Factory Curved 3D 3V Powder Coating Welded Wire Mesh Fence
Product descriptions
3D Curved Welded Wire Fence is a combination of wires in the horizontal and vertical direction welded at their junctions to provide a rigid wire mesh fence. A number of differing designs are manufactured from 3mm to 8mm wire at varying spacings for economy or strength. Styles with minimum horizontal bars widely spaced are used to restrict or deny climbing. Most curvy welded fence is supplied in a "hot galvanised" finish, due to their exposure to the elements and particularly salt laden atmospheres. However, for a more pleasing effect they can be powder coated in a range of popular colours.
PVC Coated welded wire mesh fence, also named pvc Coated Welded Wire Fence, Security Fence, V-MEX, FS CERCA, PRO 55, PARAMESH DECO, VGUARD, V-pressed welded mesh, Profile Weld Mesh, Plastice coated welded fence, Galvanized and PVC Coated Welded Mesh Fence /Security Welded Wire Fence/ Welded curved Panel fence etc...
We own the largest fence factory in Northern China; enable us to offer the best.
Welded Wire Mesh Fence Property: corrosion resistance, aging resistance, UV resistance and weather resistance.
----------------------------
Common specification:
|
Panel Height |
Panel Width | Wire Dia. | Profiles | Mesh Size | Post Height | Post size |
| 630mm | 2500mm | 5mm | 2 | 200x50mm | 1100mm | 60x40x2mm |
| 1030mm | 2500mm | 5mm | 2 | 200x50mm | 1600mm | 60x40x2mm |
| 1530mm | 2500mm | 5mm | 3 | 200x50mm | 2100mm | 60x40x2mm |
| 1730mm | 2500mm | 5mm | 3 | 200x50mm | 2400mm | 60x40x2mm |
| 2030mm | 2500mm | 5mm | 4 | 200x50mm | 2600mm | 60x40x2mm |
| 2430mm | 2500mm | 5mm | 4 | 200x50mm | 3100mm | 60x40x2mm |
Note: We also can make the size according to your requirements.
Full RAL range colors is available.
3D Curved Welded Wire Fence Applications:
Mainly used in highway and railway bridge on both sides of the protection zone.
Airports, ports, terminals security.
Municipal building in the park, lawn, zoo, pool lake, roads, and residential isolation.
Guest Houses, hotels, supermarkets and entertainment protective.
Specifications of 3D Curved Welded Wire Fence
| Height Above Ground (m) |
Panel Size (mm) |
Mesh Size (mm) |
Numbers of Beams |
Post Diameter (mm) |
| 1.2 | 1230x2500 | 50x100/50x200 | 2 | 50x70 |
| 1.8 | 1830x2500 | 50x100/50x200 | 3 | 50x70 |
| 2.0 | 2030x2500 | 50x100/50x200 | 4 | 70x100 |
| We can also manufacture the weld mesh fencing as per your dimension of the specification |
