverage Width: 666mm
Rib Height: 114mm
Rib Spacing: 333mm
Base Material: Prepainted Color Steel Sheet / Al-Mg-Mn Alloy Sheet
Available Thickness: 0.4mm-0.8mm (customizable)
Surface Coating: PE, SMP, HDP weather-resistant protective coating
Custom Length: Cut to any size according to project drawings
Matching Accessories: Standing seam clips, ridge tiles, flashing plates, edge trims
Application Scenarios
Steel structure industrial workshops, factories and warehouses
Logistics parks, distribution centers and large industrial venues
Buildings in heavy rain, strong wind and heavy snow areas
Agricultural greenhouses, breeding plants and temporary buildings
Factory Service Support
Professional profiled steel roof panel manufacturer with factory direct supply. We provide free samples, complete installation drawings and professional technical guidance. Strict pre-delivery quality inspection and reliable after-sales service for global bulk orders.
SEO Product Title
Factory Direct YX114-333-666 Angle-chase Metal Roof Tile, Color Steel & Al-Mg-Mn Hidden Fastener Profiled Roof Sheet for Industrial Buildings
