Solderable Enamelled Wire 0.8mm With 600V Voltage Rating for Industrial Controls
Product Spotlights
0.8mm solderable enamelled wire with 600V rating enables direct soldering for industrial controls. Features high-temperature enamel insulation (155°C), copper conductivity, and vibration resistance. Manufactured under ISO-certified processes for consistent reliability in automation applications. Custom diameters available.
US$ 4.25
500 - 4999 Kilograms
US$ 4.20
≥5000 Kilograms
Key Specifications
Get Latest Price
Conductor Material:
Other, Copper
Application:
Other, Industrial Control Systems
Wire Diameter:
0.8 mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Self-Bonding Enamelled Wire 0.3mm With 10% Elongation for Precision CoilsUS$ 4.20 - 4.25MOQ: 500 Kilograms -
UL Certified Enamelled Wire 1.2mm With Double Coating for Automotive ElectronicsUS$ 4.20 - 4.25MOQ: 500 Kilograms
-
Enamelled Wire for Medical Equipment Windings With RoHS Compliance ReportUS$ 4.20 - 4.25MOQ: 500 Kilograms
-
Heavy Duty Enamelled Wire for Oil-Immersed Transformer ApplicationsUS$ 4.20 - 4.25MOQ: 500 Kilograms
-
Enamelled Magnet Wire With ISO 9001 Certified Manufacturing ProcessUS$ 4.20 - 4.25MOQ: 500 Kilograms
Conductor Material
Other, Copper
Application
Other, Industrial Control Systems
Wire Diameter
0.8 mm
Voltage Rating
600 V
Insulation Type
Enamel Coating
Solderability
Direct Solderable
Conductor Type
Solid Core
Temperature Class
Class F (155°C)
Standards Compliance
International Electrical Standards
Manufactured by Shandong Huilong Electrical Material Co., Ltd., a trusted industry leader since 1970, this solderable enamelled wire delivers exceptional electrical insulation and reliability for demanding industrial applications. With a specialized 0.8mm diameter and 600V voltage rating, it ensures precise performance in motor windings, transformers, and control systems. Our 50+ years of expertise guarantees consistent quality across global markets.
Technical Specifications & Benefits:
- Direct solderability eliminates stripping requirements, reducing assembly time by up to 40%
- High dielectric strength enamel coating prevents short circuits in high-vibration environments
- Thermal stability maintains integrity at continuous 155°C operating temperatures
- Low oxidation copper core ensures minimal resistance fluctuations
| Parameter | Value |
|---|---|
| Tensile Strength | 120 - 160 MPa |
| Elongation | ≥ 15% |
| Insulation Thickness | 0.020 - 0.025 mm |
| Resistance (20°C) | 34.6 Ω/km |
Backed by ISO 9001 and ISO 14000 certified manufacturing across our 20,000m² facility, Huilong exports over $100M annually to North America, Europe, and Asia. With 100+ skilled employees ensuring stringent quality control, this wire minimizes downtime in automation systems while offering:
- Customizable spooling options
- Consistent batch-to-batch performance
- Technical support for integration challenges
Frequently Asked Questions:
-
Q: What solder temperatures are recommended?
A: Optimal results at 380°C ± 20°C with lead-free solder. -
Q: Is it suitable for high-frequency applications?
A: Yes, low capacitance design supports frequencies up to 10 kHz. -
Q: What packaging options exist?
A: Available on 5kg-25kg spools with moisture-resistant wrapping. -
Q: Can it withstand chemical exposure?
A: Resistant to common solvents; compatibility data available upon request. -
Q: Are custom diameters available?
A: Yes, diameters from 0.2mm to 2.0mm can be customized. -
Q: What's the lead time for bulk orders?
A: Standard production requires 15-20 days; expedited options possible.
Serving 15+ global markets from our Shandong facility, Huilong combines rigorous SA8000-compliant production with efficient logistics via Qingdao/Shanghai ports. Contact us today for samples or volume pricing to enhance your control system reliability.
