As a leading manufacturer, Jinhua Dika Electrical Equipment Co., Ltd. specializes in producing reliable and high-performance power solutions. Our American Standard Single Phase Transformers, available from 50Kva to 333Kva, are engineered to deliver stable voltage conversion and distribution for diverse industrial and commercial applications worldwide. Each unit is backed by a comprehensive Mill Test Report, ensuring traceable quality and material integrity from production to delivery. We understand the critical need for dependable power infrastructure, and our transformers are built to meet rigorous standards, offering you a robust and efficient solution for your electrical system needs.
Our transformers are designed with a focus on durability, efficiency, and safety. Key features include:
- Robust Construction: Utilizing high-grade grain-oriented silicon steel cores and high-conductivity windings (copper or aluminum options available) to minimize core losses and ensure efficient operation under various load conditions.
- Superior Thermal Management: Featuring ONAN (Oil Natural Air Natural) cooling and Class H insulation systems, capable of withstanding temperatures up to 180°C, ensuring long-term reliability and stable performance even in demanding environments.
- Compliance & Safety: Manufactured in accordance with American standards (ANSI/IEEE) for electrical and mechanical performance. The inclusion of a Mill Test Report provides verified data on materials and factory tests, giving you full confidence in the product's specifications and quality.
- Customizable Configurations: We offer flexibility in voltage ratings (e.g., 120/240V, 240/480V, or other specifications upon request) and optional accessories like protective enclosures, tap changers, or temperature monitors to suit your specific project requirements.
Below is a summary of key technical specifications for our standard range:
| Power Rating (Kva) | High Voltage (HV) Range* | Low Voltage (LV) Range* | Approx. Weight (kg)** | Typical Application |
|---|---|---|---|---|
| 50 | Up to 15kV | 120/240V, 240/480V | 300-450 | Small workshops, Commercial buildings |
| 75 | Up to 15kV | 120/240V, 240/480V | 400-600 | Light industrial facilities |
| 100 | Up to 15kV | 120/240V, 240/480V | 500-750 | Medium commercial complexes |
| 167 | Up to 15kV | 120/240V, 240/480V | 800-1100 | Heavy machinery, Small factories |
| 250 | Up to 15kV | 120/240V, 240/480V | 1100-1500 | Industrial plants, Large facilities |
| 333 | Up to 15kV | 120/240V, 240/480V | 1400-1900 | Major industrial operations, Power distribution |
* Voltage ratings are customizable. ** Weight is approximate and may vary based on configuration.
The advantages of choosing our transformers are clear. They provide enhanced power quality by stabilizing voltage supply, protecting sensitive equipment from fluctuations. Their energy-efficient design helps in reducing operational costs over the transformer's lifespan. Furthermore, the proven reliability translates to lower maintenance needs and reduced risk of unplanned downtime, safeguarding your productivity. For system integrators and project managers, our products offer a seamless integration into existing American-standard grids, simplifying installation and compliance processes.
With an annual export value ranging between US$1 Million and US$1.5 Million and a presence in major global markets including North America, South America, Europe, and Southeast Asia, Jinhua Dika has established a reputation for consistent quality and dependable service. Our manufacturing processes are supported by a commitment to quality management systems. We ship from major Chinese ports like Shanghai, Tianjin, Guangzhou, and Ningbo, ensuring efficient logistics. When you choose our American Single Phase Transformer, you are not just purchasing a component; you are investing in a power solution backed by international experience, verifiable quality documentation, and a manufacturer dedicated to meeting the precise needs of a global clientele. Contact us today to discuss your specifications and receive a detailed quotation.
Frequently Asked Questions (FAQ)
-
Q: What does "American Standard" mean for these transformers?
A: It signifies that the transformer is designed and manufactured to comply with common electrical standards and practices used in North America, such as those outlined by ANSI (American National Standards Institute) and IEEE (Institute of Electrical and Electronics Engineers), covering aspects like voltage ratings, insulation, and safety. -
Q: Why is the Mill Test Report important?
A: The Mill Test Report (MTR) is a certified document from the material manufacturer. It provides verifiable data on the chemical and physical properties of the core steel and winding conductors used in your specific transformer. This ensures material quality, aids in traceability, and is often required for quality assurance and regulatory compliance in projects. -
Q: Can I get a transformer with custom voltage ratings?
A: Yes, absolutely. While we offer standard configurations like 120/240V and 240/480V, we can customize the primary (high voltage) and secondary (low voltage) ratings to match your specific application requirements. Please provide your detailed specifications during inquiry. -
Q: What is the typical delivery lead time for these units?
A: Lead time varies based on the model, customization, and order quantity. Standard models typically have a shorter lead time. We provide estimated timelines upon order confirmation and work to ensure timely delivery through our established shipping channels from ports like Shanghai or Ningbo. -
Q: What are the available winding material options?
A: We offer transformers with windings made from either electrolytic copper or aluminum. Copper windings generally offer higher conductivity and efficiency, while aluminum can be a cost-effective alternative. We can advise on the best option based on your budget and performance needs. -
Q: Are these transformers suitable for outdoor installation?
A: Our standard units are typically designed for indoor or sheltered outdoor use. For full outdoor exposure, we can provide optional protective enclosures or discuss specific environmental protection features (e.g., corrosion-resistant paint, sealed tanks) that may be required. -
Q: Do you provide installation guidance or technical support?
A: Yes, we provide detailed installation manuals and wiring diagrams with each unit. Our technical team is also available to offer support and answer specific questions regarding installation, operation, and maintenance to ensure optimal performance. -
Q: What after-sales services do you offer?
A: We stand behind our products with a standard warranty. Additionally, we offer technical support, assistance with spare parts identification, and can guide maintenance procedures. Our goal is to ensure your complete satisfaction throughout the product's lifecycle.
