Product Features
1) Complete range of calibers: DN10mm to DN500mm.
2) Wide range of measurement: “Qingliu”Brand Vortex Flowmeter's range degree has always maintained an advanced level in China (). Especially when measuring small flow rates, the signal characteristics are extremely strong.
3) High temperature of the measured medium: The patented product, the extra-high temperature (H) typeVortex Flowmeter can measure the medium temperature up to400℃ or above.
4) Easy to replace the probe: Once the probe is damaged, it can be directly replaced without shutting off the flow or releasing the pressure (), truly enabling online repair(only applicable toH model).
5) Each Qingliu brand flowmeter leaving the factoryQingliu Brand Flowmeter has been individually calibrated, and no on - site parameter adjustment is required.
6) Multiple variety identifications: K, G, G0, H、B、M.
Main technical indicators
Nominal diameter (mm) 10、12.5、15、20、25、32、40、50、65、80、100、
125、150、200、250、300、350、400、450、500
Flow range Extended flow range: Liquid 40:1 Gas 25:1
Standard flow range: Liquid 10:1 Gas 8: 1
Nominal pressure (MPa) 2.5 (If >2.5, supply by agreement)
Medium temperature -40 ~ 150℃; -40 ~ 250℃; 0～300℃;-200～400℃
Case material 1Cr18Ni9Ti(Other materials are supplied by agreement)
Accuracy 1.0 grade;1.5 grade (0.5 grade is supplied by agreement)
Output signal Square wave: High level≥6V, Low level; Standard current4～20mA
Supply voltage +12VDC～24VDC
Drag coefficient Cd≤2.4
Explosion-proof mark iaⅡCT6
Environmental conditions Temperature-40～55℃, relative humidity5%～90%, atmospheric pressure86～106kPa
Applicable media Gas, liquid, steam
Explosion-proof associated equipment Zener Safety Barriers: WD97-65A/D WD97-72A/D WD97-78A/D
