As a leading manufacturer with ISO9001 certification, Shanghai Zhibang Valve Manufacture Co., Ltd. specializes in producing high-performance marine valves. Our CB/T3191 Marine Ball Valve is engineered specifically for demanding seawater applications, offering exceptional corrosion resistance and long-term reliability. With over eight years of industry experience and a significant export footprint across continents from North America to Oceania, we understand the critical requirements of marine and offshore industries. This valve is designed to withstand harsh marine environments, ensuring smooth operation and minimal maintenance for your fluid control systems.
This marine ball valve is constructed from premium 316L stainless steel, a material renowned for its superior resistance to pitting and crevice corrosion in chloride-rich environments like seawater. The design adheres to the CB/T3191 standard, ensuring compatibility and performance consistency for marine applications. Key features and benefits include:
- Superior Corrosion Resistance: The 316L stainless steel body and ball provide excellent protection against saltwater corrosion, significantly extending the valve's service life compared to standard 304 or other materials.
- Robust Construction for Marine Use: Featuring a full port design for minimal pressure drop and flanged ends for secure, leak-proof connections to piping systems commonly found on ships and offshore platforms.
- Reliable Sealing Performance: Equipped with high-grade PTFE or reinforced PTFE seats and seals, ensuring tight shut-off and reliable performance across a wide temperature range.
- Easy Operation and Maintenance: Designed with a standard lever or gear operator for easy quarter-turn operation. The stem is sealed with multiple packing rings to prevent leakage.
- Traceable Quality: Each valve is supplied with a Mill Test Report (MTR), providing full traceability of the raw material's chemical composition and mechanical properties, giving you confidence in material integrity.
- Versatile Pressure Ratings: Available in common pressure classes such as PN16, PN25, Class 150, and Class 300 to suit various system requirements.
Below is a table outlining some typical specifications. Please note that custom configurations are available upon request.
| Specification | Details |
|---|---|
| Product Standard | CB/T3191 |
| Body Material | 316L Stainless Steel (CF3M) |
| Ball & Stem Material | 316L Stainless Steel |
| Seat & Seal Material | PTFE, Reinforced PTFE, RPTFE (Optional) |
| Connection Type | Flanged (RF, FF), Threaded (NPT, BSP) |
| Operation | Lever Handle, Gear Operator (for large sizes) |
| Size Range (Nominal) | DN15 (1/2") to DN300 (12") |
| Temperature Range | -20°C to 180°C (depending on seat material) |
The primary advantage of choosing our marine ball valve is the reduction in total cost of ownership. Its durability in seawater minimizes replacement frequency and downtime. The full port design ensures efficient flow, reducing pumping energy costs. Furthermore, the comprehensive 12-month warranty underscores our confidence in the product's quality and provides peace of mind for your operations.
Shanghai Zhibang Valve backs every CB/T3191 Marine Ball Valve with the trust earned from serving a global clientele across North America, South America, Europe, Asia, Africa, and Oceania. Our annual export value reflects a consistent commitment to quality and customer satisfaction. Supported by our ISO9001 certified manufacturing processes, we ensure every valve meets stringent quality controls before shipment from major ports like Shanghai, Guangzhou, or Hong Kong. This valve is not just a component; it's a reliable solution for critical seawater handling. Contact us today to discuss your specific requirements or to request a detailed quotation for your marine project.
Frequently Asked Questions (FAQ)
Q1: Why is 316L stainless steel specified for this marine ball valve?
A1: 316L stainless steel contains molybdenum, which greatly enhances its resistance to corrosion from chlorides, making it the preferred material for seawater and other aggressive marine environments. The "L" grade denotes low carbon content, reducing the risk of sensitization and intergranular corrosion during welding.
Q2: What is the significance of the CB/T3191 standard?
A2: CB/T3191 is a Chinese national standard specifically for marine valves. It defines the design, material, manufacturing, testing, and inspection requirements for valves used on ships and marine platforms, ensuring they are fit for purpose in marine service.
Q3: What does the Mill Test Report (MTR) include, and why is it important?
A3: The MTR is a certificate from the steel mill that details the chemical composition and mechanical properties (like tensile strength and yield strength) of the raw material batch used for the valve. It is crucial for material traceability, quality verification, and compliance with project specifications.
Q4: Can this valve be used for fluids other than seawater?
A4: Yes. While optimized for seawater, its 316L construction and robust design make it suitable for a wide range of corrosive media, including various chemicals, brackish water, and certain oils, within its specified pressure and temperature limits.
Q5: What types of end connections are available?
A5: The valve is commonly supplied with flanged ends (RF or FF face) per standard dimensions like ANSI, JIS, or DIN. Threaded ends (NPT, BSP) are also available for smaller sizes. Other connection types can be customized upon request.
Q6: Is the valve fire-safe?
A6: Standard models are not certified as fire-safe. However, fire-safe design versions with metal secondary seals can be provided as a special order. Please inquire for specific fire-safe certification requirements.
Q7: What is covered under the 12-month warranty?
A7: The warranty covers defects in materials and workmanship under normal use and service conditions as specified. It includes repair or replacement of the defective valve. The warranty does not cover damage from improper installation, misuse, or operation outside designated parameters.
Q8: Do you offer customization for specific project needs?
A8: Absolutely. As a manufacturer, we can customize various aspects including size, pressure rating, end connection standards, operator type (lever, gear, pneumatic, electric actuator), and special coatings or markings to meet your project's exact specifications.
