4-Position Digital Magnetic Hotplate Stirrer SHA-4N
It is widely used in chemical synthesis,physical and chemical analysis, bio-pharmaceuticals etc.
Features
• Independent heating and stirring control
• LED display shows actual temperatures and speed
• PID controller ensures a precise and steady heating process, Max.temperature up to 220℃
• Brushless DC motor enables more powerful speed control
• External temperature sensor(PT1000) with accuracy at 0.2℃
• Overheating protection temperature at 220℃
• Stainless steel work plate with ceramic coating provides good chemical-resistant performance
• A wide variety of accessories are available
fications |
SHA-4N |
Work plate dimension |
220*550 |
Plate material |
aluminum with ceramic coating |
Motor type |
Brushless DC motor |
Motor rating input[W] |
30W×10 |
Power[W] |
800W |
Heating Power[W] |
800W |
Voltage |
100-120V,60Hz; 200-240V,50 Hz |
Stirring positions |
10 |
|
Max. stirring quantity of single position (H2O) |
1L*10 |
Max. magnetic bar[mm] |
35 |
Speed range[rpm] |
100-2000 |
Speed display |
LED |
Temperature display |
LED |
Control accuracy of sensor[rpm] |
±20 |
Temperature range[°C] |
25-220℃ |
Over temperature protection[°C] |
240 |
Temperature display accuracy[°C] |
±0.1 |
External temp. sensor |
PT1000(Accuracy±0.2℃) |
IP Protection class |
IP21 |
Dimensions[WxDxH][mm] |
650*220*85 |
Weight[kg] |
15kg |
Permissible ambient temperature[°C] |
5~40 |
Permissible relative humidity |
80% |
