Help CenterSG-150 Automatic Checkweigher With Photoelectric Detection & Auto-Learning
Product Spotlights
Related Products
-
SG-150 Automatic Checkweigher With High-Speed Sorting FunctionNegotiableMOQ: 1 Piece -
SG-150 Industrial Checkweigher for Pharma & Food Production LinesNegotiableMOQ: 1 Piece
-
SG-150 Industrial Check Weigher Replace Manual Weighing Improve Production EfficiencyNegotiableMOQ: 1 Set
-
SG-150 Industrial Check Weigher With 0.1g Accuracy & 150kg CapacityNegotiableMOQ: 1 Set
-
Stainless Steel SG-150 Check Weigher for Food & Pharmaceutical PackagingNegotiableMOQ: 1 Set
As an established manufacturer since 2011, Zhejiang Zhong Shark Industrial Technology brings you the SG-150 Automatic Checkweigher – a precision instrument designed for rigorous quality control in production environments. Operating from our 30,000-50,000 sqm facility in Zhoushan, China, we've engineered this system to deliver exceptional accuracy through advanced photoelectric detection and auto-learning capabilities. With a workforce of 101-200 dedicated professionals, we've created a solution that meets international standards while serving diverse markets across North America, South America, Europe, Asia, and beyond.
Core Technical Advantages:
Intelligent Photoelectric Detection: Dual-beam sensors accurately detect product position and trigger weight measurement with millisecond precision
Self-Optimizing System: Auto-learning function continuously adapts to product variations without manual recalibration
High-Speed Processing: Capable of weighing up to 150 items per minute with dynamic weight-based sorting
Stainless Steel Construction: Food-grade SS304 contact parts ensure corrosion resistance and meet hygiene requirements
User-Centric Interface: 10" touchscreen with multilingual support for effortless operation and data management
Performance Specifications:
| Weight Range | 5g - 6kg |
| Accuracy Class | OIML Class II |
| Throughput Speed | 100-150 ppm (products/min) |
| Reject Mechanism | Pneumatic pusher or conveyor diversion |
Our ISO9001-certified manufacturing processes ensure every SG-150 unit delivers consistent performance. With extensive export experience through Shanghai and Ningbo ports, we've successfully deployed these systems across food packaging, pharmaceutical, and consumer goods industries worldwide. The combination of rugged construction (operating in 0-40°C environments) and sophisticated software makes this solution ideal for production lines requiring:
100% weight inspection compliance
Reduced giveaway through precise filling control
Automated quality documentation
Rapid changeover between product formats
Trusted Global Solution: Serving markets from North America to Oceania, our 101-200 employee strong team provides comprehensive support. The SG-150 represents over a decade of engineering refinement since our 2011 establishment, offering:
30,000+ hours MTBF (Mean Time Between Failures)
Configurable I/O for PLC integration
Remote diagnostics capability
Customizable conveyor lengths (500-2000mm)
Frequently Asked Questions:
Q: What conveyor width options exist?
A: Standard 150mm width with 200mm/250mm available upon request
Q: Is the system suitable for irregularly shaped items?
A: The photoelectric detection handles asymmetrical products effectively when properly configured
Q: What maintenance frequency is required?
A: Monthly cleaning of sensors and quarterly calibration checks are recommended
Q: Can it integrate with existing production data systems?
A: Yes, with Modbus TCP/IP, Ethernet/IP, and analog I/O options
Q: What power supply is needed?
A: 220V AC ±10%, 50/60Hz (other voltages customizable)
Q: How does auto-learning function work?
A: Machine learning algorithms analyze weight distributions to automatically adjust tolerance thresholds
