Guangzhou Jiana Building Materials Co., Ltd. is headquartered in Panyu District, Guangzhou. It is one of the most powerful manufacturers of metal ceilings, suspended ceilings, and curtain walls in mainland China. The company mainly produces and sells aluminum honeycomb panels, aluminum corrugated panels, aluminum single panels, aluminum square tubes, aluminum gusset plates, aluminum grilles, and aluminum hanging sheets. The company has a 23 - year - old aluminum single panel design and R & D team, a 300 - person installation team, a 30,000 - square - meter factory building, and 26.8 million worth of fully automated German production equipment. It mainly has a fully automated honeycomb panel production workshop, a fully automated corrugated panel production workshop, a curtain wall panel processing workshop, a special - shaped panel processing workshop, a fully automated spraying workshop, a large - scale warehouse, and a comprehensive office building. It has high production efficiency, low cost, and good quality. Standard panels can be delivered one day after ordering, and customized panels can be delivered in 3 - 7 days. All products are sold directly by the manufacturer, saving customers 55% of the cost of middle - man price differences. The manufacturer has its own logistics team, providing free delivery nationwide, free on - site measurement, and free design. Call now and get free samples. The company can undertake one - stop services from on - site measurement to product customization, design, production, and installation. 24 - hour service hotline: 18620062003
Aluminum single panel is a new type of ceiling, interior wall, and exterior wall decoration material. It uses high - quality aluminum alloy sheets as the base material, is formed through technologies such as CNC bending, and has a decorative coating sprayed on its surface.
The base material of aluminum single panel uses single - layer aluminum alloy sheets dedicated to curtain walls, such as 1100H24, 1060H24, 3003H24, 5005H24.
The structure of fluorocarbon aluminum single panel mainly consists of components such as the panel, stiffeners, and corner codes. The size of the formed workpiece can be 1300mmX2400mm (L X W)
The coatings use well - known brand coatings such as PPG from the United States, Valspar from the United States, AKzoNobel from the Netherlands, and KCC from South Korea. The coating process is divided into two - coat - one - bake and three - coat - two - bake, and its coating performance meets the standards of AAMA (American Architectural Manufacturers Association) and ASCA (American Architectural Sprayers Council)
AAMA2605 - 98 standard.
Regular thicknesses: 2.0mm, 2.5mm, 3.0mm.
Common specifications: 600*600mm, 600*1200mm
Features of aluminum single panel:
1. Lightweight, good rigidity, and high strength. A 3.0mm - thick aluminum plate weighs 8Kg per square meter, and its tensile strength is 100 - 280n/mm2
2. Good weather resistance and corrosion resistance. Using Dvdf fluorocarbon paint with kynar - 500 and hylur500 as the base material can ensure no color fading for 25 years.
3. Good processability. Using the process of first processing and then painting, the aluminum plate can be processed into various complex geometric shapes such as planes, arcs, and spheres.
4. Uniform coating and diverse colors. The advanced electrostatic spraying technology ensures uniform adhesion between the paint and the aluminum plate, with a wide variety of colors and a large selection space.
5. Resistant to staining and easy to clean and maintain. The non - adhesive property of the fluorine coating film makes it difficult for contaminants to adhere to the surface, and it also has good self - cleaning properties.
6. Convenient and fast installation and construction. The aluminum plates are formed in the factory, and there is no need for cutting at the construction site. They can be fixed on the framework.
7. Recyclable and environmentally friendly. Aluminum plates can be 100% recycled. Different from decorative materials such as glass, stone, ceramics and aluminum - plastic panels, they have a high recycling residual value.
Application occasions of aluminum veneers: 1. Building exterior walls, beams and columns, balconies; 2. Airport/railway station terminals; 3. Conference halls, opera houses; 4. Sports stadiums; 5. Reception lobbies, etc.
Note: The above parameters are the commonly used specifications and dimensions of aluminum veneers. Changsheng can customize the production of aluminum veneers by matching the length, width and thickness according to the on - site needs of users. The production period of aluminum veneers is generally 7 - 10 days.
