Dual Door LV Power Distribution Cabinet for Industrial Plant Electrical Systems
Product Spotlights
Designed for industrial safety and efficiency, this dual-door LV distribution cabinet features segregated compartments for safer maintenance access. Built with robust materials and customizable internal layouts, it supports complex power distribution needs while ensuring thermal management and compliance with relevant electrical standards. Ideal for enhancing operational continuity in demanding plant environments.
US$ 190 - 4600
MOQ: 10 Units
Key Specifications
Get Latest Price
Application:
Other, Industrial plant electrical systems
Door Configuration:
Dual door design
Rated Voltage:
Up to 690V AC
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Customizable Low Voltage Power Cabinet With Dual Doors, IP54 & Standard Compliant DesignUS$ 190 - 4600MOQ: 10 Units -
Customizable Dual Door Low Voltage Cabinet With 1-Year Warranty & Technical SupportUS$ 190 - 4600MOQ: 10 Units
-
IP54 Rated Low Voltage Distribution Cabinet With Dual Doors & Customizable LayoutUS$ 190 - 4600MOQ: 10 Units
-
Industrial ATS Panel With Digital Display and Remote MonitoringUS$ 100 - 1000MOQ: 10 Units
-
Built-in ATS Automatic Transfer Switch for 220V/400V SystemsUS$ 100 - 1000MOQ: 10 Units
Application
Other, Industrial plant electrical systems
Door Configuration
Dual door design
Rated Voltage
Up to 690V AC
Enclosure Material
Cold rolled steel or stainless steel
Protection Rating
IP ratings available (e.g., IP31, IP54)
Mounting Type
Floor standing, wall mounted optional
Internal Configuration
Customizable busbar and component layout
Color
Standard RAL colors (e.g., RAL 7035)
Standards Compliance
IEC 61439 series standards
Brand
Jinhua Dika
As a leading manufacturer, Jinhua Dika Electrical Equipment Co., Ltd. specializes in providing robust and reliable electrical solutions for demanding industrial environments. Our Dual Door LV Power Distribution Cabinet is engineered to be the central nervous system of your industrial plant's electrical network, offering superior organization, safety, and control. With over a decade of experience and a commitment to quality certified by multiple international standards, we design this cabinet to withstand the rigors of continuous operation while ensuring easy access for maintenance and monitoring. This product represents our dedication to delivering power distribution solutions that enhance operational efficiency and safety for our global clientele across diverse markets.
The cabinet's core value lies in its intelligent dual-door design, which segregates functional zones to optimize both safety and accessibility. The robust construction and flexible internal configuration make it an ideal choice for managing complex power distribution in factories, manufacturing plants, and processing facilities.
Key Features and Technical Advantages:
- Enhanced Safety and Accessibility: The dual-door design provides a clear separation between the incoming power/breaker section and the outgoing distribution section. This allows authorized personnel to access feeder circuits for routine checks or isolation without exposing the main busbars or primary breakers, significantly improving operational safety.
- Robust Construction for Industrial Duty: Fabricated from high-quality cold-rolled steel with a powder-coated finish, the enclosure offers excellent mechanical strength and corrosion resistance. Options for stainless steel are available for highly corrosive environments, ensuring long-term durability.
- Optimized Thermal Management: Strategically placed ventilation louvers, coupled with options for internal fan kits or air conditioning units, ensure effective heat dissipation from installed components like circuit breakers and contactors, preventing overheating and extending equipment lifespan.
- Fully Customizable Internal Layout: We understand that every plant has unique requirements. The internal mounting frame is designed with a modular, fully glanded structure, allowing for flexible arrangement of busbars, cable trays, circuit breakers (MCB, MCCB), contactors, relays, and metering devices as per your specific single-line diagram.
- Comprehensive Wiring and Labeling: The cabinet includes ample space for neat and organized cable routing with dedicated entry points. All components and wires are clearly labeled according to the provided schematic, simplifying installation, troubleshooting, and future modifications.
Technical Specifications Overview:
| Parameter | Specification |
| Rated Operational Voltage (Ue) | Up to 690V AC, 50/60Hz |
| Rated Insulation Voltage (Ui) | 1000V AC |
| Enclosure Protection Degree | Standard IP31, IP54 available on request |
| Busbar System | Copper, tin-plated; Current rating customizable (e.g., 630A, 800A, 1250A) |
| Door Material & Locking | Steel, with 3-point locking system and removable key |
| Internal Separation | Form 3b or Form 4 per IEC 61439-2 (separation between functional units) |
Benefits for Your Plant Operations:
- Minimized Downtime: The segregated design allows maintenance on one section while other circuits remain powered, supporting critical process continuity.
- Improved Personnel Safety: Reduced risk of accidental contact with live main busbars during routine operations enhances workplace safety compliance.
- Scalable and Future-Proof: The modular design accommodates additional breakers or components as your plant expands, protecting your initial investment.
- Efficient Fault Management: Clear compartmentalization makes it faster and easier to identify and isolate electrical faults, speeding up restoration times.
Frequently Asked Questions (FAQ):
-
Q: What is the main advantage of a dual-door design over a single-door cabinet?
A: The primary advantage is enhanced operational safety and convenience. It allows separate, secure access to the distribution circuits without exposing the main power intake section, enabling safer live working conditions for maintenance on feeder circuits. -
Q: Can this cabinet be customized to include specific brands of components like Siemens or Schneider breakers?
A: Yes. As a manufacturer, we offer full customization. You can specify the preferred brands for circuit breakers, meters, contactors, and other internal components, and we will integrate them into the design and wiring. -
Q: What does 'LV' stand for in the product title, and what voltage range does it cover?
A: 'LV' stands for Low Voltage, which typically covers systems up to 1000V AC. Our cabinets are commonly designed for standard industrial voltages like 400V/415V or 690V AC, 3-phase systems. -
Q: Do you provide the complete electrical schematic and as-built drawings?
A: Absolutely. We provide detailed single-line diagrams (SLDs), general arrangement drawings, and bill of materials (BOM) for approval before manufacturing. Final as-built documentation is supplied upon completion. -
Q: How is the cabinet tested before shipment?
A> Each cabinet undergoes rigorous factory acceptance tests, which may include dielectric strength tests, continuity checks of protective circuits, functional operation of all devices, and verification of insulation resistance, ensuring it meets the specified performance criteria. -
Q: What is the typical lead time for a custom-configured cabinet?
A: Lead time depends on the complexity and component availability. Standard configurations may take 4-6 weeks, while highly customized projects may require 8-12 weeks. We provide a firm timeline upon finalizing the technical specification. -
Q: Can you assist with installation and commissioning guidance?
A: We provide comprehensive installation manuals and wiring diagrams. Remote technical support is available. On-site supervision or commissioning services can be arranged as an optional extra.
