Ⅰ. Description
The water immersion retort features unique liquid flow switching technology for uniform internal temperature. Preheated hot water from a tank enables fast heating and sterilization, with hot water recycled post-process for energy efficiency.
Ⅱ. Advantages
Uniform water flow: Flow direction switching ensures vertical/horizontal uniformity, delivering water to each product tray’s center for dead-end-free sterilization.
HTST treatment: Preheated hot water enables high-temperature short-time sterilization.
Deformable container compatibility: Water buoyancy protects containers under high temperatures.
Large/high-viscosity food suitability: Rotation ensures even heating of large canned/high-viscosity foods, with water buoyancy safeguarding packaging during rotation.
Ⅲ. Working Principle
Load product baskets, close the door (locked via triple safety interlocks for full-process mechanical security). The PLC controls automatic sterilization per preset recipes:
Inject preheated hot water into the retort; circulate via high-flow pumps and optimized pipes.
Steam injection heats water for sterilization; flow switching ensures uniform heat distribution.
Programmed pressure control (via automatic air injection/discharge) adapts to 3-piece cans, 2-piece cans, flexible/plastic packages, etc.
Optional hot water recovery during cooling saves energy.
An alarm signals completion; unload for the next batch.
Temperature uniformity: ±0.5℃; pressure control precision: 0.05 Bar.
➦ Timely service from a real manufacturer
➦ Years of experience in food sterilization industry
➦ Free sterilization solution support
| Mod el | Diameter(mm) | Body Length(mm) | Volume(m³) | Length(mm) | Width(mm) | Height(mm) | Basket size(LWHmm) | Design temperature(℃) | Test Pressure(bar) | Design pressure(bar) |
|---|---|---|---|---|---|---|---|---|---|---|
| J-1002 | 1000 | 1600 | 1.49 | 3200 | 1700 | 2900 | 758×650×621 | 147 | 4.4 | 3.5 |
| J-1003 | 1000 | 2400 | 2.12 | 4000 | 1700 | 2900 | 758×650×621 | 147 | 4.4 | 3.5 |
| J-1203 | 1200 | 2700 | 3.45 | 4500 | 2100 | 3350 | 860×800×775 | 147 | 4.4 | 3.5 |
| J-1204 | 1200 | 3600 | 4.47 | 5400 | 2100 | 3350 | 860×800×775 | 147 | 4.4 | 3.5 |
| J-1205 | 1200 | 4500 | 5.49 | 6300 | 2100 | 3350 | 860×800×775 | 147 | 4.4 | 3.5 |
| J-1403 | 1400 | 3000 | 5.24 | 5200 | 2500 | 3900 | 920×920×915 | 147 | 4.4 | 3.5 |
| J-1404 | 1400 | 3900 | 6.62 | 6050 | 2500 | 3900 | 920×920×915 | 147 | 4.4 | 3.5 |
| J-1504 | 1500 | 4250 | 8.26 | 6650 | 2600 | 4450 | 1000×1000×975 | 147 | 4.4 | 3.5 |
| J-1505 | 1500 | 5300 | 10.12 | 7700 | 2600 | 4450 | 1000×1000×975 | 147 | 4.4 | 3.5 |
The listed price serves as a deposit. Before placing an order, please be sure to contact us to discuss your detailed requirements and obtain an accurate quote, thereby avoiding any unnecessary complications.
