American Single Phase Transformer 50Kva to 333Kva for Residential and Commercial Service
Product Spotlights
American Standard Single Phase Transformers (50-333Kva) designed for reliable residential and commercial power distribution. Features robust construction, high efficiency for cost savings, flexible mounting options, and compliance with common industry standards. Ideal for stable voltage transformation in diverse environments, backed by manufacturer expertise and global logistics support.
US$ 1250
≥10 Units
Key Specifications
Get Latest Price
Power Rating:
50Kva to 333Kva
Phase Configuration:
Single Phase
Application:
Residential and Commercial Service
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
American Single Phase Transformer Pad-Mounted Design 50Kva 75Kva 100Kva 167Kva 250Kva 333KvaUS$ 1250MOQ: 10 Units -
Single Phase Pad-Mounted Transformer American Standard Compliant 50Kva to 333Kva RangeUS$ 1250MOQ: 10 Units
-
Single Phase Pad-Mounted Transformer 50Kva 75Kva 100Kva 167Kva 250Kva 333Kva American Voltage RatingUS$ 1250MOQ: 10 Units
-
50Kva 75Kva 100Kva 167Kva 250Kva 333Kva American Single Phase Transformer With Mill Test ReportUS$ 1250MOQ: 10 Units
-
50Kva 75Kva 100Kva 167Kva 250Kva 333Kva Single Phase Transformer American Specification for Reliable Power SupplyUS$ 1250MOQ: 10 Units
Power Rating
50Kva to 333Kva
Phase Configuration
Single Phase
Application
Residential and Commercial Service
Core Material
High-grade silicon steel
Insulation Class
H-class (or customizable)
Cooling Method
AN (Air Natural) or AF (Air Forced)
Winding Material
Copper or Aluminum (available)
Mounting Type
Pad-mounted, Pole-mounted, or Enclosed
Standards Compliance
IEEE C57.12.00, ANSI standards
Optional Features
Taps, protective enclosures, monitoring
As a leading manufacturer, Jinhua Dika Electrical Equipment Co., Ltd. specializes in providing reliable and efficient power solutions for a global market. Our American Standard Single Phase Transformers, ranging from 50Kva to 333Kva, are engineered to deliver stable and safe voltage transformation for both residential communities and commercial facilities. With an annual export value reflecting our commitment to quality and service, we understand the critical need for durable equipment that minimizes downtime and operational costs.
Our transformers are designed to meet the rigorous demands of modern electrical infrastructure. Key features and benefits include:
- Robust Construction: Built with high-grade materials for long-term reliability in diverse environments.
- High Efficiency: Optimized design reduces core and copper losses, leading to lower energy consumption over the transformer's lifespan.
- Flexible Configuration: Available in various mounting styles (pad, pole, enclosed) to suit specific site requirements.
- Thermal Management: Advanced cooling systems ensure stable operation even under continuous or peak loads.
- Safety Focus: Designed with clear safety margins and protective features to safeguard both the equipment and connected systems.
Technical specifications are a cornerstone of our product offering. Below is a summary table of key parameters across the standard range:
| Power Rating (Kva) | Typical Primary Voltage (V) | Typical Secondary Voltage (V) | Approx. Dimensions (LxWxH) mm* | Weight Range (kg)* |
|---|---|---|---|---|
| 50 | 240/480 | 120/240 | 800x600x900 | 350-450 |
| 100 | 240/480 | 120/240 | 900x700x1000 | 550-700 |
| 167 | 2400/4160Y | 240/480 | 1100x900x1200 | 850-1100 |
| 333 | 2400/4160Y | 240/480 | 1300x1100x1400 | 1400-1800 |
*Dimensions and weight are approximate and can vary based on specific design options like enclosure type and tap configuration.
The advantages of choosing our transformers extend beyond the specifications:
- Operational Cost Savings: High efficiency translates directly into reduced electricity bills.
- Reduced Maintenance: Durable construction and quality components minimize the need for frequent servicing.
- System Compatibility: Designed to integrate seamlessly with existing American-standard electrical panels and distribution systems.
- Scalability: The wide power range allows you to select the perfect unit for current needs with options for future expansion.
- Versatile Application: Ideal for powering apartment buildings, shopping centers, schools, offices, and small industrial loads.
With over a decade of experience and a team of 11-50 dedicated professionals, Jinhua Dika has established itself as a trusted partner in the electrical equipment sector. Our products are shipped from major ports like Shanghai, Tianjin, Guangzhou, and Ningbo, ensuring smooth logistics to our main markets across North America, South America, Europe, Asia, Africa, and Oceania. Our operational framework is guided by a commitment to quality management and social responsibility, as reflected in our adherence to recognized standards. This global reach and structured approach enable us to deliver not just a product, but a reliable power solution backed by consistent performance and manufacturer support. We invite you to experience the difference that a purpose-built, quality-engineered transformer can make for your residential or commercial project.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between copper and aluminum windings, and which one is better?
A: Copper windings generally offer higher conductivity and mechanical strength, leading to slightly better efficiency and potentially longer life under high-stress conditions. Aluminum windings are lighter and can be a cost-effective alternative for certain applications. The choice depends on your specific budget, efficiency goals, and load profile. We can advise on the best option for your needs. -
Q: Are these transformers suitable for both indoor and outdoor installation?
A: Yes, our transformers are available in configurations suitable for various environments. Standard models often come in NEMA 3R enclosures for outdoor use, protecting against rain and sleet. Indoor models or units with different enclosure ratings (like NEMA 1 or NEMA 12) are also available upon request to match the installation site conditions. -
Q: Do you offer transformers with multiple voltage taps?
A: Absolutely. We understand that utility voltages can vary. Most of our transformers can be equipped with ±5% or ±2x2.5% voltage taps on the primary side as a standard or optional feature. This allows for fine-tuning the output voltage to compensate for line drops or to match specific equipment requirements. -
Q: What is the typical lead time for an order of a 150Kva transformer?
A: Lead times vary based on order volume, customization, and current production schedule. For standard 150Kva models, the typical production lead time is approximately 4-6 weeks after order confirmation. We provide more accurate timelines during the quotation process. -
Q: Can you provide transformers that meet specific regional standards beyond ANSI/IEEE?
A: While our standard range is built to common American standards (ANSI/IEEE), we have experience in customizing products to meet other international specifications. Please provide the specific standard or certification requirement (e.g., CSA for Canada) during inquiry, and we will evaluate the feasibility. -
Q: What kind of warranty do you offer on these transformers?
A: We stand behind the quality of our manufacturing. Our transformers typically come with a standard warranty covering materials and workmanship. The specific terms and duration (e.g., one year from shipment) will be detailed in the sales contract. Extended warranty options may be available. -
Q: How do I determine the correct Kva rating needed for my application?
A: Selecting the right size involves calculating the total connected load and considering factors like demand factor, diversity, and future expansion. We recommend consulting with a qualified electrical engineer. Alternatively, you can share your load details (equipment list, voltages, phases) with our technical team, and we can assist in recommending an appropriate size. -
Q: Do you provide installation support or technical documentation?
A: Yes, we provide comprehensive technical documentation including wiring diagrams, nameplate data, and installation instructions with each transformer. While we do not typically provide on-site installation services, our technical support team is available to answer questions during the planning and installation phases.
