Help CenterPA66 A3WUNQ601 Modified Polyamide Pellets Weather Resistant Raw Stock
Product Spotlights
Related Products
-
PA66 Granules A3WG5 for Electrical Components With Low Warpage and High FlowNegotiableMOQ: 1 Kilogram -
PA66 Granules A60G1 for Precision Engineering Parts With High StiffnessNegotiableMOQ: 1 Kilogram
-
PA66 Granules A3EG6BK for Injection Molding With 30% Glass Fiber ReinforcementNegotiableMOQ: 1 Kilogram
-
PA66 Granules A3HG7 for Gears and Bearings With Enhanced Heat StabilizationNegotiableMOQ: 1 Kilogram
-
PA66 Granules A3WUNQ601 for Under-the-Hood Automotive ApplicationsNegotiableMOQ: 1 Kilogram
As a specialized manufacturer of high-performance engineering plastics, Shanghai Wenqin Plastics is proud to introduce our PA66 A3WUNQ601 Modified Polyamide Pellets. This weather-resistant raw stock is engineered to meet the rigorous demands of applications exposed to harsh environmental conditions, combining the inherent strength of PA66 with superior resistance to UV degradation and weathering. We understand that material failure due to environmental stress can lead to significant costs for our B2B clients, which is why we have developed this specialized grade to provide long-term reliability and performance.
Our PA66 A3WUNQ601 is formulated to deliver exceptional durability. The modification process enhances the polymer's ability to withstand prolonged exposure to sunlight, rain, and temperature fluctuations without significant loss of mechanical properties or aesthetic appearance. This makes it an ideal choice for parts that must perform reliably outdoors for extended periods.
Superior Weathering Resistance: Specially modified to resist UV radiation, moisture absorption, and thermal cycling, preventing premature cracking, fading, or embrittlement.
Maintained Mechanical Strength: Retains the high tensile strength, stiffness, and impact resistance characteristic of standard PA66, even after long-term environmental exposure.
Excellent Processability: The pellet form ensures consistent feeding and melting behavior in standard injection molding and extrusion equipment, facilitating efficient production.
Design Flexibility: Available in natural and customizable colors, allowing for aesthetic integration into final products without requiring painting in some cases.
Broad Application Suitability: Specifically developed for components that face the elements, offering a robust material solution for challenging use cases.
The technical specifications of PA66 A3WUNQ601 are designed to provide engineers and purchasers with reliable performance data. Below is a summary of key properties:
| Property | Typical Value | Test Standard |
| Tensile Strength | 80 - 85 MPa | ISO 527 |
| Flexural Modulus | 3000 - 3200 MPa | ISO 178 |
| Izod Impact Strength (Notched) | 5 - 7 kJ/m² | ISO 180 |
| Melting Point | Approx. 260 °C | ISO 11357 |
| Moisture Absorption (Equilibrium 23°C/50% RH) | ~2.5% | ISO 62 |
Choosing our weather-resistant PA66 translates into tangible benefits for your business:
Extended Product Lifespan: Components made from A3WUNQ601 demonstrate reduced degradation, leading to fewer warranty claims and enhanced customer satisfaction.
Reduced Total Cost of Ownership: By delaying the need for replacement parts, this material contributes to lower long-term maintenance costs for the end-user.
Supply Chain Reliability: Sourced from our dedicated manufacturing facility, we ensure consistent quality and stable supply to support your production schedules.
Technical Support: Our team can provide guidance on processing parameters and design considerations to optimize the performance of this material in your specific application.
Shanghai Wenqin Plastics operates a focused manufacturing facility and leverages robust management systems, including ISO 9001 for quality and ISO 14000 for environmental management. Our products reach a global clientele through major ports like Shanghai and Ningbo, serving diverse markets from North America and Europe to Southeast Asia and Africa. This global reach is a testament to the consistent quality and performance of our engineering plastic compounds. We invite you to experience the difference that a purpose-built, weather-resistant polyamide can make for your outdoor or harsh-environment applications. Contact us today to request samples, discuss your specifications, or get a competitive quote.
Frequently Asked Questions (FAQ)
Q: How does the 'weather resistant' modification in A3WUNQ601 differ from standard PA66?
A: The modification typically involves adding stabilizers such as UV absorbers and antioxidants to the polymer matrix. These additives significantly slow down the molecular degradation caused by sunlight (UV) and oxygen, which are primary factors in color fading, surface chalking, and loss of mechanical properties in standard plastics outdoors.Q: Is this material suitable for continuous outdoor exposure in all climates?
A: PA66 A3WUNQ601 is designed for enhanced performance in outdoor conditions. However, the actual lifespan will depend on factors like geographic location (UV index), specific environmental pollutants, and part design. It performs well in a wide range of climates but for extreme conditions, further testing or specific grade consultation is recommended.Q: Can I use my existing injection molding machine settings for standard PA66 with this grade?
A: Generally, yes. The processing window is similar to standard PA66. However, due to the modifiers, slight adjustments to temperature profiles (especially in the nozzle and front zones) and holding pressure might be beneficial. We provide recommended processing guidelines with the material datasheet.Q: Does the weather-resistant modification affect the material's color or clarity?
A: The natural color of the modified pellets may have a slight tint compared to unmodified natural PA66. For applications requiring specific colors, we offer customizable coloring. The material is inherently opaque.Q: What is the typical lead time for an order, and what are the packaging options?
A: Lead times vary based on order quantity and current production schedule. Standard packaging is 25 kg multi-layer paper bags with inner lining. Larger bulk packaging options may be available upon request for substantial orders.Q: Are there any special storage requirements for this material?
A: Like all polyamides, it is hygroscopic. Although modified, it should be stored in a cool, dry place in its original sealed packaging until use. For optimal processing, pre-drying is recommended according to standard PA66 procedures to prevent surface defects.Q: Can this grade be combined with glass fiber or other reinforcements?
A: The A3WUNQ601 is a modified base resin. We offer other grades that combine weather resistance with reinforcements like glass fiber. Please inquire about specific reinforced and weather-resistant compounds if your application requires higher stiffness or strength.Q: Do you provide material certification or test reports?
A: Yes, we can provide Certificates of Analysis (CoA) with key property data for each batch. Additional specific test reports may be available upon request.
