Technical parameters:
Model: Y-HU-150G
2. Internal box size: 400 x 500 x 400 mm
3. Form size: 650 x 1550 x 1010 mm
4. Temperature range: low temperature - 70 ° C ~ high temperature 150 ° C
5. Humidity range: standard type (20% ~ 98% RH)
6. Temperature resolution: 0.01 ° C
7. Temperature volatility: ≤ ± 0.5 ° C
8. Humidity volatility:
9. Temperature uniformity: ± 2.0 ° C
10. Humidity deviation: 75% R.H below ± 5.0% RH, 75% R.H above + 2.0 / -3.0% RH
11, heating rate: about 1.0 ° C ~ 3.0 ° C / min
12, cooling rate: about 0.8 ° C to 1.3 ° C\ min
13, power requirements: AC220V / 50HZ
This is a newly designed test box. The test box has stable performance, high accuracy, very little noise and a small area. It is the choice of office buildings and laboratories. High-temperature alternating humidity test boxes are called programmable humidity and humidity testing boxes mainly used for environmental reliability tests of products and materials. The simulated environmental requirements include: high temperature, low temperature, humidity, high temperature constant, high temperature cycle, high temperature alternating, constant humidity and humidity alternating, high temperature high humidity high humidities, low temperature high moisture high humidified, high temperature low moisture low humidified and high temperature low wet humidified. Factory sales hotline: Optoelectronic communication high-temperature test boxes are widely used in: electronics, electrical, electrical appliances, batteries, computers, power supplies, motors, electronic products, electronic components, resistors, capacitors, wires, cables, circuit boards, circuit plates, PCBs, FPCs, LEDs, LCDs, military, Aviation, aerospace, automotive, automotive parts, automotive electronics, chemical, chemicals, coatings, paints, inks, printing, adhesives, plastics, plastics polyethylene, rubber, hardware, ceramics, building materials, polymer materials, synthetic materials and other products scientific research, research and development, quality testing, etc. Inner Box Material: SUS304 Stainless Steel Outer Box Material: Cold Rolled Steel Plate Paint Treatment Thermal Insulation Material: Rigid polyurethane foam or ultra-fine glass wool, It has good thermal insulation and other characteristics. Seal: imported silicone seal strips Controlling temperature and humidity mode: PID control SSR balance temperature and moisture 'heating: stainless steel wing air heating and humidification: shallow tank steam humidification Refrigerant: originally imported fully enclosed French Tikang compressor, Mechanical single-stage or overlapping refrigeration equipment water purifier (optional) electrically powered automatic water insertion (optional) Convection system: custom aluminum wind blades of special motors for air conditioning equipment runtime timer: 120 sets of programs, 1200 sequences, up to 999 cycles, and each sequence time is set at 99 hours and 59 minutes. A large area of observation window in the center of the door is equipped with observation lights, fully automatic control and safety protection system, and the controller uses a touchscreen temperature and humidity controller.
