US$ 4.31 50 - 499 Kilograms
US$ 4 500 - 999 Kilograms
US$ 3.08 ≥1000 Kilograms
Key Specifications
Get Latest Price
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Kaixin Metal Products Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

Alloy aluminum plate. Magnesium is the main alloying element in the 5052 alloy aluminum plate. It is the most widely used anti-rust aluminum. This 5052 aluminum plate alloy has high strength, especially high fatigue strength. It has high plasticity and corrosion resistance and cannot be strengthened by heat treatment. It has good plasticity when semi-cold worked and low plasticity when cold worked. It has good corrosion resistance, good weldability, poor machinability, and can be polished.

The aluminum-magnesium alloy also contains small amounts of manganese, chromium, beryllium, titanium, etc. Most of the manganese in the alloy forms MnAl6 except for a small amount in solid solution. In the 5052 aluminum plate, the role of chromium is similar to that of manganese. It improves the resistance to stress corrosion cracking, increases the strength of the base metal and the weld, and reduces the tendency of welding cracks.

Chemical Composition

Chemical Composition

Aluminum Al: Balance

Silicon Si: ≤0.25

Copper Cu: ≤0.10

Magnesium Mg: 2.2~2.8

Zinc Zn: ≤0.10

Manganese Mn: ≤0.10

Chromium Cr: 0.15~0.35

Iron Fe: ≤0.40

Note: Single: ≤0.05; Total: ≤0.15

Mechanical Properties

Mechanical Properties

Tensile strength (σb): 170~305MPa

Yield strength under specified conditions σ0.2 (MPa) ≥ 90

Elastic modulus (E): 69.3~70.7Gpa

Annealing temperature: 345℃.













Product Tags: 5052-H32 , 5052- , 5052-H32 alloy aluminum plate , Alloy aluminum plate , Thin plate
