As a dedicated manufacturer with over a decade of experience in electrical equipment, Jinhua Dika Electrical Equipment Co., Ltd. proudly presents our robust Industrial Electrical Panel Board with MV/HV Switchgear. Engineered for demanding environments, this panel board is designed to provide reliable, safe, and efficient power distribution and control for industrial facilities worldwide. Our commitment to the ISO9001 quality management system ensures every unit meets stringent standards for performance and durability, making it a trusted component in critical power infrastructure. With an annual export value reflecting our global reach, we understand the diverse needs of markets from North America to Southeast Asia and deliver solutions that power productivity and safety.
This industrial panel board integrates medium and high voltage switchgear components into a cohesive, organized assembly. It serves as the central nervous system for electrical distribution, managing power flows up to 400A with precision and protection. Key features and benefits include:
- Robust Construction & Safety: The enclosure is typically fabricated from high-grade cold-rolled steel or corrosion-resistant stainless steel, offering superior mechanical strength. Designed with operator safety as a priority, it features secure interlocking systems, clear labeling, and insulated busbars to prevent accidental contact.
- High-Capacity Performance: With a capacity of up to 400A, this board is capable of handling significant electrical loads found in manufacturing plants, data centers, utility substations, and large commercial complexes.
- Flexible Configuration: The panel board is highly customizable. It can be configured with various MV/HV switchgear components such as circuit breakers (vacuum, SF6), disconnect switches, protection relays, metering devices, and control modules to suit specific project requirements.
- Enhanced Reliability: Built with high-quality components and rigorous assembly processes, it ensures minimal downtime and long service life. Proper segregation of compartments and effective heat dissipation contribute to stable operation.
- Simplified Maintenance & Operation: A logical layout, easy access doors, and front-operable controls allow for straightforward inspection, testing, and maintenance procedures, reducing operational costs.
The technical specifications of our Industrial Electrical Panel Board are detailed below. Please note that specific parameters can be tailored based on client needs.
| Parameter | Specification / Description |
|---|---|
| Rated Operational Voltage (Ue) | Typically 3.6kV, 7.2kV, 12kV, 24kV, 36kV (MV/HV ranges) |
| Rated Current (In) | Up to 400 Amperes |
| Short-Circuit Withstanding Capacity (Icw) | Customizable (e.g., 25kA, 31.5kA, 40kA for 1s or 3s) |
| Enclosure Protection (IP Rating) | Standard IP20 for indoor use; IP54, IP65 available for harsh/dusty environments |
| Dimensions (H x W x D) | Fully customizable. Common sizes range from 2200mm x 800mm x 1500mm. |
| Busbar Material | Electro-tinned copper or aluminum, with insulation shrouds |
| Operating Ambient Temperature | -5°C to +40°C (Extended range available upon request) |
| Standards Compliance | Design conforms to IEC 62271, ANSI, or other international standards as required |
Choosing a Jinhua Dika panel board means partnering with a manufacturer that has a proven track record. Our products are shipped from major ports like Shanghai, Tianjin, Guangzhou, and Ningbo, ensuring efficient logistics to your location. With a dedicated team of 11-50 skilled professionals, we maintain control over the entire manufacturing process, from design to final testing. Our presence in diverse markets from Eastern Europe to Oceania demonstrates our product's adaptability and reliability across different grid standards and climatic conditions. This panel board is not just an enclosure; it's a comprehensive, safety-focused power management solution built to support your industrial operations for years to come. We encourage you to contact us with your specific project requirements for a detailed quotation and technical consultation.
Frequently Asked Questions (FAQ)
Q1: What is the primary difference between MV and HV switchgear in this panel board?
A1: Medium Voltage (MV) typically refers to a range from 1kV to 36kV, while High Voltage (HV) generally starts above 36kV. Our panel boards are designed to accommodate components within common industrial MV ranges (e.g., 3.3kV-36kV) and can be engineered for higher voltages based on specific project specifications and component selection.
Q2: Can this panel board be customized for my specific factory layout and electrical load requirements?
A2: Absolutely. Customization is a core strength. We can modify dimensions, layout, busbar rating, component brands (like ABB, Siemens, Schneider, or others), protection schemes, and communication interfaces to integrate seamlessly with your existing infrastructure and meet your precise load profile.
Q3: What safety features are incorporated to protect personnel?
A3: Multiple safety features are standard, including but not limited to: mechanical or electrical interlocks to prevent access to live parts, earthing switches for safe maintenance, viewing windows for status checking without opening doors, insulated busbars, and clear warning labels. The enclosure itself provides a defined degree of protection (IP rating) against contact and environmental ingress.
Q4: What is the typical lead time for a standard and a customized unit?
A4: Lead times vary. A standard configuration might be delivered in 4-6 weeks. For fully customized solutions involving specific switchgear and design approval, the lead time can range from 8 to 12 weeks, depending on complexity. We provide a clear timeline upon project confirmation.
Q5: Do you provide installation guidance or after-sales support?
A5: Yes, we provide detailed installation manuals, electrical diagrams, and general guidance. While on-site installation by our team can be arranged for an additional cost, our documentation is comprehensive. We also offer after-sales technical support via email or video call to assist with commissioning and troubleshooting.
Q6: Which international standards do your panel boards comply with?
A6: Our designs are based on widely recognized international standards such as the IEC 62271 series for HV switchgear and controlgear. We can also design to meet specific regional standards like ANSI in North America, upon request. Compliance with local grid codes should be verified during the design phase.
Q7: What is the warranty period for your Industrial Electrical Panel Boards?
A7: We offer a standard warranty period of 12 months from the date of shipment against defects in materials and workmanship. Extended warranty options may be available for discussion.
Q8: How do you ensure quality control during manufacturing?
A8: Our ISO9001 certification underpins our quality management system. Every production stage involves checks: from incoming component inspection, in-process assembly verification, to final comprehensive testing including insulation resistance, HV withstand, mechanical operation, and functional tests of all protective devices.
