As a specialized manufacturer of high-performance engineering plastics, Shanghai Wenqin Plastics Co., Ltd. is proud to offer our premium PA66 A3EG6 Nylon Resin with 30% Glass Fiber Reinforcement. Designed for demanding applications, this material provides an exceptional balance of mechanical strength, dimensional stability, and thermal performance, making it a reliable choice for manufacturers of critical engineering components. Our commitment to quality control, backed by a robust management system, ensures that every batch of our PA66 GF30 resin meets the stringent requirements of the global engineering industry, helping you build products that last.
This glass fiber reinforced PA66 compound is engineered to overcome the limitations of standard nylon, delivering enhanced properties that are crucial for structural and load-bearing parts. The integration of 30% glass fibers significantly improves tensile strength, flexural modulus, and resistance to creep under load, while also reducing the coefficient of thermal expansion. This results in components that maintain their shape and performance across a wide temperature range. Furthermore, the material exhibits good chemical resistance to many oils, fuels, and solvents, ensuring longevity in harsh operating environments. Its excellent flow characteristics during injection molding allow for the production of complex, thin-walled parts with high precision and consistent quality.
The technical specifications of our PA66 A3EG6 resin are tailored for performance. Below is a summary of key properties:
| Property | Typical Value | Test Standard |
| Tensile Strength | 160 - 180 MPa | ISO 527 |
| Flexural Modulus | 8000 - 9500 MPa | ISO 178 |
| Heat Deflection Temperature (1.8 MPa) | 250 - 255 °C | ISO 75-1/-2 |
| Density | 1.35 g/cm³ | ISO 1183 |
| Mold Shrinkage (parallel) | 0.3 - 0.6 % | - |
Choosing our PA66 GF30 material offers distinct advantages for your production and end-products:
Enhanced Durability: Parts exhibit superior resistance to wear, fatigue, and impact, leading to longer service life and reduced maintenance costs.
Dimensional Precision: Low and predictable mold shrinkage ensures tight tolerances and excellent part-to-part consistency, which is vital for assembly and function.
Weight Reduction: As a high-strength plastic, it can often replace metals, contributing to overall weight savings in automotive, electrical, and industrial equipment without sacrificing performance.
Design Freedom: The material's processability allows for the integration of multiple features into a single, complex molding, simplifying assembly and reducing part count.
Shanghai Wenqin Plastics operates with a firm commitment to international standards. Our production is guided by a comprehensive quality management system. This foundation, combined with our strategic location in Shanghai with access to major ports like Shanghai and Ningbo, enables us to reliably serve a diverse global clientele across North America, Europe, Asia, and beyond. We understand the critical nature of engineering plastics and provide material solutions you can trust for your most challenging applications. Contact us today to discuss how our PA66 A3EG6 resin can enhance your component manufacturing.
Frequently Asked Questions (FAQ)
Q1: What is the main difference between standard PA66 and this 30% glass fiber reinforced grade?
A1: The primary difference lies in the significantly enhanced mechanical properties. The 30% glass fiber reinforcement increases tensile strength, stiffness (flexural modulus), and heat resistance while reducing thermal expansion and improving dimensional stability compared to unfilled PA66.
Q2: Is this material suitable for outdoor or UV-exposed applications?
A2: Standard PA66 GF30 has limited inherent UV resistance. For prolonged outdoor use, we recommend inquiring about stabilized or UV-resistant versions, which can be customized upon request to include additives for improved weatherability.
Q3: What are the typical injection molding parameters for this resin?
A3: Recommended melt temperature ranges from 280°C to 300°C, with a mold temperature of 80°C to 100°C. Due to the glass fiber content, it is advisable to use hardened steel molds and proper screw design to account for increased abrasiveness.
Q4: Can you supply this material in colors other than natural?
A4: Yes. While the standard supply is in natural color (off-white), we can provide custom color compounding. Please specify your color requirements, and we can offer samples for approval.
Q5: How does the moisture absorption of this material affect processing and part performance?
A5: Like all nylon materials, PA66 is hygroscopic. It is crucial to dry the resin thoroughly before processing (e.g., 4-6 hours at 80-90°C) to prevent surface defects and ensure optimal mechanical properties. Finished parts will also absorb moisture from the air, which can slightly increase toughness and impact strength.
Q6: What industries commonly use this type of reinforced nylon?
A6: This material is widely used in automotive (under-hood components, connectors), electrical and electronics (housings, insulators), industrial machinery (gears, bearings, rollers), and consumer appliances where high strength and heat resistance are required.
Q7: Do you provide technical data sheets and material samples for testing?
A7: Absolutely. We provide comprehensive technical data sheets detailing all physical, thermal, and mechanical properties. We also offer sample quantities for your in-house testing and mold trials to validate performance for your specific application.
