Help CenterHigh Permeability Cold Rolled Grain Oriented Silicon Steel Strip Narrow Coil for Transformer Inductor Core Low Iron Loss
Product Spotlights
Silicon steel coil features stable electromagnetic performance for electric equipment.
Silicon steel coil is widely used in transformers, motors and electrical industries.
Related Products
-
High Permeability Silicon Steel Strip Precision Slit Grain Oriented Electrical Steel Coil Custom Width Cutting for Magnetic CoreUS$ 555 - 565MOQ: 10 Metric Tons -
Cold Rolled High Permeability Silicon Steel Strip for Efficient Energy TransmissionUS$ 555 - 565MOQ: 10 Metric Tons
-
Robust K9 Centrifugal Ductile Cast Iron Pipe for Long Term Municipal Drinking Water UseUS$ 555 - 565MOQ: 10 Metric Tons
-
Cold Rolled High Permeability Silicon Steel Strip for Efficient Power Transformer Core ManufacturingUS$ 555 - 565MOQ: 10 Metric Tons
-
Low Loss High Permeability Silicon Steel Strip for Generator and Electric Motor Core ApplicationsUS$ 555 - 565MOQ: 10 Metric Tons
Silicon steel coil, also known as electrical steel or cold-rolled silicon steel, is a soft magnetic iron-silicon alloy containing 0.5%–4.5% silicon. It is primarily used to manufacture cores for motors, transformers, and inductors. The key performance requirements are low core loss (iron loss) and high magnetic permeability. Common grades include: 50W800, 50W1300, 35W270, 35W440, B50A470, B35A210, 23Q110, etc. In these designations, W stands for Non-Oriented (NO), while Q or R stands for Grain-Oriented (GO). Grain-oriented silicon steel (e.g., 23Q110) offers excellent magnetic properties along the rolling direction and is ideal for transformers. Non-oriented silicon steel (e.g., 50W1300) is isotropic and suitable for rotating machines.
Applications:
Motors: home appliances (air conditioners, refrigerators, washing machines), industrial motors, EV traction motors
Transformers: power transformers, distribution transformers, reactors
Small inductors: ballasts, relays, current transformers
Customer Common Terms & Abbreviations:
CRGO: Cold-Rolled Grain-Oriented steel
CRNGO: Cold-Rolled Non-Oriented steel
Core loss (iron loss): unit W/kg (e.g., P1.5/50 = 1.5 Tesla, 50Hz)
Magnetic induction: B50 (flux density at 5000 A/m)
Laminations: stacked core sheets
Annealing: heat treatment to relieve stress
Insulation coating: T2, T3, T4 types
Thickness specifications: 0.23mm, 0.27mm, 0.30mm, 0.35mm, 0.50mm
When placing orders, customers typically define technical requirements using grades (e.g., 50W1300 or 23Q110), CRGO/CRNGO, core loss values, and thickness.
