Panqi Heavy Industry presents our advanced Foam Laminating Machine engineered for precision bonding of diverse materials including EPE, XPE, EVA, PU foam, cardboard, and honeycomb structures. As an ISO9001-certified manufacturer established in 2019, we've exported industrial solutions to over 50 countries across North America, Europe, Asia, and Oceania, demonstrating our global manufacturing expertise.
Our laminator utilizes innovative hot melt technology to deliver superior adhesion without solvents, creating eco-friendly composites with exceptional bond strength. The machine's modular design allows customization for specific production requirements, enabling manufacturers to achieve:
- ✓ Consistent adhesive application with ±2% accuracy
- ✓ Seamless integration into existing production lines
- ✓ Energy savings through efficient thermal management
- ✓ Reduced material waste with precision edge control
Technical innovations include our proprietary melt tank design that maintains adhesive viscosity within ±5°C, ensuring optimal application consistency across continuous 24-hour operations.
| Working Width | 1200-2200mm (customizable) |
| Adhesive Consumption | 30-150g/m² adjustable |
| Temperature Range | 150-200°C (±1°C accuracy) |
| Line Speed | 5-15 meters/minute |
The heavy-duty construction features reinforced steel frames and industrial-grade components capable of handling material densities from 20kg/m³ to 250kg/m³. Our PLC-controlled system provides:
- • Real-time monitoring of temperature, speed, and adhesive flow
- • Preset programs for different material combinations
- • Automatic fault detection with diagnostic codes
- • Remote maintenance access capability
Backed by our 10,000-30,000 sqm manufacturing facility and team of 51-100 technical specialists, Panqi delivers robust machinery with US$5-10 million annual export validation. Serving diverse industries from automotive soundproofing to premium packaging, our laminators consistently demonstrate:
- → 30% faster setup time compared to conventional systems
- → 95% uptime reliability in demanding environments
- → 18-month mean time between failures
Frequently Asked Questions:
Q: What materials thickness can this machine handle?
A: Our system accommodates material thicknesses from 0.5mm to 50mm through adjustable pressure rollers and customizable nip settings.
Q: Can the machine apply different adhesive patterns?
A: Yes, our modular nozzle system can be configured for spiral spray, bead application, or curtain coating patterns based on your bonding requirements.
Q: What maintenance is required?
A: Daily cleaning of application heads and monthly lubrication of bearings. Full maintenance kits are provided with detailed schedules.
Q: Is training included?
A: Comprehensive operator training is provided either at our Zhengzhou facility or your production site.
Q: Can it laminate multiple layers simultaneously?
A: The standard configuration bonds two materials. For tri-laminate production, we offer optional secondary application modules.
Q: What adhesive types are compatible?
A: Designed for EVA, PES, PA, and PO-based hot melt adhesives with viscosity up to 50,000 cps at application temperatures.
Q: How long is the delivery time?
A: Standard configurations ship in 45 days. Custom solutions require 60-90 days based on complexity.
Q: What warranty is provided?
A: 18 months on mechanical components and 12 months on electrical systems with lifetime technical support.
