As a dedicated manufacturer with over a decade of experience in electrical enclosures and control systems, Jinhua Dika Electrical Equipment Co., Ltd. proudly presents our robust 100A Steel Power Distribution Box. Engineered specifically for demanding outdoor environments, this integrated unit combines reliable power distribution with advanced PLC control capabilities within a single, durable NEMA 4X rated enclosure. It is designed to be the central nervous system for your outdoor monitoring networks, providing protected power, intelligent control, and data connectivity for surveillance cameras, sensors, and communication equipment. We understand the critical need for uptime in remote installations, which is why we build this cabinet to withstand harsh weather, corrosion, and temperature fluctuations, ensuring your monitoring operations remain uninterrupted.
This product is more than just a box; it's a complete outdoor electrical solution. The core of its value lies in the seamless integration of a 100-amp power distribution panel with a programmable logic controller (PLC) cabinet. This consolidation eliminates the need for separate enclosures, reducing installation complexity, footprint, and potential failure points. The PLC allows for automated control sequences, remote monitoring via SCADA systems, and intelligent responses to sensor inputs, making your monitoring setup smarter and more efficient. The heavy-duty steel construction provides superior physical protection and electromagnetic shielding for sensitive electronic components.
Let's delve into the specific features and technical specifications that make this distribution box a reliable choice:
- Unmatched Environmental Protection: The NEMA 4X rating certifies protection against windblown dust and rain, hose-directed water, and corrosion. It is suitable for outdoor use in industrial, utility, and infrastructure applications.
- Robust Power Handling: Centered around a 100A main circuit breaker or disconnect switch, the panel is configured with multiple branch circuits to safely distribute power to various monitoring devices, including PoE switches, heater/blowers, and lighting.
- Intelligent Control Core: The integrated PLC compartment is pre-wired with DIN rail, terminal blocks, and surge protection. It is designed to house industry-standard PLCs (brand and model optional) for logic control, data acquisition, and communication protocols like Modbus TCP/IP or Ethernet/IP.
- Thoughtful Design for Serviceability: Features include a removable gland plate for easy cable entry, hinged door with continuous hinge and three-point latching, internal mounting panels, and ample wiring space. Viewing windows and status indicator cutouts are available.
- Thermal Management Options: To maintain optimal internal temperature, the cabinet can be equipped with options such as sun shields, exhaust fans, air conditioners, or thermostatically controlled heaters, all specifiable at the time of order.
The following table outlines some of the key construction and configuration parameters:
| Parameter | Specification / Option |
| Primary Material | Galvanized Steel or Stainless Steel (304) |
| Enclosure Standard | NEMA 4X (Watertight, Corrosion Resistant) |
| Main Disconnect Rating | 100 Amperes |
| Door Seal Material | Silicone Gasket |
| Internal Dimensions (HxWxD) | Customizable (e.g., 60"x48"x24") |
| Paint Finish | Powder-Coated, Standard RAL 7035 |
| Locking Mechanism | Stainless Steel Cam Locks (Keyed Alike Optional) |
Choosing this integrated solution offers significant advantages. It reduces total project cost by combining two critical functions into one purchased and installed unit. It enhances system reliability by providing a controlled, protected environment for both power and control electronics. It simplifies future maintenance and expansion with a clear, organized layout. For system integrators and end-users, this translates to a lower total cost of ownership, reduced system downtime, and a cleaner, more professional installation.
Jinhua Dika Electrical backs this product with a manufacturing pedigree trusted in over a dozen global markets, from North America and Western Europe to Southeast Asia and Africa. Our commitment to structured quality management is reflected in our adherence to ISO 9001 standards for our processes. With an annual export value reflecting consistent international demand, we have the scale and expertise to support your projects. We offer flexible customization to match your exact schematic, branding, and accessory requirements, shipping efficiently from major Chinese ports. For a robust, intelligent, and weatherproof foundation for your next outdoor monitoring deployment, contact us to discuss your specifications and receive a tailored quotation.
Frequently Asked Questions (FAQ)
Q1: Can this cabinet be used in coastal or high-salt environments?
A1: Yes. The NEMA 4X rating includes corrosion resistance. For severe coastal applications, we recommend specifying 304 stainless steel construction for maximum longevity against salt spray.
Q2: Is the PLC included, or is it just an empty cabinet?
A2: The cabinet is designed and pre-wired to accommodate a PLC. The PLC unit itself is typically specified by the customer or system integrator based on the required I/O count and communication protocol. We can source and install a PLC per your project needs as a value-added service.
Q3: How are the internal power distribution components configured?
A3: The internal layout is fully customizable. We work from your provided single-line diagram to install circuit breakers, terminal blocks, transformers, surge protectors, and DIN rail components as specified. We can also provide design assistance.
Q4: What are the delivery lead times for a customized unit?
A4: Lead time depends on the complexity of customization. For a standard design with minor modifications, production typically takes 3-4 weeks. More complex builds may require 5-6 weeks. We provide a firm timeline upon review of your specifications.
Q5: Does the enclosure come with any cable entry provisions?
A5: Yes. It includes a removable gland plate with multiple knockouts for conduit or cable gland entry. The location and size of knockouts can be adjusted per your cable schedule. Sealed cable glands can be pre-installed if specified.
Q6: Can you provide documentation like wiring diagrams and material certifications?
A6: Absolutely. We provide as-built wiring diagrams, a bill of materials, and general arrangement drawings with the shipment. Material certifications for the steel and paint are available upon request.
Q7: Is remote monitoring capability built into the cabinet?
A7: The capability is enabled by the PLC and its communication modules. The cabinet provides the protected housing and power for these components. You would select a PLC with Ethernet or cellular modem capability to achieve remote monitoring and control.
Q8: What is your policy for spare parts or future identical orders?
A8: We maintain drawings and build records for all custom projects. Re-ordering an identical unit is straightforward. We also can supply common spare parts like door gaskets, locks, and latch mechanisms.
