PowerEdge R360 1U Rack Server With Intel Xeon 6300 Series, 128 GB DDR5 Memory, and GPU Support

PowerEdge R360 1U Rack Server With Intel Xeon 6300 Series, 128 GB DDR5 Memory, and GPU Support photo-1
PowerEdge R360 1U Rack Server With Intel Xeon 6300 Series, 128 GB DDR5 Memory, and GPU Support photo-2
PowerEdge R360 1U Rack Server With Intel Xeon 6300 Series, 128 GB DDR5 Memory, and GPU Support photo-3
PowerEdge R360 1U Rack Server With Intel Xeon 6300 Series, 128 GB DDR5 Memory, and GPU Support photo-4
PowerEdge R360 1U Rack Server With Intel Xeon 6300 Series, 128 GB DDR5 Memory, and GPU Support photo-5
Negotiable MOQ: 1 Combo (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Application:
Other
Processor Type:
Intel Xeon
Operating System:
Windows Server
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Application Other
Processor Type Intel Xeon
Operating System Windows Server
Power Supply Single PSU
Storage Capacity >1TB
Instruction System CISC
Max. CPUs 1
Number of CPu Threads Other
Supporting Memory Capacity >1TB
System Architecture X86 Server
Network Connectivity 1GbE
Server Form Factor 1U
Management Interface iDRAC
Storage Type Hybrid Storage(Combination of HDDs and SSDs)
Form Factor 1U
RAM Capacity 128GB

PowerEdge R360 Rack Server

Deliver powerful compute performance with GPU support in a single processor server designed for growing businesses.


Product Overview

The Dell PowerEdge R360 addresses evolving compute demands with an easy-to-manage rack server designed for businesses looking for affordable enterprise features.


Technical Specifications

Feature Technical Specifications
Processor One Intel® Xeon® 6300 series or one Intel® Xeon® E-2400 series processor with up to 8 cores
One Intel® Pentium® G7400/G7400T processor with 2 cores
Memory
  • 4 DDR5 DIMM slots, supports UDIMM 128 GB max, speeds up to 4400 MT/s

  • Supports unregistered ECC DDR5 DIMMs only

Storage Controllers
  • Internal Controllers: HBA355i Adpt, PERC H355 Adpt, PERC H755 Adpt, HBA355i front, H355 front, H755 front

  • Internal Boot: Internal USB 3.0, or Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 SSDs, USB

  • External HBAs (non-RAID): HBA355e Adpt

  • Software Controller: S160

Drive Bays Front bays:
  • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB

  • Up to 8 x 2.5-inch SAS/SATA (SSD) max 61.44 TB

Power Supplies
  • 600 W Platinum 100 -- 240 VAC or 240 VDC, hot swap redundant

  • 700 W Titanium 200 -- 240 VAC or 240 VDC, hot swap redundant

Cooling Options Air cooling
Dimensions
  • Height - 42.8 mm (1.68 inches)

  • Width - 482.0 mm (18.97 inches)

  • Depth - 585.3 mm (23.04 inches) without bezel

  • Depth - 598.9 mm (23.57 inches) with bezel

Form Factor 1U rack server


Key Features

High-Performance Computing

Powered by Intel® Xeon® processors with 4400 MT/s DDR5 memory and advanced NVMe BOSS-N1 for reduced latency and seamless scalability.


GPU Support

Supports NVIDIA A2 GPU for video and audio computing applications, ideal for retail, manufacturing, and logistics environments.


Advanced Security

Cyber Resilient Architecture with silicon root of trust, secure boot, TPM 2.0, and multi-factor authentication for Zero Trust environments.


Efficient Management

Dell OpenManage portfolio provides comprehensive systems management with automation tools for scalable infrastructure operations.


Management & Integration

Embedded Management: iDRAC9, iDRAC Direct, iDRAC RESTful API with Redfish
OpenManage Software: Enterprise, Power Manager, Service, Update Manager plugins
Integrations: VMware vCenter, Microsoft System Center, ServiceNow, Ansible, Terraform


Connectivity & Expansion

Embedded NIC: 2 x 1 GbE LOM
GPU Options: 1 x 60 W single-width GPU
PCIe: Up to two PCIe Gen4 slots
Ports: Comprehensive front and rear connectivity including USB, Ethernet, VGA, and serial ports


Operating Systems

Supports Canonical Ubuntu Server LTS, Microsoft Windows Server with Hyper-V, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, and VMware ESXi.


OEM-Ready Version Available

From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.


Sustainability & Services

Designed with recycled materials and energy-efficient components to reduce carbon footprint and operational costs. Backed by comprehensive Dell Technologies Services across 170+ countries.


Important Notices

  • Open the packaging, check the products carefully, and handle them gently

  • The product is brand new original unopened equipment

  • All products include 1 year warranty, buyer responsible for return shipping costs

  • International buyers responsible for import duties, taxes, and customs charges

  • We comply with all U.S. and international customs laws
