Help CenterMulti-effect Evaporator 1000L Capacity for Pharmaceutical Industry
Product Spotlights
Related Products
-
5-Effect Falling Film Evaporator With Energy Recovery SystemUS$ 6470 - 869000MOQ: 1 Combo -
316L Stainless Steel Multi-effect Evaporator With Automatic CIPUS$ 6470 - 869000MOQ: 1 Combo
-
Multi-effect Evaporator With Titanium Heat Exchanger for Corrosive MediaUS$ 6470 - 869000MOQ: 1 Combo
-
Multi-effect Evaporator Installation and Commissioning Service IncludedUS$ 6470 - 869000MOQ: 1 Combo
-
Multi-effect Evaporator With 2-Year Warranty and Technical SupportUS$ 6470 - 869000MOQ: 1 Combo
As a leading manufacturer with nearly a decade of expertise, Qingdao Conqinphi Environmental Technology Group specializes in delivering high-performance, reliable industrial solutions. Our Multi-effect Evaporator with a 1000L capacity is engineered specifically for the stringent demands of the pharmaceutical sector, offering superior efficiency in concentration, solvent recovery, and waste stream management. Built within our expansive 10,000-30,000 square meter facility by a dedicated team of 201-300 professionals, this system embodies our commitment to precision engineering and operational excellence for global clients.
This evaporator is designed to maximize energy efficiency and product integrity. The multi-effect configuration significantly reduces steam consumption by reusing vapor from one effect to heat the next, making it a cost-effective and sustainable choice for large-scale pharmaceutical production.
- Enhanced Energy Efficiency: Utilizes a cascading heat recovery process between effects, drastically lowering operational energy costs compared to single-effect units.
- Precision Temperature Control: Maintains precise thermal profiles critical for heat-sensitive pharmaceutical compounds, preventing degradation.
- High-Quality Construction: Fabricated from corrosion-resistant stainless steel, ensuring purity, cleanability, and long-term durability in GMP environments.
- Scalable & Flexible Design: The 1000L capacity is ideal for pilot plants and full-scale production, with customizable configurations (e.g., triple-effect, quadruple-effect) to match specific process viscosity, boiling point elevation, and throughput requirements.
- Advanced Automation: An optional PLC-based control system allows for fully automated operation, precise parameter logging, and reduced manual intervention, enhancing batch consistency and compliance.
Key technical specifications and operational parameters are summarized below:
| Parameter | Specification / Description |
|---|---|
| Design Capacity | 1000 Liters (per effect, approximate working volume) |
| Operating Pressure Range | Vacuum to Atmospheric (customizable) |
| Standard Construction Material | Stainless Steel 316L / 304 (selectable) |
| Heat Transfer Surface Type | Calandria / Falling Film / Forced Circulation (configurable) |
| Primary Heating Medium | Saturated Steam or Thermal Oil |
| Condenser Type | Surface Condenser or Direct Contact (available upon request) |
| Separation Efficiency | Designed for high separation of volatile components |
The system's advantages translate directly into client benefits. It enables reduced utility costs through efficient energy use, ensures product quality and yield protection via gentle evaporation, and supports regulatory compliance with its hygienic design. The robust build minimizes downtime and maintenance, providing a reliable backbone for critical production processes.
Trust is paramount in the pharmaceutical supply chain. Qingdao Conqinphi's operations are backed by a comprehensive quality management system, including ISO9001 certification, ensuring consistent manufacturing standards. Our products reach markets worldwide, with an annual export value of US$10-50 Million, serving North America, Europe, Southeast Asia, and beyond directly from the Port of Qingdao. This global footprint and proven track record underscore our capability to deliver and support complex equipment like the 1000L Multi-effect Evaporator. We invite you to leverage our engineering expertise to optimize your pharmaceutical concentration processes. Contact us today to discuss your specific application and receive a tailored solution proposal.
Frequently Asked Questions (FAQ)
Q1: What is the main advantage of a multi-effect evaporator over a single-effect model for pharmaceutical use?
A: The primary advantage is vastly improved energy efficiency. In a multi-effect system, the vapor produced in one effect serves as the heating source for the next, significantly reducing steam consumption and operational costs, which is crucial for large-scale, energy-intensive pharmaceutical production.
Q2: Can this 1000L evaporator handle heat-sensitive or viscous materials?
A: Yes. The design is highly adaptable. For viscous products, a forced circulation configuration can be specified. For heat-sensitive compounds, operation under vacuum lowers the boiling point, and falling film designs provide short residence time, minimizing thermal exposure.
Q3: What level of automation is typically provided?
A: We offer scalable automation. A basic system includes essential instrumentation for manual control. For full operational control and data integrity, we recommend an optional PLC-based system with a human-machine interface (HMI) for recipe management, monitoring, and reporting.
Q4: Are the materials of construction compliant with pharmaceutical standards?
A> Absolutely. The standard offering uses polished stainless steel (grades 316L or 304), which meets cGMP requirements for cleanability, corrosion resistance, and product contact suitability. Material certificates are available upon request.
Q5: How is the condensate (distillate) handled? Can solvents be recovered?
A: The system is designed for effective separation. The condenser yields a clean condensate stream. For solvent recovery applications, the design can incorporate fractional condensation or specific condenser arrangements to separate and collect different volatile components.
Q6: What is the typical delivery and installation timeline?
A: As a custom-engineered product, the timeline depends on the final configuration. Generally, from order confirmation, fabrication and testing in our factory take approximately 14-20 weeks. We provide detailed installation manuals and can offer supervised installation services.
Q7: Do you provide performance testing or validation support?
A: Yes. The unit undergoes comprehensive factory acceptance testing (FAT) against agreed specifications. We can also provide documentation packages to support your site qualification (IQ/OQ) protocols, though execution is typically client-led.
Q8: What after-sales support do you offer?
A: We provide detailed operation manuals, spare parts lists, and remote technical support. A warranty period covers manufacturing defects. Long-term service contracts for maintenance and spare parts supply are available.
