Brief introduction:
This production line can finish raw material mixing, disinfection, even quality, cooling, aging, ,congealment, filling and hardening.
This production line is the automatic model, which can finish automatically from feeding to finished products.
Electrical equipment art controlled in a centralized way, which doesn’t need steam boiler and other cooling equipment
This production line can produce kinds of ice cream, such as cup ice cream,egg-tray ice cream,stick ice cream,chocolate-coated ice cream,kernel ice cream and ice sucker, etc, by only changing the filling equipment.
Process:
Mixing, disinfection, viscolizer machine------plate heat exchanger-----aging barrel-----cooling machine group------congealment machine-------automatic filling machine
Technical data:
Model |
Capacity |
Water consumption |
Expansibility |
refrigerating fluid |
Power |
Voltage |
dimension |
GGBQL-500 |
500kg/8h |
6t vadose water |
90-100% |
R-22 |
27KW |
380V 50Hz |
9200*3500*1500mm |
GGBQL-1000 |
1000kg/8h |
6t vadose water |
90-100% |
R-22 |
46KW |
380V 50Hz |
12000*3200*1800mm |
Feature:
Complete in Set: Electrical equipment art controlled in a centralized way, no need to have steam boiler and other cooling equipment.
Rich in Varieties: The production line can realize the changes of many varieties only by replacing its feeding head. It can produce cup ice cream, egg-tray ice cream, stick ice cream, chocolate-coated ice cream,kernel ice cream and ice sucker.
Perfect in Service: We can install, adjust and test our equipment, train personnel, provide technology and prescriptions, all free of charge, until qualified products are made so as to ensure your investment is perfectly safe.
