Help Center3 Phase SF6 Load Break Switch for Indoor High Voltage Switching in Industrial Plant Power Rooms
Product Spotlights
Related Products
-
Indoor SF6 Load Break Switch Disconnector for Mining Electrical Distribution System ProtectionUS$ 450MOQ: 10 Units -
3 Phase Indoor SF6 Load Break Switch Disconnector, 24kV 630A, Manual/Electric Spring Operating MechanismUS$ 450MOQ: 10 Units
-
Indoor High Voltage 3 Phase SF6 Load Break Switch Disconnector With 2-Year Mechanical WarrantyUS$ 450MOQ: 10 Units
-
SF6 Gas Insulated Load Break Switch, Epoxy Resin Housing, 12kV to 36kVUS$ 520MOQ: 10 Units
-
SF6 Load Break Switch for Substation Secondary Side Protection, 12-36kVUS$ 520MOQ: 10 Units
As a specialized manufacturer with over a decade of experience in electrical equipment, Jinhua Dika Electrical Equipment Co., Ltd. proudly presents our 3 Phase SF6 Load Break Switch, engineered specifically for the demanding environment of indoor high voltage switching in industrial plant power rooms. Our commitment to quality, evidenced by our ISO 9001 certified production processes, ensures that every switch delivers reliable performance, enhanced safety, and simplified maintenance for your critical power distribution infrastructure. This product is a cornerstone of our export portfolio, trusted by clients across North America, Southeast Asia, Europe, and other global markets.
Designed to meet the rigorous demands of industrial applications, our SF6 load break switch offers a compact, maintenance-free solution for safely making, breaking, and isolating high voltage circuits. The use of SF6 gas as the interrupting and insulating medium provides superior arc-quenching capabilities and allows for a significantly reduced footprint compared to air-insulated alternatives, making it ideal for space-constrained power rooms.
Key Features and Technical Advantages:
- Enhanced Safety and Reliability: The sealed SF6 gas chamber ensures operations are isolated from the external environment, preventing internal flashovers and protecting personnel. The design offers a high degree of protection against accidental contact.
- Maintenance-Free Operation: The sealed-for-life SF6 gas system requires no regular maintenance of the interrupting contacts, reducing lifecycle costs and operational downtime.
- High Performance Switching: Capable of making and breaking rated load currents, as well as transformer magnetizing currents and cable charging currents, with ease and reliability.
- Flexible Configuration: Available in both fixed and withdrawable versions to suit different installation and maintenance philosophies. Options include manual spring-operated mechanisms or motorized drives for remote operation.
- Robust Construction: Built with high-quality materials and components to ensure a long mechanical life, typically exceeding 5000 operations, under normal service conditions.
Detailed Technical Specifications:
| Parameter | Specification |
|---|---|
| Rated Voltage (Ur) | 12 kV, 24 kV, 36 kV, 40.5 kV |
| Rated Normal Current (Ir) | 630 A, 1250 A, 1600 A (Customizable) |
| Rated Short-Time Withstand Current (Ik) | 20 kA / 3s, 25 kA / 3s, 31.5 kA / 3s |
| Rated Peak Withstand Current (Ip) | 50 kA, 63 kA, 80 kA |
| SF6 Gas Pressure (at 20°C) | 0.04 MPa (abs) nominal |
| Power Frequency Withstand Voltage (1 min) | 42 kV / 65 kV / 70 kV / 95 kV (Ur dependent) |
| Lightning Impulse Withstand Voltage | 75 kV / 125 kV / 145 kV / 185 kV (Ur dependent) |
| Mechanical Life | ≥ 5000 operations |
| Operating Mechanism | Manual Spring (Standard), Motorized (Optional) |
| Degree of Protection (Enclosure) | IP4X (Standard), Higher ratings available |
Benefits for Your Industrial Plant:
- Space Optimization: The compact design allows for higher density switchgear layouts, maximizing valuable floor space in your power room.
- Operational Continuity: Reliable switching performance minimizes the risk of unplanned outages, supporting continuous production processes.
- Reduced Total Cost of Ownership: Low maintenance requirements and high durability translate into significant cost savings over the equipment's lifespan.
- Improved Safety Culture: The enclosed design and clear switching positions enhance operator safety, contributing to a safer working environment.
- System Flexibility: Suitable for a wide range of applications including ring main units, transformer feeders, and cable feeders within industrial distribution networks.
Backed by Jinhua Dika's robust manufacturing capabilities and a comprehensive portfolio of international management system certifications including ISO 9001, ISO 14000, and OHSAS 18001, this 3 Phase SF6 Load Break Switch represents a fusion of quality, safety, and performance. With an annual export value exceeding US$1 million and a presence in markets from North America to Oceania, our products are proven in diverse industrial settings. Our dedicated team of 11-50 professionals ensures strict quality control from sourcing to shipment via major ports like Shanghai and Ningbo. For a reliable, safe, and efficient solution to your indoor high voltage switching needs, choose the switch trusted by industrial plants worldwide. Contact us today for detailed specifications, pricing, and to discuss your specific application requirements.
Frequently Asked Questions (FAQ):
-
Q: What is the primary advantage of using SF6 gas in this load break switch?
A: SF6 gas offers excellent dielectric strength and arc-quenching properties. This allows for a much more compact switch design compared to air-insulated units, while providing reliable interruption of load currents and enhanced operational safety in a sealed environment. -
Q: Is this switch suitable for outdoor installation?
A: No, this model is specifically designed and rated for indoor installation within protected environments like industrial plant power rooms. For outdoor applications, please inquire about our outdoor-rated switchgear solutions. -
Q: Can the switch be motorized for remote operation?
A: Yes. While a manual spring-operated mechanism is standard, a motorized operating mechanism is available as an optional feature. This enables remote control and integration into SCADA or automation systems. -
Q: What maintenance does the SF6 gas system require?
A: The switch is designed as a maintenance-free, sealed system for the normal service life. The SF6 gas is sealed within the interrupter chamber and does not require replenishment under standard operating conditions. Periodic visual inspections and mechanical checks are recommended. -
Q: What are the standard voltage and current ratings available?
A: We offer a range of standard ratings, typically up to 40.5 kV for voltage and up to 1600 A for current. Specific ratings like 12kV/630A or 24kV/1250A are common. We can also provide customized ratings to match your project specifications. -
Q: How is the switch connected to the power system?
A: The switch features standardized cable connection points or busbar interfaces for easy integration into your switchgear lineup. Connection kits for specific cable types (e.g., copper or aluminum) are available upon request. -
Q: Does the switch provide earth switching functionality?
A: This specific model is a load break switch for circuit isolation and load current interruption. For earthing functionality, it can be optionally combined with a separate earthing switch module to create a switch-disconnector-earthing combination unit. -
Q: What is the typical delivery lead time?
A: Lead times vary based on configuration, order quantity, and current production schedule. For standard models, typical lead times range from 4 to 8 weeks. We recommend contacting our sales team for an accurate timeline for your order.
