Help CenterHigh Speed Eddy Current Dynamometer for New Energy Motor Testing
Related Products
-
Eddy Current Dynamometer High Efficiency Power Torque Tester for Motor Industrial UseNegotiableMOQ: 1 Set -
High Precision Eddy Current Dynamometer Torque Speed Test BenchNegotiableMOQ: 1 Set
-
Electric Dynamometer for High-Power Motor TestNegotiableMOQ: 1 Set
-
Industrial Electric Dynamometer for Pump Fan and Industrial Motor TestingNegotiableMOQ: 1 Set
-
High Speed Electric Dynamometer for EV Motor and Powertrain TestNegotiableMOQ: 1 Set
High-speed eddy current dynamometer product introduction:
Applicable occasions of high-speed eddy current dynamometer: high-charged eddy current dynamometer is suitable for torque and power measurement of high-speed power machinery, especially suitable for simulation life test and temperature rise test of power machinery, such as compressor motors, new energy vehicle motors, air compressor motors, etc.
Features of high-speed eddy current dynamometer:
1. Simple structure, stable operation, low price, easy to use and maintain
2. Water cooling, low noise and low vibration;
3. The input speed range is wide, which can be used for type testing of different motors and power machinery such as frequency conversion speed regulation
4. The controller adopts single-phase AC power supply, and the control power is small;
5. The device can also be used as a brake, and the braking torque is large.
model |
Max.torque |
Rated speed |
Max.operating power |
Max.speed |
(N.m) |
(rpm) |
(W) |
(rpm) | |
| CNDWH1KS | 0.1 | 15000 | 250 | 40000 |
| CNDWH2KS | 0.2 | 15000 | 500 | 40000 |
| CNDWH5KS | 0.5 | 15000 | 800 | 40000 |
| CNDWH10KS | 1 | 10000 | 1200 | 30000 |
| CNDWH20KS | 2 | 10000 | 1500 | 30000 |
| CNDWH50KS | 5 | 9000 | 2000 | 25000 |
| CNDWH100KS | 10 | 6000 | 3000 | 20000 |
| CNDWH200KS | 20 | 6000 | 4000 | 15000 |
| CNDWH500KS | 50 | 4000 | 6000 | 10000 |
| CNDWH1KKS | 100 | 2000 | 8000 | 6000 |
1.Multiple measures can be taken to increase the operating power of the dynamometer, which can be requested when an order is being placed.
2.Specifications not listed in the table can be customized according to customer requirements.
3.The low-temperature water-cooled dynamometer with S must be equipped with a low-temperature circulating cooling-water tank device.
