Home > Industrial Equipment & Components > Engine & Part > Engine > Factory 18HP 1105F Air Cooled Single Cylinder Diesel Engine 4 Stroke Vertical Diesel Power Engine With Electric Start
Factory 18HP 1105F Air Cooled Single Cylinder Diesel Engine 4 Stroke Vertical Diesel Power Engine With Electric Start
Product Spotlights
18HP 1105F single cylinder air-cooled, compact portable
Direct injection, low fuel consumption & high torque
Optional hand / electric start, easy cold start
Built-in low oil pressure protection, safe operation
Durable cylinder & crankshaft, long service life
Simple structure, easy maintenance
CE ISO certified, 12-month warranty
Widely used for generator, water pump, farm machinery
Direct injection, low fuel consumption & high torque
Optional hand / electric start, easy cold start
Built-in low oil pressure protection, safe operation
Durable cylinder & crankshaft, long service life
Simple structure, easy maintenance
CE ISO certified, 12-month warranty
Widely used for generator, water pump, farm machinery
US$ 560
1 - 29 Unit
US$ 550
30 - 99 Unit
US$ 530
≥100 Unit
Key Specifications
Get Latest Price
Type:
Electric Motor
Warranty:
1 Year
Fuel:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
20 days
Related Products
-
Belon Power 5KW Multi-fuel Silent Generator Gas LPG CNG Methane PropaneUS$ 810 - 910MOQ: 1 Set -
Belon Power 8KW Multi-fuel Silent Generator Gasoline LPG CNG Natural GasUS$ 880 - 980MOQ: 1 Set
-
Belon Power 10KW Double Cylinder Multi-fuel Silent Generator Gasoline Natural Gas LPG CNG LNG PropaneUS$ 1750 - 1860MOQ: 1 Set
-
7KW Multi-fuel Silent Generator Gasoline Natural Gas CNG LNG LPG Methane Propane Standby GeneratorUS$ 850 - 950MOQ: 1 Set
-
12KW Dual Cylinder Multi-fuel Silent Generator Gasoline Natural Gas CNG LNG LPG Methane Propane Standby Power UnitUS$ 1850 - 1950MOQ: 1 Set
Type
Electric Motor
Warranty
1 Year
Fuel
Diesel
Speed
High Speed
After-sales Service
Send parts with next order
Ignition Mode
Ignition
Cooling Cylinder
Air-Cooled
Intake Pressure Impulse
Naturally Aspirated
Piston Movement
Reciprocating
Number of Strokes
Four-Stroke
Cylinder Arrangement Form
L
Number of Cylinders
Single-Cylinder
Transport Package
Carton
Specification
1105FD
Trademark
Belon Power
Origin
Chongqing, China
Factory 18HP 1105F Air Cooled Single Cylinder Diesel Engine 4 Stroke
Vertical Diesel Power Engine With Electric Start
| Model | 1105FD |
| BorexStroke（mm) | 105x88 |
| Displacement（cc) | 761 |
| Speed（rpm) | 3000/3600 |
| Rated Power | 13kw/18hp |
| Max Power | 13.5kw/19hp |
| Engine Type | Single cylinder，Vertical，4-stroke，direct inject，air-cooled diesel engine |
| Start Mode | Electric |
| Output Mode | crankshaft |
| Fuel Tank Capacity（L) | 8.5 |
| Oil Tank Capacity（L) | 2.2 |
| Packing Size（mm) | 570x550x600 |
| Gross Weight（kg) | 63 |
| Container Load Quantity（20GP/40HQ) | 120/336 |
