Help Center0.35mm NOES 35W250 Coil Sheet 600–1250mm Width JIS C2552 Motor Rotor Lamination Steel
Product Spotlights
Related Products
-
Non Grain Electrical Steel 65W600 0.65mm IEC GB/T High Punching Quality Motor SheetUS$ 0.55 - 1.25MOQ: 100 Kilograms -
50W1300 NOES 0.50mm Coated Sheet for Industrial Motors, Generators, and HVAC EquipmentUS$ 0.55 - 1.25MOQ: 100 Kilograms
-
Electrical Steel 35W440 0.35mm Strip Coil ASTM A677 IEC Low Core Loss Motor MaterialUS$ 0.55 - 1.25MOQ: 100 Kilograms
-
Non-Oriented Silicon Steel 50W800 0.50mm GB/T Transformer and Appliance Core LaminationsUS$ 0.55 - 1.25MOQ: 100 Kilograms
-
0.35mm 35W250 NOES Coil With C3 Coating IEC ASTM Standards for Rotating EquipmentUS$ 0.55 - 1.25MOQ: 100 Kilograms
Precision Steel for Motor Rotors
35W250 non-oriented silicon steel offers excellent magnetic uniformity and low eddy current loss. Available in 600–1250mm widths, it is ideal for rotors, motor cores, and small electrical machinery requiring high performance and energy efficiency.
Key Specifications (Non-Oriented Silicon Steel Coil)
Parameter |
Specification / Range |
Remarks |
Standards |
ASTM A677, IEC 60404-8-4, GB/T 2521 |
Others on request |
Grades |
50W800, 50W600, 35W440, 65W1300 |
– |
Thickness |
0.35 mm – 0.65 mm |
– |
Width |
600 mm – 1250 mm |
Slit edge available |
Core Loss (50Hz) |
P1.5: 3.0 – 6.5 W/kg |
Grade dependent |
Magnetic Induction B50 |
≥1.65 – 1.75 T |
– |
Coating |
C-3 / C-5 / C-6 insulation coating |
– |
Density |
7.75 – 7.80 g/cm³ |
– |
Testing |
Epstein frame, tensile, hardness |
Mill cert provided |
Packaging |
Rust-proof paper + steel strapping + wooden pallet |
Seaworthy, ISPM 15 |
Q1：Do you offer sample orders？
A：Yes, samples are available for quality evaluation. Sample cost is charged but refundable upon bulk order.
Q2：What is your MOQ？
A：Our standard MOQ is 100 kg per specification. For common grades and standard sizes, we accept small batch orders. Mixed orders for different products are also welcome.
Q3：Can you provide custom sizes？
A：Yes, we can produce any length, width, thickness, or diameter based on your drawings. Cutting, slitting, and other processing services are available with tolerance as required.
Q4：What certifications do you provide？
A：Each shipment comes with EN 10204 3.1 mill test certificate (MTC). Third-party inspection reports (SGS/BV/TÜV) can be arranged upon request.
Q5：What is your lead time？
A：7–15 working days for stock items. 20–30 days for custom orders, depending on quantity and specification.
Q6：What surface treatments are available？
A：Various surface treatments are available upon request, including pickled, polished, coated, oiled, or as required.
Q7：What payment terms do you accept？
A：T/T (30% deposit + 70% against BL copy), L/C at sight, Western Union, etc.
Q8：What about packaging for export？
A：Standard seaworthy packaging with waterproof protection, steel straps, corner protectors, and ISPM 15 fumigation certification. Custom packaging is available as required.
