**Technical Parameters of XP-3380II Oxygen Content Detector COSMOS New Universe Handheld Oxygen Concentration Meter**
**General Specifications:**
- **Model:** XP-3380II
- **Product Name:** COSMOS New Universe Handheld Oxygen Concentration Meter
- **Measurement Principle:** Electrochemical sensor
- **Measurement Range:** 0.0% to 30.0% O₂
- **Resolution:** 0.1% O₂
- **Accuracy:** ±1.0% of full scale
- **Response Time:** ≤15 seconds (for 90% response)
- **Operating Temperature:** -10°C to 50°C (14°F to 122°F)
- **Operating Humidity:** 0% to 95% RH (non-condensing)
- **Sampling Method:** Diffusion or optional pump sampling
- **Display:** LCD with backlight
- **Power Supply:** Rechargeable lithium battery (included)
- **Battery Life:** Approximately 24 hours of continuous use
- **Charging Time:** 4-6 hours
- **Dimensions:** 180 mm × 75 mm × 35 mm (7.1" × 3.0" × 1.4")
- **Weight:** Approximately 300 g (0.66 lbs)
**Features:**
- Portable and lightweight design for easy handling.
- High-precision electrochemical sensor for reliable oxygen concentration measurement.
- Real-time data display with clear LCD screen.
- Low power consumption with long battery life.
- Alarm function for high/low oxygen concentration levels.
- Data logging capability (optional).
- Suitable for industrial, medical, and environmental applications.
**Applications:**
- Industrial safety monitoring in confined spaces.
- Medical oxygen therapy and respiratory equipment testing.
- Environmental air quality assessment.
- Laboratory research and educational purposes.
**Accessories Included:**
- XP-3380II main unit
- Rechargeable lithium battery
- USB charging cable
- User manual
- Carrying case
**Optional Accessories:**
- External sampling pump
- Data logging software
- Calibration kit
**Note:** Specifications are subject to change without prior notice. For optimal performance, regular calibration and maintenance are recommended.
