Flat Drip Irrigation Pipe Production LineUS$ 200000 - 250000MOQ: 1 Set
These lines are designed for the production of thin wall irrigation laterals with flat emitters. Ease of use, reliability, performance, repeatablity, economy of material and productivity are qualities which describe the line. All components are available from a single source and offer a fully integrated solution.
High speed Flat Drip Irrigation Tape Line
This flat drip irrigation tape production line is further developed and manufactured, optimizing all the technology of our thousands of high speed & composite pipe production line, absorbing the advanced technology of world class level equipment. It is the leader with the highest speed,fully automation, and outstanding stability.
Tehnical Data:
Model |
Dripper Insertion Speed |
Line Speed |
Feeder +Buffer | Perforation |
Production/day |
QDCO-DL200 |
800PCS/MIN |
180-200M/MIN |
1+0 | 2 Units |
255000-280000m |
QDCO-DL300 |
2000PCS/MIN |
250-300M/MIN |
1+1 | 3 Units |
350000-430000m |
QDCO-DL400 |
3000PCS/MIN |
350-400M/MIN |
2+1 | 4 or 6 Units |
500000-570000m |
Features of Flat Drip Irrigation Tape Machine :
(1) HIGH SPEED: We are the highest speed production line in China, the stable production speed 150m/min, the maximum speed:180m/min.
(2) EASY TO OPERATE: Use the most advanced Simens PLC control system,which can achieve the synchronous control of the the whole line; Fully automatically pipe coiling machine, automatic to change the coil.
(3) STABLE PRODUCTION:Adopt the world famous brand, such as ABB inverter, Schneilder Electric apparatus, Simens servo motor and PLC.We have more than 20 years experience, each parts of the line are manufacture by ourselves,to be sure of the precision and good quality control.
(4) HIGH PRECISION :Punching unit adopts visual imaging PLC monitoring system, to make sure the high speed punching precision.
(5) SAVE COST :High speed improve the production efficiency; automatically function save the human being cost; Thinner Pipe Thickness:0.15mm, can save raw materials cost.
(6) GOOD APPERANCE: With Brushed Stainless Steel Vacuum tank & cooling tank, not rustiness, good looks.
DRIP TAPE APPLICATION:
(1) Drip irrigation tape is the core of drip irrigation system. It is suitable for planting crops in fields, greenhouses and greenhouses. It can save water and fertilizer and improve economic benefits.
(2) At present, drip irrigation is the most commonly used water-saving irrigation method in arid and water shortage areas. Drip irrigation technology can make water utilization rate reach 95%.
(3) Drip irrigation belt is widely used in the places lack of water. Water saving and grain increasing is an important measure to improve the yield of food crops, and drip irrigation technology plays an important role in food production.
(4) The working principle of drip irrigation technology is to use the low-pressure pipeline system to transport water directly to the field, and then through the emitter, orifice or drip irrigation belt installed on the capillary, the water drops evenly and slowly into the soil near the crop root zone, so that the soil in the most developed area of the crop root system often maintains the appropriate humidity and makes the soil water, fertilizer, gas, heat and microorganism live In order to create favorable conditions for high and stable yield of crops.
(5) The water for drip irrigation is stabilized, filtered and fertilized by the first filtration system, then passed through the main pipe and branch pipe, and finally dropped to the plant root through the drip irrigation belt. In a word, drip irrigation is suitable for crops in water shortage area.
