As a dedicated supplier of high-performance engineering plastics, Shanghai Wenqin Plastics Co., Ltd. is proud to offer DuPont Virgin PA66 500PNC010. Established in 2020 and operating from our facility in Shanghai, we specialize in providing premium materials that meet the rigorous demands of global industrial markets. This specific grade represents the pinnacle of Nylon 66 performance, engineered by DuPont for applications where failure is not an option. We understand that our clients in sectors like automotive, electrical, and heavy machinery require materials that deliver consistent, reliable performance under stress, heat, and harsh environmental conditions. Our role is to ensure a steady supply of this authentic, traceable virgin resin, directly supporting your manufacturing excellence and product integrity.
DuPont Virgin PA66 500PNC010 is a high-performance polyamide 66 resin designed for precision engineering applications. Its properties make it a preferred choice for components that must withstand significant mechanical loads, elevated temperatures, and exposure to various chemicals.
Core Characteristics & Technical Advantages:
Superior Mechanical Strength: Offers an excellent balance of high tensile strength, stiffness, and impact resistance, even in challenging environments.
Enhanced Heat Resistance: Maintains its structural integrity and key mechanical properties at elevated temperatures, outperforming many standard thermoplastics.
Good Chemical Resistance: Demonstrates resilience against a wide range of oils, fuels, and solvents, making it suitable for under-hood automotive parts and industrial fluid handling systems.
Excellent Dimensional Stability: Provides low moisture absorption compared to other nylons, leading to better dimensional consistency in finished parts.
Superior Wear & Abrasion Resistance: Ideal for moving parts, gears, bearings, and guides where friction is a concern.
Consistent Processability: As a virgin material from DuPont, it ensures batch-to-batch consistency for reliable injection molding or extrusion, reducing production variances.
Typical Technical Specifications (Representative Values):
| Property | Test Method | Typical Value |
| Tensile Strength (Dry) | ISO 527 | 80 - 85 MPa |
| Flexural Modulus | ISO 178 | 3000 MPa |
| Melting Point | ISO 11357 | Approx. 260 °C |
| HDT @ 1.8 MPa | ISO 75 | > 200 °C |
| Density | ISO 1183 | 1.14 g/cm³ |
Benefits for Your Business:
Extended Product Lifespan: Components made from this material exhibit enhanced durability, reducing failure rates and maintenance needs.
Design Flexibility: Enables the production of complex, high-strength parts that might otherwise require metal, allowing for weight reduction and design innovation.
Reliable Supply Chain: Sourcing from Shanghai Wenqin Plastics provides access to authentic DuPont material with clear traceability, supported by efficient logistics from major ports like Shanghai and Ningbo.
Risk Mitigation: Using a well-known, high-grade virgin resin minimizes the risks associated with material inconsistencies, ensuring your production runs smoothly.
Frequently Asked Questions (FAQ):
Q: Is this truly virgin DuPont PA66, or a recycled/regrind material?
A: We supply 100% virgin DuPont PA66 500PNC010. It is sourced directly to ensure original performance properties and full traceability, which is critical for demanding applications.Q: What are the most suitable processing methods for this grade?
A: This grade is primarily designed for injection molding and extrusion processes. Optimal processing parameters should be developed based on your specific part geometry and equipment.Q: How does PA66 500PNC010 perform in high-temperature environments?
A: It offers a high Heat Deflection Temperature (HDT), allowing it to perform reliably in continuous use at elevated temperatures, a key requirement for under-hood automotive or electrical components.Q: Does the material require pre-drying before processing?
A: Yes, like most polyamides, PA66 is hygroscopic. We recommend thorough drying according to standard protocols (e.g., 80-90°C for 3-4 hours in a desiccant dryer) to prevent issues like splay or reduced mechanical properties.Q: Can you provide material certifications or test reports?
A> As a company holding multiple management system certifications including ISO9001, we can provide relevant documentation such as material data sheets and certificates of analysis upon request to support your quality assurance processes.Q: What industries commonly use this specific PA66 grade?
A: Its primary applications are in automotive (sensors, connectors, under-hood components), electrical & electronics (coil formers, switches), and industrial machinery (gears, bearings, wear pads) where high mechanical and thermal performance is required.Q: What are the available packaging options?
A: The material is typically supplied in 25kg standard poly bags on pallets. Custom packaging can be discussed based on order volume and specific logistics requirements.Q: What is the lead time for orders?
A: Lead times depend on order quantity and current stock levels. We maintain strategic inventory and leverage our Shanghai location for efficient shipment, aiming to provide reliable and timely delivery to our global clientele across North America, Europe, Asia, and other regions.
Choosing Shanghai Wenqin Plastics as your supplier means partnering with a certified and committed provider. Our adherence to stringent quality management systems, including ISO9001 and IATF 16949 (implied by TS16969), underscores our dedication to consistency and reliability. With a focused team of 11-50 professionals, we ensure personalized service and technical support for your projects. Our extensive reach across North America, South America, Europe, Asia, Africa, and Oceania demonstrates our capability to serve a global industrial base efficiently from our strategic port locations. When your application demands the proven performance of genuine DuPont Virgin PA66 500PNC010, contact us to discuss how this high-performance material can enhance your product's reliability and durability.
