Help CenterCRGO Silicon Steel Strip 30Q130 Width 1000mm C6 Coating for Electromagnetic Equipment
Product Spotlights
Related Products
-
Hi-B Grain Oriented Electrical Steel Sheet 0.18mm High Induction Core Material for TransformersUS$ 1.45 - 4.25MOQ: 100 Kilograms -
GB/T 2521 CRGO Steel Coil 23Q085 Slitted Width Available for Transformer Lamination ProcessingUS$ 1.45 - 4.25MOQ: 100 Kilograms
-
M5 Grain Oriented Silicon Steel 0.35mm Electrical Core Material for Reactor ManufacturingUS$ 1.45 - 4.25MOQ: 100 Kilograms
-
ASTM IEC Certified CRGO Electrical Steel 27Q120 for Power Distribution Transformer AssembliesUS$ 1.45 - 4.25MOQ: 100 Kilograms
-
Grain Oriented Electrical Steel Coil 23Q110 0.23mm With Insulation Coating for Core StackingUS$ 1.45 - 4.25MOQ: 100 Kilograms
High-Efficiency Core Material for Electromagnetic Equipment
This 30Q130 CRGO silicon steel strip is designed for electromagnetic equipment and precision magnetic components. The C6 coating provides excellent insulation between laminations, reducing eddy current losses and improving operational efficiency. Its high magnetic permeability and low core loss make it suitable for motors, reactors, transformers, and other electrical applications requiring stable magnetic performance.
Key Specifications (Grain-Oriented Silicon Steel Coil)
Parameter |
Specification / Range |
Remarks |
Standards |
ASTM A876, IEC 60404-8-4, GB/T 2521 |
Others on request |
Grades |
23Q110, 27Q120, 30Q130, 35Q145 |
High-permeability available |
Thickness |
0.18 mm – 0.35 mm |
– |
Width |
600 mm – 1250 mm |
Slit edge available |
Core Loss P1.7 (50Hz) |
0.8 – 1.2 W/kg |
– |
Magnetic Induction B8 |
≥1.80 – 1.88 T |
– |
Coating |
C-5 (T1) / C-6 (T2) insulation coating |
– |
Density |
7.65 g/cm³ |
– |
Testing |
Epstein frame, tension, coating continuity |
Mill cert provided |
Packaging |
Rust-proof paper + steel strapping + wooden pallet |
Seaworthy, ISPM 15 |
Q1：Do you offer sample orders？
A：Yes, samples are available for quality evaluation. Sample cost is charged but refundable upon bulk order.
Q2：What is your MOQ？
A：Our standard MOQ is 100 kg per specification. For common grades and standard sizes, we accept small batch orders. Mixed orders for different products are also welcome.
Q3：Can you provide custom sizes？
A：Yes, we can produce any length, width, thickness, or diameter based on your drawings. Cutting, slitting, and other processing services are available with tolerance as required.
Q4：What certifications do you provide？
A：Each shipment comes with EN 10204 3.1 mill test certificate (MTC). Third-party inspection reports (SGS/BV/TÜV) can be arranged upon request.
Q5：What is your lead time？
A：7–15 working days for stock items. 20–30 days for custom orders, depending on quantity and specification.
Q6：What surface treatments are available？
A：Various surface treatments are available upon request, including pickled, polished, coated, oiled, or as required.
Q7：What payment terms do you accept？
A：T/T (30% deposit + 70% against BL copy), L/C at sight, Western Union, etc.
Q8：What about packaging for export？
A：Standard seaworthy packaging with waterproof protection, steel straps, corner protectors, and ISPM 15 fumigation certification. Custom packaging is available as required.
