Help CenterVacuum-sealed Corn Sterilization Autoclave, Canned Corn Steam High-pressure Sterilization Autoclave,Steam& Air Retort
Product Spotlights
By adding a fan on the basis of steam sterilization, the heating medium and the packaged food are in direct contact and forced convection, and the presence of air in the retort is allowed. The pressure can be controlled independently of the temperature. The retort can set multiple stages according to different products of different packages.
Applicable to the following fields:
Dairy products: tin cans; plastic bottles, cups; flexible packaging bags
Related Products
-
Steam and Air Retort / Canned Pet Food Sterilization RetortUS$ 30000 - 100000MOQ: 1 Unit -
Retort Manufacturer / Steam Air Retort / Professional Manufacturer of Condiment Sauce Packaging Sterilization LineUS$ 30000 - 100000MOQ: 1 Unit
-
Steam and Air Sterilization Retort / Sterilization Equipment for Plastic Cup-Packaged FoodUS$ 30000 - 100000MOQ: 1 Unit
-
Steam& Air Retort /Fish Canned Food High-temperature Sterilization Equipment/Autoclave Food Sterilizer/Canned Fish RetortUS$ 30000 - 100000MOQ: 1 Unit
-
DTS/Spray Type Steam Fish Canned Food Sterilization Retort Steam Autoclave Retort/thermal SterilizationUS$ 30000 - 100000MOQ: 1 Unit
Working principle:
Put the product into the sterilization retort and close the door. The retort door is secured by triple safety interlocking. Throughout the whole process, the door is mechanically locked.
The sterilization process is automatically carried out according to the recipe input to the micro-processing controller PLC.
This system is based on the direct heating for food packaging by steam, without other heating media (for example, the spray system is used water as an intermediate medium). Since the powerful fan forces the steam in the retort to form a cycle, the steam is uniform. Fans can accelerate the heat exchange between steam and food packaging.
Throughout the whole process, the pressure inside the retort is controlled by the program by feeding or discharging compressed air through the automatic valve to the retort. Due to steam and air mixed sterilization, the pressure in the retort is not affected by temperature, and the pressure can be set freely according to the packaging of different products, making the equipment more widely applicable (three-piece cans, two-piece cans, flexible packaging bags, glass bottles, plastic packaging etc.).
Model |
Diameter (mm) |
Body Length (mm) |
Volume (m³) |
Length (mm) |
Width (mm) |
Height (mm) |
Basket size (LWHmm) |
Design temperature(℃) |
Test Pressure (bar) |
Design pressure (bar) |
H-1203 |
1200 |
3000 |
3.79 |
5100 |
2350 |
2300 |
780×780×755 |
147 |
0.44 |
0.35 |
H-1204 |
1200 |
3800 |
4.69 |
5300 |
2350 |
2300 |
780×780×755 |
147 |
0.44 |
0.35 |
H-1205 |
1200 |
4650 |
5.65 |
6400 |
2350 |
2300 |
780×780×755 |
147 |
0.44 |
0.35 |
H-1403 |
1400 |
3300 |
5.70 |
4150 |
2450 |
2600 |
870×870×890 |
147 |
0.44 |
0.35 |
H-1404 |
1400 |
4200 |
7.08 |
5100 |
2450 |
2600 |
870×870×890 |
147 |
0.44 |
0.35 |
H-1504 |
1500 |
4500 |
8.70 |
5700 |
2450 |
2600 |
930×930×930 |
147 |
0.44 |
0.35 |
H-1505 |
1500 |
5500 |
10.47 |
6600 |
2450 |
2600 |
930×930×930 |
147 |
0.44 |
0.35 |
H-1605 |
1600 |
5900 |
12.77 |
6400 |
2700 |
3400 |
1000×1000×975 |
147 |
0.44 |
0.35 |
H-1606 |
1600 |
6900 |
14.78 |
7300 |
2700 |
3400 |
1000×1000×975 |
147 |
0.44 |
0.35 |
H-1805 |
1800 |
6600 |
18.07 |
7500 |
3200 |
3800 |
1120×1120×1120 |
147 |
0.44 |
0.35 |
H-1806 |
1800 |
7800 |
21.12 |
8500 |
3200 |
3800 |
1120×1120×1120 |
147 |
0.44 |
0.35 |
H-2005 |
2000 |
7200 |
24.35 |
8000 |
3900 |
4500 |
1240×1240×1240 |
147 |
0.44 |
0.35 |
The listed price serves as a deposit. Before placing an order, please be sure to contact us to discuss your detailed requirements and obtain an accurate quote, thereby avoiding any unnecessary complications.
