Help CenterSmall Household Appliance Panel Display Driver ic Tm1620b
Related Products
-
16 - Segment 8 - Digit Electronic Scale, Small Household Appliance Led Digital Tube Display Driver ic Tm1640US$ 0.07 - 0.07MOQ: 1000 Pieces -
Small Household Appliance Panel Display Driver ic Tm1617US$ 0.08MOQ: 1000 Pieces
-
Panel Driver ic Tm1620 for Induction Cookers and Microwave OvensUS$ 0.11MOQ: 1000 Pieces
-
Rgb 3-channel Led Guardrail Tube, Point Light Source, Led Strip Constant Current Driver ic Tm1903US$ 0.02 - 0.02MOQ: 100 Pieces
-
9-channel Constant Voltage Driver ic Tm1809 for Guardrail Tubes and Light StripsUS$ 0.07 - 0.08MOQ: 1000 Pieces
| ||||||||||||||||||||||
| ||||||||||||||||||||||
1. Overview
TM1620B is a dedicated circuit for driving and controlling LED (Light Emitting Diode Display) with a keyboard scanning interface. It is internally integrated with MCUDigital interface, data latch, LED high-voltage driver, keyboard scanning and other circuits. This product has excellent performance and reliable quality. It is mainly used for the display screen drivers of products such as VCR, VCD, DVD and home theaters. It uses the SOP20 package form.
2. Feature description
· Adopts power CMOS process
· Display mode (6 segments ×7 digits ~9 segments ×4 digits)
· Keys (6×1Bit)
· Brightness adjustment circuit (8-level adjustable duty cycle)8)
· Serial interface (CLK,STB,DIO)
· Oscillation mode: Built-inRC oscillation (450KHz+5%)
· Built-in power-on reset circuit
· Package form:SOP20
If you need a detailed specification or want to have a detailed chat, please add QQ375491012
