The Lab scale sterilizer completely simulates the industrial production sterilization in the laboratory. It is widely used for taste test of new product, research of product formulation, formula update, evaluation of product color, test of shelf life, etc. It is designed to replicate industrial scale heat exchanger in the laboratory.
The Lab scale sterilizer is manufactured with advanced design and technologies to meet requirements from universities, institutes, enterprises’ R&D department for simulating industrial manufacture and research in laboratory.
Application:
In the laboratory of universities and institutes and enterprises’ R&D department, it is completely simulated the industrial production sterilization in the laboratory, used for taste test of new product, research of product formulation, formula update, evaluation of product color, test of shelf life , etc.
It is suitable for wide range of visidity, and can precisely mimic product preparation, homogenization, aging, pasteurism, fast sterilization under ultra-temperature.
Technology data
|
Name |
Lab Tubular UHT sterilizer |
|
Rated capacity: L/H |
20-100L |
|
Power: KW |
13-28KW |
|
Max. pressure:bar |
10 |
|
Minimum batch feed: L |
3 |
|
SIP function |
Available |
|
CIP function |
Available |
|
Homogenization inline |
Optional |
|
Aseptic filling inline |
Optional |
|
Sterilization temperature: ℃ |
85~150 |
|
Holding time: Second |
3/5/10/20/30/300(Choose Either) |
|
Outlet teperature: ℃ |
Adjustable |
|
Dimension:mm |
5000×1500×2000 |
