As a specialized manufacturer of electrical equipment, Jinhua Dika Electrical Equipment Co., Ltd. proudly presents our IP65 Protected Electrical Control Panel with MV/HV Switchgear and a 400A rating. Engineered for demanding industrial environments, this panel integrates robust protection with high-performance switchgear to ensure safe and reliable power distribution. Our commitment to the ISO9001 quality management system guarantees a product built to meet rigorous standards, offering our global clients in North America, Europe, Asia, and beyond a dependable solution for their critical electrical infrastructure.
This control panel is designed to be the nerve center for medium and high-voltage power systems. Its core value lies in providing a secure, organized, and protected enclosure for essential switchgear components, safeguarding them from environmental hazards while facilitating efficient operation and maintenance.
Key Features and Technical Specifications:
- IP65 Protection: The enclosure offers complete protection against dust ingress and can withstand water jets from any direction. This makes it suitable for outdoor installations, wash-down areas, or industrial settings with significant particulate or moisture exposure.
- High-Current Capacity: With a 400A rating, the panel is capable of handling substantial power loads, making it ideal for primary distribution points, substation feeder circuits, or large industrial machinery power supplies.
- MV/HV Switchgear Integration: The panel is designed to house medium voltage (typically 1kV to 35kV) or high voltage switchgear components. The internal layout is optimized for safety clearances, cable routing, and component accessibility.
- Robust Construction: The enclosure is typically constructed from high-grade steel, providing mechanical strength and durability. Finishes are applied to resist corrosion, ensuring long service life even in harsh conditions.
- Customizable Design: While we offer standard configurations, the panel's internal layout, dimensions, door arrangements, and accessory fittings (like lighting, heaters, or extra terminals) can be customized to match specific project requirements and switchgear vendor components.
- Enhanced Safety & Accessibility: Features include secure locking mechanisms, clear viewing windows for indicators, well-organized cable entry points with gland plates, and ergonomic access to internal components for testing and maintenance.
Advantages and Client Benefits:
- System Reliability: By protecting sensitive switchgear from environmental contaminants, the panel minimizes failure risks, leading to higher system uptime and reduced maintenance costs.
- Operational Safety: The sealed enclosure prevents accidental contact with live parts, enhancing personnel safety. Proper internal organization reduces the risk of errors during operation.
- Project Flexibility: Our ability to customize the panel allows it to integrate seamlessly into your existing electrical layout, saving on installation time and adaptation costs.
- Global Compliance: Manufactured under ISO9001, our processes ensure consistent quality, a crucial factor for international projects across our main markets from Eastern Europe to Oceania.
- Long-Term Durability: The robust build and protective rating ensure the panel remains functional for years, providing a solid return on investment for your power distribution assets.
Typical Technical Parameters (Standard Configuration Example):
| Parameter | Specification / Range |
| Protection Standard (Ingress) | IP65 (IEC 60529) |
| Rated Current (Busbar/Feeder) | 400 Amperes |
| Application Voltage Level | MV (e.g., 10kV, 15kV) / HV (customizable) |
| Enclosure Material (Typical) | Powder-coated steel |
| Internal Space Configuration | Designed for circuit breakers, relays, meters, busbars |
| Door Type | Single or double door with lock |
| Cable Entry Options | Bottom or side entry with gland plates |
| Mounting | Wall-mounted or floor-standing frame |
| Optional Features | Internal lighting, ventilation fans, heating elements, extra terminal blocks |
Trust and Commitment from Jinhua Dika:
Backed by our annual export value of US$1-1.5 Million and a dedicated team of 11-50 professionals, we have successfully supplied reliable electrical solutions to diverse markets worldwide. Our panels are shipped from major ports like Shanghai, Tianjin, Guangzhou, and Ningbo, ensuring efficient logistics. Choosing our IP65 Protected Control Panel means partnering with an established manufacturer that understands the needs of industrial power systems. We invite you to leverage our expertise and quality-focused production to secure your electrical distribution points. Contact us to discuss your specific requirements for a customized, robust, and safe MV/HV control panel solution.
Frequently Asked Questions (FAQ):
Q1: What does the IP65 rating specifically mean for this panel?
A: IP65 indicates two levels of protection: "6" means the enclosure is dust-tight—no dust ingress; "5" means it can protect against water jets from any direction. It is suitable for outdoor use or areas with periodic water wash-downs.
Q2: Can this panel be used for both Medium Voltage (MV) and High Voltage (HV) applications?
A: Yes, the design accommodates switchgear for both MV (common range up to 35kV) and HV systems. The internal layout, insulation clearances, and busbar specifications will be customized based on your specific voltage level and switchgear components.
Q3: Is the 400A rating for the entire panel or per feeder?
A: The 400A rating typically refers to the capacity of the main busbar system within the panel. Individual feeder circuits or breaker ratings can be specified lower, based on your distribution design. The panel structure is designed to safely handle the 400A main current.
Q4: What kind of switchgear components can be installed inside?
A> The panel can house components like vacuum or air circuit breakers, isolators, protection relays (overcurrent, earth fault), metering units, control switches, and indication lamps. The layout is planned according to your provided switchgear specifications.
Q5: How are the dimensions of the panel determined?
A: Dimensions are not fixed. They are calculated based on the number, size, and arrangement of the switchgear devices you need to install, along with required safety clearances and cable routing space. We provide custom sizing as part of the design process.
Q6: Does the panel come with any internal wiring or is it just an empty enclosure?
A: We can supply the panel as a fully assembled unit including internal busbars, wired auxiliary circuits (for relays, lighting), and terminal blocks, or as an enclosure ready for you to install your own switchgear and wiring. This is customizable upon request.
Q7: What certifications does the product have?
A> Our manufacturing process is certified under the ISO9001 Quality Management System, ensuring consistent quality control. The panel itself can be built to comply with relevant international electrical standards (like IEC) based on project requirements, but specific product certifications (e.g., for switchgear) depend on the installed components.
Q8: What is the typical lead time for a customized order?
A: Lead time varies based on the complexity of customization and current production schedule. Generally, for a standard-design panel with specific dimensions, it can range from 4 to 8 weeks. We provide a precise timeline after finalizing the design specifications.
