3D PVC Coated Green Security Steel Fence , 5.0mm Wire Mesh Fence Panels
Product descriptions
It is made of high quality low carbon steel wire, galvanized wire. Then will be hot dipped galvanized,powder coated or pvc coated. It looks modern and attractive. Mainly used for security protection in construction site, residential building, sports field, warehouse, highway or airport service area, railway station, etc.
The height are available in a range of heights from 630 till 2430 mm.
The panels have vertical barbs of 30 mm that can be placed at the top or at the bottom.
The horizontal reinforcements of Bekafor Classic give the panels extra rigidity.
The popular wire diameter are 4.0mm and 5.0mm,mesh holes are 50×100mm,50×150m,50×200mm,others are available.
Common specification:
|
Panel Height |
Panel Width | Wire Dia. | Profiles | Mesh Size | Post Height | Post size |
| 630mm | 2500mm | 5mm | 2 | 200x50mm | 1100mm | 60x40x2mm |
| 1030mm | 2500mm | 5mm | 2 | 200x50mm | 1600mm | 60x40x2mm |
| 1530mm | 2500mm | 5mm | 3 | 200x50mm | 2100mm | 60x40x2mm |
| 1730mm | 2500mm | 5mm | 3 | 200x50mm | 2400mm | 60x40x2mm |
| 2030mm | 2500mm | 5mm | 4 | 200x50mm | 2600mm | 60x40x2mm |
| 2430mm | 2500mm | 5mm | 4 | 200x50mm | 3100mm | 60x40x2mm |
Note: We also can make the size according to your requirements.
Full RAL range colors is available.
3D Curved Welded Wire Fence Applications:
Mainly used in highway and railway bridge on both sides of the protection zone.
Airports, ports, terminals security.
Municipal building in the park, lawn, zoo, pool lake, roads, and residential isolation.
Guest Houses, hotels, supermarkets and entertainment protective.
Specifications of 3D Curved Welded Wire Fence
| Height Above Ground (m) |
Panel Size (mm) |
Mesh Size (mm) |
Numbers of Beams |
Post Diameter (mm) |
| 1.2 | 1230x2500 | 50x100/50x200 | 2 | 50x70 |
| 1.8 | 1830x2500 | 50x100/50x200 | 3 | 50x70 |
| 2.0 | 2030x2500 | 50x100/50x200 | 4 | 70x100 |
| We can also manufacture the weld mesh fencing as per your dimension of the specification |
