As a specialized manufacturer with a strong presence in the global marine industry, Shanghai Zhibang Valve Manufacture Co., Ltd. is proud to present our premium Ductile Iron Gate Valve, engineered specifically for demanding marine and offshore pipeline applications. Since our establishment in 2016, we have dedicated our expertise to producing robust and reliable flow control solutions. This valve is designed to meet the rigorous DIN 3352 specification, offering shipbuilders, offshore platform operators, and marine engineers a dependable component for isolating flow in seawater cooling lines, ballast systems, fuel oil lines, and other critical shipboard services. Its construction prioritizes longevity and minimal maintenance in corrosive marine environments, directly addressing the core need for operational safety and cost-efficiency in maritime operations.
The valve's performance is defined by a combination of superior materials, precise engineering, and adherence to international standards. Below are the key features and technical specifications that set our marine gate valve apart:
- Robust Construction for Harsh Environments: The valve body is cast from high-grade ductile iron (EN-GJS-400-15), providing an excellent balance of strength, toughness, and impact resistance—far superior to standard gray iron. This material choice is critical for withstanding the dynamic stresses, vibrations, and potential water hammer effects common in marine systems.
- Superior Sealing and Corrosion Resistance: The wedge/disc and seat are typically furnished with stainless steel or bronze, ensuring a bubble-tight seal and exceptional resistance to seawater corrosion and erosion. The stem, made from AISI 410 or 304 stainless steel, is designed for smooth operation and long-term integrity.
- Standard-Compliant Design: Manufactured in full compliance with DIN 3352 for gate valves and DIN 3202-F1 for face-to-face dimensions, this valve ensures easy integration and replacement within existing European-standard marine piping systems. Flange connections conform to DIN 2501 standards.
- Versatile Pressure and Operation Options: Available in a range of pressure classes (PN10 to PN40) to suit various system requirements. Operation can be via a standard handwheel, manual gearbox for high-torque applications, or with an electric actuator for remote and automated control systems.
- Protective Coatings: A standard high-quality epoxy coating provides a durable barrier against rust. For particularly aggressive environments, specialized marine-grade coatings (such as zinc-aluminum or reinforced epoxy) are available upon request to extend service life.
The technical specifications for our standard range are summarized in the table below. Custom configurations regarding materials, pressure ratings, and actuation are available to meet specific project needs.
| Parameter | Specification / Option |
| Design & Manufacturing Standard | DIN 3352, DIN 3202-F1 |
| Pressure Rating (PN) | 10, 16, 25, 40 |
| Size Range (DN) | 50, 65, 80, 100, 125, 150, 200, 250, 300 |
| Temperature Range | -10°C to +120°C |
| Stem Type | Rising Stem, Outside Screw & Yoke (OS&Y) |
| Test Standards | Shell Test: 1.5 x PN, Seat Test: 1.1 x PN |
Choosing our DIN 3352 gate valve translates into tangible benefits for your marine projects. You gain a component that reduces downtime through reliable performance, lowers lifecycle costs due to its durable construction and corrosion resistance, and ensures regulatory compliance for vessel and platform systems. The standardized design simplifies procurement, installation, and spare parts management across your fleet or facility.
Trust and Global Reach: Backed by our ISO9001:2015 certified quality management system, every valve undergoes stringent inspections to guarantee performance. Our annual export value of US$1-1.5 million reflects the trust placed in us by clients across North and South America, Europe, Southeast Asia, Africa, the Middle East, and Oceania. We efficiently serve these global markets through major ports like Shanghai, Guangzhou, and Hong Kong. This valve embodies our commitment to delivering industrial-grade reliability where it matters most. For your next marine pipeline project, ensure uninterrupted operation and system integrity with a valve built to exacting standards. Contact us today for a quotation or to discuss your specific technical requirements.
Frequently Asked Questions (FAQ)
Q1: Is this valve suitable for seawater service?
A: Yes, it is specifically designed for marine applications. The use of ductile iron, stainless steel, or bronze for critical wetted parts, combined with protective epoxy coatings, provides excellent resistance to seawater corrosion. For prolonged exposure in highly aggressive conditions, we can provide valves with enhanced marine-grade coatings.
Q2: What does "Meets DIN 3352 Spec" mean for me as a buyer?
A: It guarantees that the valve's design, dimensions, pressure-temperature ratings, and testing procedures conform to a widely recognized and respected German industrial standard. This ensures compatibility with other DIN-standard piping components, predictable performance, and is often a requirement for European shipyards and offshore projects.
Q3: Can this valve be used for other fluids besides water?
A: While optimized for water (sea, fresh, cooling), it can handle other non-aggressive fluids like oils and gases within its specified temperature and pressure limits. The specific fluid compatibility depends on the selected trim materials. Please consult our technical team with your medium details for confirmation.
Q4: What types of operation are available?
A: We offer three main types: Standard Handwheel for manual operation, Gear Operator for larger sizes where handwheel torque is high, and Electric Actuator for integration into automated control systems. The actuator option is customizable.
Q5: What is the delivery lead time for standard sizes?
A: For standard DN50 to DN300 sizes in common pressure ratings, we typically maintain stock or can offer production lead times of approximately 4-6 weeks. Exact timing depends on the order quantity and specific configuration.
Q6: Do you provide documentation with the valves?
A: Yes. Each shipment is accompanied by essential documentation, which usually includes a Material Test Certificate (MTC) or Certificate of Conformity, product manual, and packing list. Detailed inspection reports or third-party certifications are available upon request.
Q7: How does the epoxy coating hold up in a marine environment?
A: The standard epoxy coating is a thermosetting powder coat that provides a thick, uniform, and chemically resistant barrier, offering very good protection against salt spray and atmospheric corrosion. It is a common and effective finish for marine environments. For submerged or splash zone service, we recommend discussing upgraded coating options.
Q8: Can you manufacture valves to other standards like ANSI/ASME?
A: Yes. While this product line focuses on DIN standards, as a manufacturer, we have the capability to produce gate valves to various international standards including ANSI/ASME B16.34, BS, JIS, etc. Please inquire about your required standard.
