As a leading manufacturer with a strong global footprint, Shanghai Zhibang Valve Manufacture Co., Ltd. specializes in delivering robust and reliable fluid control solutions for demanding marine environments. Our DN50-DN600 Marine Butterfly Valves are engineered specifically for shipboard seawater systems, where corrosion resistance, durability, and fail-safe operation are non-negotiable. Leveraging our ISO9001-certified production processes and years of expertise, we provide valves that ensure long-term system integrity and minimal maintenance, helping ship operators and builders enhance operational safety and reduce lifecycle costs. Trusted by clients across North America, Europe, Asia, and beyond, our products are a cornerstone for reliable marine engineering.
These marine-grade butterfly valves are designed to handle the harsh conditions of seawater, including high salinity, suspended solids, and varying pressures. The core design features a rotating disc to regulate flow, offering excellent shut-off capabilities and low-pressure drop. Key characteristics include:
- Superior Corrosion Protection: Critical components are constructed from materials like stainless steel and nickel-aluminum bronze, which offer exceptional resistance to seawater pitting and crevice corrosion.
- Robust Sealing Performance: Utilizing elastomer seats such as EPDM or NBR, the valves ensure bubble-tight shut-off even after prolonged exposure to abrasive media.
- Versatile Actuation Options: Available with manual lever handles, precision gear operators, or automated electric actuators for integration into centralized control systems.
- Compact & Lightweight Design: The wafer-style construction saves space and weight compared to gate valves, a critical advantage in space-constrained shipboard installations.
- Broad Compatibility: Designed to fit standard flange dimensions (e.g., ANSI, DIN, JIS), facilitating easy replacement and installation in existing seawater pipelines.
The technical specifications of our DN50-DN600 Marine Butterfly Valves are detailed below to help engineers make informed selection decisions.
| Parameter | Specification |
| Nominal Diameter (DN) | 50, 65, 80, 100, 125, 150, 200, 250, 300, 350, 400, 450, 500, 600 |
| Pressure Rating | PN10, PN16, Class 150 (Custom ratings available) |
| Body Material Options | Ductile Iron (Epoxy Coated), Cast Steel, Stainless Steel (CF8M/316) |
| Disc Material Options | Stainless Steel 316, Nickel-Aluminum Bronze (C95800) |
| Seat Material Options | EPDM (Standard), NBR, PTFE (for higher temp/corrosion) |
| Stem Material | Stainless Steel 316 (Standard), 17-4PH Stainless optional |
| Connection Type | Wafer, Lug, Double Flange |
| Operating Temperature | -10°C to +120°C (with EPDM seat), up to 200°C with PTFE |
| Operation Method | Lever, Worm Gear, Electric Actuator (on request) |
| Flow Characteristic | Approximately Equal Percentage |
The advantages of specifying our valves extend beyond the specifications. They translate into tangible benefits for ship owners and system integrators:
- Extended Service Life: The combination of corrosion-resistant alloys and protective coatings significantly reduces maintenance frequency and replacement costs over the vessel's lifespan.
- Enhanced System Reliability: Consistent, leak-free performance ensures seawater cooling, ballast, and firefighting systems operate as designed, preventing costly downtime.
- Operational Flexibility: The availability of different actuation methods allows for optimization based on the level of automation required, from manual local control to fully remote operation.
- Cost-Effective Installation: The lightweight wafer design reduces structural support needs and simplifies installation, lowering overall project labor and material costs.
Backed by Shanghai Zhibang Valve's commitment to quality under the ISO9001 framework and supported by an annual export value reflecting consistent global demand, these marine butterfly valves represent a reliable investment. Our established supply chain from major ports like Shanghai, Guangzhou, and Hong Kong ensures timely delivery to projects worldwide, from shipyards in Eastern Europe to fleets operating in Oceania. For your next marine seawater system project, choose a valve solution built for endurance and performance. Contact us today to discuss your specific requirements, request a detailed quotation, or arrange for product samples.
Frequently Asked Questions (FAQ)
Q1: What makes these valves specifically suitable for seawater applications?
A: These valves utilize materials like nickel-aluminum bronze and stainless steel 316, which are renowned for their high resistance to chloride-induced stress corrosion cracking and biofouling, common in seawater. The seat materials are also selected for compatibility with saline environments.
Q2: Can I get these valves with electric actuators for remote control?
A: Yes, electric actuation is a customizable option. We can provide valves fitted with electric actuators suitable for 24VDC, 110VAC, or other standard shipboard power supplies, complete with necessary control signals and feedback.
Q3: Are your valves compatible with existing ANSI flanges on my vessel?
A: Absolutely. Our valves are manufactured to standard dimensions compatible with ANSI, DIN, JIS, and other common flange standards. Please specify your required flange standard and pressure class when inquiring.
Q4: What is the typical lead time for an order of DN300 valves?
A: Lead times vary based on order quantity, material selection, and actuation requirements. Standard configurations from our inventory may ship quickly, while customized orders typically have a longer production schedule. We provide accurate lead time estimates with every quotation.
Q5: Do you offer any corrosion protection coatings on ductile iron bodies?
A: Yes, as a standard practice, our ductile iron valve bodies receive a high-quality epoxy coating, which provides an effective barrier against seawater corrosion. Additional coating systems can be discussed for specific project needs.
Q6: How do I determine the correct seat material (EPDM vs. NBR vs. PTFE) for my application?
A: The choice depends on operating temperature and media. EPDM is excellent for general seawater up to 120°C. NBR is suitable for lower temperatures and offers good oil resistance. PTFE is used for higher temperatures or more aggressive chemical services. Our technical team can assist in selection.
Q7: What kind of testing do your valves undergo before shipment?
A: Each valve undergoes rigorous factory testing, which typically includes a shell test (body strength) and a seat leak test to ensure integrity. Certificates of compliance and test reports are available upon request.
Q8: Can you supply valves according to specific marine classification society rules?
A: We can discuss requirements for classification society approvals (such as ABS, DNV, LR, etc.). Material certifications and manufacturing processes can be tailored to meet the necessary guidelines, subject to project specifications and order volume.
